P0520 EOP SENSOREC-339
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0520 EOP SENSOR
DTC LogicINFOID:0000000012431537
DTC DETECTION LOGIC
NOTE:
If DTC P0520 is displayed with DTC P0643, first pe
rform the trouble diagnosis for DTC P0643. Refer to
EC-356, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.CHECK ENGINE OIL LEVEL
Check engine oil level. Refer to LU-7, "
Inspection".
Is inspection result normal?
YES >> GO TO 3.
NO >> Check engine oil leak. Refer to LU-7, "
Inspection".
3.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-339, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431538
1.CHECK ENGINE OIL PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect engine oil pressure sensor harness connector.
3. Turn ignition switch ON.
4. Check the voltage between engine oil pressure sensor harness connector terminals.
Is inspection result normal?
YES >> GO TO 2
NO >> Repair or replace error-detected parts.
DTC No. CONSULT screen terms
(Trouble diagnosis content) Detecting condition
Possible cause
P0520 EOP SENSOR/SWITCH
[Engine oil pressure sensor
circuit] ECM detects the following status continuously for
5 seconds or more:
• A voltage signal transmitted from the engine oil
pressure sensor is lower than 0.3 V.
• A voltage signal transmitted from the engine oil pressure sensor is higher than 5.02 V. • Harness or connectors
(Engine oil pressure sensor circuit is
open or shorted.)
• Engine oil pressure sensor
Engine oil pressure sensor GroundVo l ta g e
(Approx.)
Connector Terminal
F38 1Ground 5 V
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-340
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0520 EOP SENSOR
2.CHECK ENGINE OIL PRESSURE SENSOR
GROUND CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between engine oil pressure sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK ENGINE OIL PRESSURE SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between engine oil pressure sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK ENGINE OIL PRESSURE SENSOR
Refer to EC-340, "
Component Inspection".
Is inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Replace engine oil pressure sensor. Refer to EM-93, "
Exploded View".
Component InspectionINFOID:0000000012431539
1.CHECK ENGINE OIL PRESSURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect engine oil pressure sensor harness connector.
3. Check resistance between engine oil pr essure sensor connector terminals.
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Replace engine oil pressure sensor. Refer to EM-93, "
Exploded View".
Engine oil pressure sensorECM
Continuity
Connector Terminal Connector Terminal
F38 3F11 60 Existed
Engine oil pressure sensor ECM
Continuity
Connector Terminal Connector Terminal
F38 2F11 47 Existed
Engine oil pressure sensor
Condition Resistance (kΩ)
Te r m i n a l
1 2
None 4 – 10
32 – 8
2 1
4 – 10
31 – 3
3 12
– 8
21 – 3
Revision: August 2015 2016 Versa Note

cardiagn.com

P0524 ENGINE OIL PRESSUREEC-341
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000012431540
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0520 or P0075,
perform trouble diagnosis for DTC P0520 or P0075
first. Refer to EC-339, "
DTC Logic" or EC-180, "DTC Logic".
DTC CONFIRMATION PROCEDURE
CAUTION:
If “Diagnosis Procedure” is unfinish ed, be sure to perform Step 3 and 4.
1.PRECONDITIONING-I
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PRECONDITIONING-II
Is
“Diagnosis Procedure” of DTC P0524 finished?
YES >> GO TO 5.
NO >> GO TO 3.
3.CHECK ENGINE OIL LEVEL
Check engine oil level. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Proceed to EC-342, "
Diagnosis Procedure"
4.CHECK ENGINE OIL PRESSURE
WITH CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. Start the engine and check that “EOP SENSOR” changes, according to engine speeds.
Without CONSULT
DTC No. CONSULT screen terms
(Trouble diagnosis content) Detecting condition
Possible cause
P0524 ENGINE OIL PRESSURE
(Engine oil pressure too low) An engine oil pressure sensor signal
voltage applied to ECM remains lower
than the specified value continuously for
10 seconds or more when the engine
speed is 1,000 rpm or more. • Decrease in engine oil pressure
• Decrease in engine oil level
• Engine oil condition
• Engine oil pressure sensor
• Engine body
Monitor item
Condition Va l u e
(Approx.)
EOP SENSOR • Engine oil temperature: 80
°C (176 °F)
• Selector lever: P or N position (CVT), Neutral position (M/T)
• Air conditioner switch: OFF
• No load Engine speed:
600 rpm
1,053 mV or more
Engine speed:
2,000 rpm 1,802 mV or more
Revision: August 2015
2016 Versa Note

