2016 MAZDA MODEL 6 Navigation Manual (in English)

©2014 Mazda Motor CorporationNov. 2014 (Print1)
/"7$76&&JOEC



/"7$76&&JOEC











2
1 Warnings and Safety information ................................. 4
2 Getting started ............................................................... 6
2.1 Before using the navigation system .................................................. 6
2.2 Navigation menu ........................................................................\
....... 8
2.3 Buttons and other controls on the screen ...................................... 10
2.3.1 Using keyboards ........................................................................\
.......... 10
2.3.2 Press and Hold ........................................................................\
..............11
2.4 Map screen ........................................................................\
.............. 12
2.4.1 Navigating on the map ........................................................................\
12
2.4.2 Position markers ........................................................................\
......... 132.4.2.1 Selected map location (Cursor) and selected map object ...... 13
2.4.3 Objects on the map ........................................................................\
..... 13 2.4.3.1 Streets and roads .................................................................... 13
2.4.3.2 Turn preview and Next street ................................................. 14
2.4.3.3 Lane information and Signposts ............................................ 16
2.4.3.4 Junction view ........................................................................\
.. 17
2.4.3.5 Highway/Freeway exit services ............................................. 17
2.4.3.6 Elements of the active route ................................................... 19
2.4.4 Manipulating the map ........................................................................\
.. 20
2.4.5 Checking the details of the current position (Where Am I?) .............. 23
3 On-road navigation ...................................................... 24
3.1 Selecting the destination of a route ............................................... 24
3.1.1 Entering an address or a part of the address ........................................ 25 3.1.1.1 Entering an address ................................................................ 25
3.1.1.2 Entering the midpoint of a street as the destination ............... 30
3.1.1.3 Selecting an intersection as the destination ............................ 33
3.1.1.4 Selecting a city center as the destination ............................... 36
3.1.2 Selecting the destination from the POI (point of interest) ................... 39 3.1.2.1 Quick search for a POI (point of interest) ............................... 39
3.1.2.2 Searching for Help nearby ..................................................... 42
3.1.2.3 Searching for a POI (point of interest) by category ................ 45
3.1.2.4 Searching for a POI (point of interest) by name ..................... 49
3.1.3 Searching for a Place using Local Search (Only some countries and regions) ..............................................................\
.................................. 53
3.1.4 Selecting a map location as the destination ........................................ 55
3.1.5 Selecting the destination from your Favorites .................................... 57
Table of contents
/"7$76&&JOEC


 /"7$76&&JOEC











3
3.1.6 Selecting a recent destination from the History ................................. 59
3.1.7 Entering the coordinate of the destination .......................................... 61
3.2 Checking route parameters and accessing route related functions ... 63
3.3 Modifying the route ........................................................................\
. 65
3.3.1 Selecting a new destination when already having a route:
New Route, Waypoint or Final Destination ........................................ 65
3.3.2 Editing the list of destinations (Edit Route) ....................................... 66
3.3.3 Checking route alternatives when planning the route ........................ 67
3.3.4 Changing the road types used in route planning ................................ 69
3.4 Saving a location as a Favorite destination .................................. 71
3.4.1 Editing the details of a Favorite destination ....................................... 71
4 Reference Guide ............................................................ 74
4.1 Concepts ........................................................................\
.................. 74
4.1.1 Smart Zoom ........................................................................\
................ 74
4.1.2 Route calculation and recalculation .................................................... 74
4.1.3 Road safety cameras and other proximity alert points (Only some countries and regions) ........................................................................\
.. 76
4.1.4 Speed limit warning (Only some countries and regions) .................... 77
4.1.5 Traffi c information in route planning (Only some countries and
regions) ..............................................................\
.................................. 77
4.1.5.1 Historical traf fi c ...................................................................... 78
4.2 Settings menu ........................................................................\
.......... 79
4.2.1 Guidance Settings ........................................................................\
........ 80
4.2.2 Warning Settings ........................................................................\
.......... 80
4.2.3 Traffi c Settings ........................................................................\
........... 81
4.2.4 Route Settings ........................................................................\
............. 82
4.2.5 Map Settings ........................................................................\
............... 83
4.2.6 Visual Guidance settings .................................................................... 85
5 Glossary ........................................................................\
. 86
6 End-User Terms ............................................................ 88
/"7$76&&JOEC


 /"7$76&&JOEC











4
1 Warnings and Safety information
The navigation system guides you to your destination using the GPS recei\
ver. The
navigation system does not transmit your GPS position and you cannot be \
tracked.
It is important that you look at the display only when it is safe to do \
so.
If you are the driver of the vehicle, we recommend that you operate the
navigation system before you start your journey. Plan the route before
your departure and stop if you need to change the route.
Drive the vehicle according to the road signs and the road shape. If you\
deviate from
the recommended route, the navigation system changes the instructions ac\
cordingly.
For more information, consult the End-User Terms (page 88).
/"7$76&&JOEC


 /"7$76&&JOEC











5
1
2
3
4
5
6
Memo
/"7$76&&JOEC



/"7$76&&JOEC











6
2 Getting started
2.1 Before using the navigation system
To use the navigation system, the SD card containing the map information \
needs to
be inserted in the SD card slot.
Type AType D
Type C Type B
SD card slot
SD card slot SD card slot
SD card slot
/"7$76&&JOEC


 /"7$76&&JOEC











7
1
2
3
4
5
6
When inserting the SD card, never move the slider on the side of the SD \
card to the
LOCK position. If the slider is set to LOCK, the SD card cannot be read \
and the
navigation system will not operate.
This SD card is valid for use in only one vehicle. Never use it in anoth\
er vehicle. If
the SD card is used fi rst in one vehicle and then in another, the navigation system
for either one of the vehicles may become inoperable.
/"7$76&&JOEC


 /"7$76&&JOEC











8
2.2 Navigation menu
You can reach all parts of the navigation system from the Navigation menu\
.
Select
and open the navigation menu.
You have the following options:
•
/ : Open/close
Opens and closes the UMP (menu bar).
The UMP (menu bar) is displayed on the lower part of the screen.
•
: Adds a destination.
Select your destination by entering an address or selecting a POI (poin\
t of
interest), a location on the map or one of your Favorite destinations. \
You can
also look up your recent destinations from the Smart History by entering\
the
coordinates. If an Internet connection is available, Local Search can be\
of further
help to fi nd your destination.
