65
1
2
3
4
5
6
3.3 Modifying the route
When navigation is already started, there are several ways to modify the\
active
route. The following sections show some of those options.
3.3.1 Selecting a new destination when already having a route: New Route, Waypoint or Final Destination
If you already have a recommended route and you select a new destination\
as
described in the above sections, the application will ask you whether to\
start a new
route, add a new waypoint (intermediate destination) to the route or a\
ppend the
newly selected destination at the end of the current route.
• Select to plan a new route to the newly selected location. The
previous destination and waypoint(s) are deleted.
• Select
to add the newly selected location as an intermediate destination
to your route. The other destinations of the route remain intact. Note: the new
waypoint is placed among destinations to keep the route optimal. To decide where
a waypoint to appear, use the Edit Route feature.
• Select
to append the newly selected destination at the end
of the route. The other destinations of the route remain intact. The previous fi nal
destination is now the last waypoint.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 66 of 92
66
3.3.2 Editing the list of destinations (Edit Route)
You can edit the route by modifying the list of destinations.
1. Select
after selecting on the MAP screen.
2. Select
.
3. Edit the destination or waypoint.
: Add the new destination or waypoint.
: Start the route plan in consideration of the selected destination or waypoint.
4. Select the destination or waypoint to display the menu.
: Close the menu.
: Delete the selected destination or waypoint from the list.
: Move the selected destination or waypoint forward one by one.
: Move the selected destination or waypoint rearward one by one.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 67 of 92
67
1
2
3
4
5
6
3.3.3 Checking route alternatives when planning the route
You can select from different route alternatives or change the route planning method
after you have selected a new destination.1. Select
after selecting on the MAP screen.
2. Select .
3. The four route alternatives are displayed next to the selected route pla\
nning method. Select one to view it on the map.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 68 of 92
68
4. Details of a route can be checked by selecting
.
5. Select one of the route alternatives or select to return to the previous
screen.
The navigation system recalculates the route. The orange line now shows the
new recommended route.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 69 of 92
69
1
2
3
4
5
6
3.3.4 Changing the road types used in route planning
To recalculate the active route with different road type preferences, do as follows.
These changes can also be made in Settings (page 82). 1. Select
after selecting on the MAP screen.
2. Select
.
3. Select any of the listed road types to modify the route. If needed, scro\
ll the list for all road types. You have the following options (their order depends on
the selected vehicle type):
•
- You might need to avoid highways/freeways if you
are towing another vehicle.
•
- Charge roads are pay roads where you
can purchase a pass or vignette to use the road for a longer period of
time. They can be enabled or disabled separately from toll roads.
•
- The navigation system includes toll
roads (pay roads where there is a per-use charge) in the routes by
default. If you disable toll roads, the navigation system plans the best\
toll-free route.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 70 of 92
70
•
- The navigation system includes ferries in a
planned route by default. However, a map does not necessarily contain
information about the accessibility of temporary ferries. You might also
need to pay a fare on ferries.
•
- Setting in which routes with carpool lanes
can be created or not created.
•
- A border crossing may be a shorter route
depending on the route. For this function, you can select whether or not\
to cross a border when planning the route.
•
- The navigation system excludes
unpaved roads by default: unpaved roads can be in a bad condition and
usually you cannot reach the speed limit on them.
4. The route has already been recalculated. Select
to return to the Map
screen.
Some functions are not available depending on some countries and regions\
.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 71 of 92
71
1
2
3
4
5
6
3.4 Saving a location as a Favorite destination
You can add any location to Favorites, the list of frequently used destin\
ations.
Planning a route to one of the Favorite destinations is described on pag\
e 57. 1. Select a destination as described before. It can be an address, a Place,\
any location on the map, a previously used destination from History, etc.
2. A searched destination can be registered to Favorites by selecting
on the veri fi cation screen of the destination search
results.
3.4.1 Editing the details of a Favorite destination
You can select a location that you have already saved as a Favorite and e\
dit its
details. Adding a location to the list of Favorite destinations is described on p\
age 71. 1. Press the Favorites button on the commander switch.
2. Select the Navigation tab.
3. The list of Favorite destinations is displayed.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
Page 72 of 92
72
The following functions can be used by selecting Add/Edit Navigation
Favorite.
Add Current Location: Set the current location to Favorites.
Add Current Destination
: Register the current destination to Favorites.
Add from Contact : Register an address registered to the contacts list.
Move: Switch the Favorites order.
Delete: Delete the registered Favorites.
Your home address can be registered/changed by selecting Home.
The following functions can be used by selecting the registered Favorite\
s.
Replace with Current Location: Set the current location to Favorites.
Replace with Current Destination: Register the current destination to Favorites.
Replace with Address from Contacts : Register an address registered to the
contacts list.
Move: Switch the Favorites order.
Rename: Edit the registered Favorites name.
Delete: Delete the selected Favorites.
/ " 7 $ 7 6 & & J O E C / " 7 $ 7 6 & & J O E C
