2016 MAZDA MODEL 6 Navigation Manual (in English)

17
1
2
3
4
5
6
2.4.3.4 Junction view
If you are approaching a highway/freeway exit or a complex intersection \
and the
needed information exists, the map is replaced with a 3D view of the jun\
ction. The
optimum driving lane is indicated by an arrow, and road signs are displayed as
additional information at the top of the screen.
2.4.3.5 Highway/Freeway exit services
You may need a gasoline station or a restaurant during your journey. This feature
displays a new button on the map when you are driving on highways/freewa\
ys.
/"7$76&&JOEC


 /"7$76&&JOEC











18
Select this Open button to open a panel with the details of the next few\
exits or
service stations.
Applicable only when the setting is “Only when menu is open”.
Select any of them to display the exit area on the map. You can now easily add this
exit as a waypoint to your route if needed.
There are two types of settings for displaying the next expressway exit;\
one which
constantly displays the next expressway exit while traveling on an expre\
ssway, or
the other which displays the next expressway exit only when the menu pan\
el is
open.
You can change the settings in Visual Guidance settings (page 85).
/"7$76&&JOEC


 /"7$76&&JOEC












19
1
2
3
4
5
6
2.4.3.6 Elements of the active route
The navigation system shows the route in the following way:
Symbol NameDescription
Current car position
markerIf there is a road close by, a blue-colored
arrow symbol moves to the road which is the
closest.
The red mark present around a blue-colored
arrow symbol indicates the correct GPS
information. It may be indicated away from
the road because there is no existing road
information.
Waypoint
(intermediate
destination) An intermediate destination of the route
before reaching the
fi nal destination.
Destination (end
point) The fi
nal destination of the route.
Route color The route always stands out with its color on the map, both in daytime and in nighttime
mode.
Streets and roads
that are excluded
from the navigation You can choose whether you want to use or
avoid certain road types (page 82). However,
when the navigation system cannot avoid
such roads, the route will include them and
it will show them in a color that is different
from the route color.
Streets and roads
that are affected by
traffi c events Road segments may be affected by traf
fi c
events received. These streets and roads are
displayed in an alternate color, and small
symbols displayed along the route show the
type of traf fi c event.
Some functions are not available depending on some countries and regions\
.
/"7$76&&JOEC


 /"7$76&&JOEC











20
2.4.4 Manipulating the map
By touching and dragging any part of the map screen, it can be moved to \
a location
close to the currently displayed map.
In addition, the map operation button is displayed, and by touching each\
of the
buttons, you can zoom in and out of maps, change the map perspective and\
select a
destination.
Action Button(s)
Description
Map movement
using touch and
drag No buttons You can move the map in any direction: select
and hold the map, and move your fi nger
towards the direction you want to move the
map.
Zooming in and
out
, Changes how much of the map is displayed on
the screen.
The navigation system uses high-quality
vector maps that let you examine the map at
various zoom levels, always with optimized
content.
Map scaling has a limit in 3D map view mode.
If you zoom out further, the map switches to
2D view mode.
Select the button once to modify the view in
large steps, or select and hold the button to
modify it continuously and smoothly.
/"7$76&&JOEC


 /"7$76&&JOEC












21
1
2
3
4
5
6
Action Button(s)Description
Tilting up and
down
, Changes the vertical view angle of the map in
3D mode.
Select the button once to modify the view in
large steps, or select and hold the button to
modify it continuously and smoothly.
Rotating left
and right
, Changes the horizontal view angle of the map.
Select the button once to modify the view in
large steps, or select and hold the button to
modify it continuously and smoothly.
Compass
The direction of the compass shows North.
Select the button to switch to North-up view,
and then select again to rotate the map in the
previous direction.
Open/close
, The UMP (menu bar) is displayed on the
lower part of the screen.
Hides the displayed UMP if the UMP has been
displayed.
Select
destination
Select this button to select the Cursor as a
new destination. The route is automatically
calculated.
Return to
normal
navigation
Select this button to move the map back to
follow the current GPS position. Automatic
map rotation is also re-enabled.
The map manipulation buttons disappear and
navigation continues.
/"7$76&&JOEC


 /"7$76&&JOEC












22
Action Button(s)Description
2D or 3D view
, ,
When this button is selected, the map view
mode can be changed.
•
: The map is displayed so that north is up
regardless of the direction of travel.
•
: The map is rotated so that the direction
of travel is displayed in the upward
direction.
•
: Displays things such as actual
construction sites three dimensionally on the
map.
Zoom-in/zoom-
out mode
You can zoom-in/zoom-out of maps.
Rotate mode
Rotates maps.
Perspective
angle mode
You can change the angle of perspective on a
map.
/"7$76&&JOEC


 /"7$76&&JOEC












23
1
2
3
4
5
6
2.4.5 Checking the details of the current position (Where Am I?)
This screen contains information about the current position (or about t\
he last known
position if GPS reception is not available).
You can access this screen from the map in one of the following ways: 1. Select
after selecting on the MAP screen.
2. Select the Where Am I? screen.
/"7$76&&JOEC


 /"7$76&&JOEC











24
3 On-road navigation
You can set up your route in different ways:
If you need a route for immediate navigation, you can select the destina\
tion and start
navigating to it right away (normal navigation).
You can plan routes with multiple destinations. Select the fi rst destination. Then
select a second destination and add it to your route to create a multi-p\
oint route. You
can add as many destinations to your route as you like.
3.1 Selecting the destination of a route
The navigation system offers you several ways of choosing your destination:
• Enter a full address or a part of an address (page 25).
• Select a POI (point of interest) from a database as your destination (\
page 39).
• Searches the destination from the map (page 55).
• Use a previously saved Favorite destination (page 57).
• Select a location from the History of previously used destinations (pag\
e 59).
• Enter the coordinate of the destination (page 61).
There are other convenient functions.
/"7$76&&JOEC