cardiagn.com

EC-342
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0524 ENGINE OIL PRESSURE
Check engine oil level. Refer to
LU-7, "Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Proceed to EC-342, "
Diagnosis Procedure"
5.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Maintain the following conditions for about 10 consecutive seconds.
NOTE:
With engine speed set around 4,000 rpm, the phenomenon can be reproduced more easily.
3. Check DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-342, "Diagnosis Procedure"
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431541
1.CHECK ENGINE OIL LEVEL
1. Turn ignition switch OFF.
2. Check engine oil level. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK ENGINE OIL PRESSURE
WITH CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. Start the engine and check that “EOP SENSOR” changes, according to engine speeds.
Without CONSULT
Check engine oil level. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check oil pressure. Refer to LU-7, "
Inspection".
3.CHECK ENGINE OIL PRESSURE SENSOR
Check engine oil pressure sensor. Refer to EC-340, "
Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Replace engine oil pressure sensor. Refer to EM-93, "
Exploded View".
4.CHECK ENGINE OIL LEAKAGE
Check engine oil leakage. Refer to LU-7, "
Inspection".
Selector leverP or N position (CVT)
Neutral position (M/T)
Engine coolant temperature 70° C (158°F) or more
Engine speed 1,000 rpm or more
Monitor item Condition Va l u e
(Approx.)
EOP SENSOR • Engine oil temperature: 80°
C (176°F)
• Selector lever: P or N position (CVT), Neutral position (M/T)
• Air conditioner switch: OFF
•No load Engine speed:
600 rpm
1,053 mV or more
Engine speed:
2,000 rpm 1,802 mV or more
Revision: August 2015
2016 Versa Note

cardiagn.com

P0524 ENGINE OIL PRESSUREEC-343
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK CAUSE OF ENGINE OIL CONSUMPTION
Check the following item.
>> Repair or replace error-detected parts.
Component InspectionINFOID:0000000012431542
1.CHECK ENGINE OIL PRESSURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect engine oil pressure sensor harness connector.
3. Check the resistance between engine oil pressure sensor connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace engine oil pressure sensor. Refer to EM-93, "
Exploded View".
Step Inspection itemEquipmentStandardReference
1PCV valve EC-476, "
Inspection"
2 Exhaust front tubeVisual• No blocking
• No abnormal sounds —
3 Oil pump Visual• No blocking
• No damage
—
4 •Piston
• Piston pin
• Piston ring • Piston to piston pin oil clearance
EM-102, "
Inspection"
• Piston ring side clearanceEM-102, "
Inspection"
• Piston ring end gapEM-102, "
Inspection"
5 Cylinder block • Cylinder block top surface distortion
EM-102, "Inspection"
• Piston to cylinder bore clearanceEM-102, "
Inspection"
Engine oil pressure sensor
Resistance (kΩ)
+ −
Te r m i n a l
1 24
– 10
32 – 8
2 14
– 10
31 – 3
3 12
– 8
21 – 3
Revision: August 2015 2016 Versa Note

cardiagn.com

P059F ACTIVE GRILLE SHUTTEREC-347
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
3. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform trouble diagnosis for power supply circuit.
NO >> Repair or replace the error-detected parts.
12.CHECK ACTIVE GRILLE SHUTTER RELAY SIGNAL CIRCUIT - 2
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between active grille shutter relay harness connector and IPDM E/R harness con- nector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> Perform trouble diagnosis for power supply circuit.
NO >> Repair or replace the error-detected parts.
Component Inspection (Active Grille Shutter)INFOID:0000000012431545
1.CHECK ACTIVE GRILLE SHUTTER
With CONSULT
1. Start the engine.
2. Select “ACTIVE GRILLE SHUTTER” in “ACT IVE TEST” mode of “ENGINE” using CONSULT.
3. Touch “CALIBRTN”.
4. After the calibration completes, check the operation of active grille shutter as follows.
Without CONSULT
1. Turn ignition switch OFF.
2. Operate shutter by hands to close position.
3. Check the operation of active grille shutter as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace active grille shutter. Refer to EXT-33, "
Removal and Installation".
Component Inspection (Act ive Grille Shutter Relay)INFOID:0000000012431546
1.CHECK ACTIVE GRILLE SHUTTER RELAY
1. Turn ignition switch OFF.
+
Fuse No. Continuity
Active grille shutter relay
Connector Terminal E72 5 27 Existed
+ −
Continuity
Active grille shutter relay IPDM E/R
Connector Terminal Connector Terminal E72 2F42 39 Existed
Condition Active grille shutter
Select “CLOSE” Close → Open
Select “OPEN” Open → Close
Condition Active grille shutter
Ignition switch: ON Close → Open
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-350
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0604 ECM
P0604 ECM
DTC LogicINFOID:0000000012741286
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm th at battery voltage is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON (engine stopped) and wait least 20 minutes. CAUTION:
Never start engine during this procedure.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-350, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012741287
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-350, "
DTC Logic".
Is the 1st trip DTC
P0604 displayed again?
YES >> Replace ECM. Refer to EC-477, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition
Possible cause
P0604 ECM
[Internal control module
random access memory
(RAM) error] Malfunction in the internal RAM of ECM.
ECM
Revision: August 2015 2016 Versa Note

cardiagn.com

P0605 ECMEC-351
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0605 ECM
DTC LogicINFOID:0000000012741288
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltag e is 11 V or more with ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON (engine stopped) and wait least 20 minutes. CAUTION:
Never start engine during this procedure.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Turn ignition switch ON.
4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-351, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012741289
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC confirmation procedure. Refer to EC-351, "
DTC Logic".
Is the 1st trip DTC
P0605 displayed again?
YES >> Replace ECM. Refer to EC-477, "Removal and Installation".
NO >> INSPECTION END
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition
Possible cause
P0605 ECM
[Internal control module
read only me
mory (ROM)
error] Malfunction in the internal ROM of ECM.
ECM
Revision: August 2015 2016 Versa Note

cardiagn.com
