2016 NISSAN MAXIMA Nissan Connect Navigation Manual


> (GLW    0RGHO 1&*1-1 @
*12:
Depending on the screen, pushing the
button will display the previous screen.
For character input operation, push or push
and hold to delete the characters entered.
Push and hold to quit the voice recognition
session.
ª7. Voice recognitionº
CAUTION*8,''%)''))$&'%).Never insert foreign objects such as
coins into the SD card slot. Doing so
may result in a malfunction of the
device.
. Do not apply too much pressure
when inserting the SD card into the
slot. Doing so may result in a mal-
function of the device.
. The SD card may be hot when it is
removed from the device. This does
not indicate a malfunction.
NOTE:
Do not remove the SD card containing map
data. If the SD card containing map data is
accidentally removed, reinsert the SD card
containing map data into the slot and place
the ignition switch in the OFF position.
LIQUID CRYSTAL DISPLAYNCGNJN1402-120906-372A4E1B-44A4-402D-B2E2-BBC1C2EE95EAThe display is a liquid crystal display and should
be handled with care.
WARNING1&*1-1%)$'))%)((($('Never disassemble the display. Some
parts utilize extremely high voltage.
Touching them may result in serious
personal injury.
Characteristics of liquid crystal displayGUID-606BA666-3A03-489B-86FB-CE0129A6D140. If the temperature inside the vehicle is
especially low, the display will stay relatively
dim or the movement of the images may be
slow. These conditions are normal. The
display will function normally when the
interior of the vehicle has warmed up.
. Some pixels in the display are darker or
brighter than others. This condition is an
inherent characteristic of liquid crystal dis-
plays, and it is not a malfunction. .
A remnant of the previous display image may
remain on the screen. This screen burn is
inherent in displays, and it is not a malfunc-
tion.
. The screen may become distorted by strong
magnetic fields.
Maintenance of displayGUID-A416EADC-8AF0-4234-BF0D-ADD3A5F4AF96
CAUTION*8,'%$$%&%)'&$.To clean the display screen, use a dry,
soft cloth. If additional cleaning is
necessary, use a small amount of
neutral detergent with a soft cloth.
. Clean the display with the ignition
switch in the OFF position. If the
display is cleaned while the ignition
switch is placed in the ON position,
unintentional operation may occur.
. To clean the display, never use a
rough cloth, alcohol, benzine, thinner
or any kind of solvent or paper towel
with a chemical cleaning agent. They
will scratch or deteriorate the panel.
. Do not splash any liquid such as
water or car fragrance on the display.
Contact with liquid will cause the
2. Getting started
&RQGLWLRQ
2-5


> (GLW    0RGHO 1&*1-1 @
2. Getting started
system to malfunction.STEERING WHEEL SWITCHESNCGNJN1402-120906-1B7CD1C1-5D48-4964-8816-2649513B59D0
5GH0233X
Type A (if so equipped)
5GH0296X
Type B (if so equipped)
*1<>(TALK):
Push to use the voice recognition system.
Push and hold to end the voice recognition session.
ªGiving voice commandsº (page 7-2)
*2<>/<>,
:
During voice recognition operation, tilt up/
down to highlight different items, and push
to select the highlighted item.
Audio operations are also possible by tilting
the switch up and down.
ªSteering wheel mounted audio con-
trol buttonsº (page 3-11)
*3<>:
Push to display the hands-free phone
operation screen.
When you receive a phone call, push this
button to answer the call.
ª4. Hands-Free Phoneº
*4<>/<>:
The buttons are used mainly for the vehicle
information display operation. Refer to the
vehicle Owner's Manual for details.
During voice recognition operation, <
>
can be used to return to the previous
screen.
*5:
Push to change the audio source to the
available mode.
ªSelecting audio sourceº (page 3-12)
&RQGLWLRQ
2-6


> (GLW    0RGHO 1&*1-1 @
*6<>:
Push + or - to adjust the volume.
INFO:
Steering wheel switches are mainly for the
vehicle information display control and may not
be able to operate the touch screen display
depending on the conditions. Follow the pop-up
guide messages and labels shown on the vehicle
information display.
Some of the information displayed on the vehicle
information display are linked with the touch
screen display.
For other details of the vehicle information
display, refer to the vehicle Owner's Manual.
DISPLAY COMMANDER (if so
equipped)
GUID-EA578DD1-511A-4657-9194-0E1CAE4CD87FWith this system, the same operations as those
for the control panel are possible using the
Display Commander.
5GH0305X
*1


> (GLW    0RGHO 1&*1-1 @
2. Getting started
CAUTION*8,'&%%(&'.Do not force the USB device into the
USB port. Inserting the USB device
tilted or up-side-down into the port
may damage the port. Make sure that
the USB device is connected correctly
into the USB port.
. Do not grab the USB port cover (if so
equipped) when pulling the USB
device out of the port. This could
damage the port and the cover.
. Do not leave the USB cable in a place
where it can be pulled unintention-
ally. Pulling the cable may damage
the port.
The vehicle is equipped with USB ports and an
AUX input jack. When connected, the in-vehicle
audio system can play audio contents from the
compatible device.
Type A (if so equipped):
USB port 1 is located in the media pocket. USB
port 2 is located at the rear of the center console
box. The AUX input jack is located in the media
pocket.
5GH0234X
Media pocket
5GH0265X
Rear of center console box
Type B (if so equipped):
Two USB ports and the AUX input jack are
located in the media pocket.
5GH0297X
Media pocket
*1AUX (Auxiliary) input jack:
Connect an audio player that accepts a 1/8
in (3.5 mm) TRS connector (such as an
MP3 player etc.) to play music.
*2USB port 1, USB port 2:
Connect a compatible device to play media
from an iPod


> (GLW    0RGHO 1&*1-1 @
INFO:
. Refer to your AUX and USB device manu-
facturer's owner information regarding the
proper use and care of the device.
. Even when iPod


> (GLW    0RGHO 1&*1-1 @
2. Getting started
corresponding menu screens.
The following menus are available on the Launch
Bar.. [Audio]
. [Phone]
. [Info]
. [MENU]
. [Map]
. [Navi]
. [Settings] Launch Bar operation with Display Com-
mander (if so equipped):
5GH0345X
Sliding the slide switch backwards will enable
the center dial operation of the Launch Bar. Slide
the switch forward to return to operate Shortcuts
with the center dial.
AudioGUID-649C8501-BB6A-4900-9AEA-0E10ACEA7886Touching [Audio] on the Launch Bar will display
the audio screen. When [Audio] is touched while
the audio screen is displayed, the audio source
menu screen will be displayed.
ªSelecting audio sourceº (page 3-12)
INFO:
Pushing


> (GLW    0RGHO 1&*1-1 @
INFO:
Pushing


> (GLW    0RGHO 1&*1-1 @
2. Getting started
MAIN SCREEN OPERATIONSNCGNJN1402-B2704A91-F2DB-44B4-827A-4CF2E650F379.Displaying previous screen
5GH0266X
*1Touch [] to return to the screen dis-
played previously. .
Horizontal scrolling
5GH0239X
*1Touch [<] to scroll to the previous page.
*2Touch [>] to scroll to the next page.
*3Indicates the position of the currently
displayed page. Page scrolling with Display Comman-
der (if so equipped):
5GH0346X
Slide the slide switch leftward to scroll to the
previous page. Slide the slide switch right-
ward to scroll to the next page.
&RQGLWLRQ
2-12
