2016 TOYOTA PRIUS V Owners Manual

PRIUS v_OM_OM47B12U_(U)
3776-3. Using the storage features
6
Interior features
Push the button to open the lid.
The lid can be opened by pushing
either the front or rear button.
●If the lower glove box is opened when the parking lights are illuminated, the
light illuminates.
Glove boxes
Upper glove boxLower glove box
Pull up the lever. Pull up the lever.
Console box
●The tray slides forward/backward and
can be removed.

378
PRIUS v_OM_OM47B12U_(U)
6-3. Using the storage features
■Cup holders
Cup holders/bottle holders/door pockets
Front passenger’s sideCenter console (front)
Push the lid. Type A
Type B
Pull out the lid.
Center console (rear)
Open the lid and adjust the holder.
When closing, stow the holder
before closing the lid.
1
2

PRIUS v_OM_OM47B12U_(U)
3796-3. Using the storage features
6
Interior features
■Bottle holders/door pockets
●When storing a bottle, close the cap.
●The bottle may not be stored depending on its size or shape.
Front doorsRear doors
●The type B cup holder on the center con-
sole (front side): The cup holder can be
used store small objects if the inner tray
is removed.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles or glass
and paper cups containing liquid in the bottle holders.
The contents may spill and glasses may break.

380
PRIUS v_OM_OM47B12U_(U)
6-3. Using the storage features
Auxiliary boxes
Type A (if equipped)Type B
Press in the lid.
The overhead console is useful for
temporarily storing small items.
WARNING
Do not store items heavier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident. (type A)
Card holder

381
PRIUS v_OM_OM47B12U_(U)
6-3. Using the storage features
6
Interior features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
Cargo hooks

382
PRIUS v_OM_OM47B12U_(U)
6-3. Using the storage features
Auxiliary boxes
Center Side
Pull the lever upward to lift the
deck board.
When using the auxiliary box on
the front of the vehicle, fold and
pick up the deck board and move it
toward the front of the vehicle.
Lift the center deck board and
then lift the side deck boards.
Lift the side deck board from the
front side of the vehicle to prevent
hitting the cargo hook.
Behind the rear seats
Umbrellas (less than 30 in. [77
cm] long) can be stored.

PRIUS v_OM_OM47B12U_(U)
3836-3. Using the storage features
6
Interior features
■Installing the luggage cover
Set the holder of one side into
the installation position, then
install both holders from below
with the cover in its contracted
state.
■Using the luggage cover
Pull out the luggage cover and
secure it to the hook brackets.
Attach the hooks to the head
restraints.
■Removing the luggage cover
Retract the cover and release
both ends, then lift it out.
Luggage cover

384
PRIUS v_OM_OM47B12U_(U)
6-3. Using the storage features
■Stowing the luggage cover
Lift the center deck board
and remove the side deck
boards.
Fold inwards together with
the head restraint installation
hooks and secure. Then,
stow in the auxiliary boxes.
1
2
WARNING
●To avoid injury, always return the cargo hooks to their stowed positions
when not in use.
●If the deck boards are removed, return them to their original positions
before driving. In the event of sudden braking, an accident may occur due
to an occupant being struck by the deck boards or the items stored in the
auxiliary box.
●Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.
