2016 MAZDA MODEL 6 display

4
1 Warnings and Safety information
The navigation system guides you to your destination using the GPS recei\
ver. The
navigation system does not transmit your GPS position and you cannot be \
tracked.
It is important that you look at the display only when it is safe to do \
so.
If you are the driver of the vehicle, we recommend that you operate the
navigation system before you start your journey. Plan the route before
your departure and stop if you need to change the route.
Drive the vehicle according to the road signs and the road shape. If you\
deviate from
the recommended route, the navigation system changes the instructions ac\
cordingly.
For more information, consult the End-User Terms (page 88).
/"7$76&&JOEC


 /"7$76&&JOEC











8
2.2 Navigation menu
You can reach all parts of the navigation system from the Navigation menu\
.
Select
and open the navigation menu.
You have the following options:
•
/ : Open/close
Opens and closes the UMP (menu bar).
The UMP (menu bar) is displayed on the lower part of the screen.
•
: Adds a destination.
Select your destination by entering an address or selecting a POI (poin\
t of
interest), a location on the map or one of your Favorite destinations. \
You can
also look up your recent destinations from the Smart History by entering\
the
coordinates. If an Internet connection is available, Local Search can be\
of further
help to fi nd your destination.
/"7$76&&JOEC


 /"7$76&&JOEC











9
1
2
3
4
5
6
• : Displays the screen where traffi c information and the GPS reception
conditions can be set and veri fi ed.
•
: Cancels waypoint/route
•
: Finds Places nearby
You can search for points of interest (POI) near the vehicle position.
•
: Displays the route parameters and the route in its full length on the \
map. You
can also perform route-related actions such as editing or canceling your\
route,
picking route alternatives, avoiding parts of the route, simulating navi\
gation or
adding the destination to your Favorites.
•
/ / : Changes View mode
The map view mode can be changed (2D north up/2D heading up/3D).
•
: Switches to the Settings screen where you change navigation settings.
Some functions are not available depending on some countries and regions\
.
/"7$76&&JOEC


 /"7$76&&JOEC











12
2.4 Map screen
2.4.1 Navigating on the map
The data fi elds are different when you are navigating an active route and when you
have no speci fi ed destination (the burgundy line is not displayed).
Field Description

Shows the speed limit of the current road if the map
contains it.

Shows the distance you need to travel on the route before
reaching your fi nal destination.
Shows the estimated arrival time at the fi nal destination of
the route.
If the navigation system is capable of receiving live traf fi c
information, the calculation takes into account traf fi c
delays affecting your route.
This estimation can be inaccurate at times.
Some functions are not available depending on some countries and regions\
.
/"7$76&&JOEC


 /"7$76&&JOEC











13
1
2
3
4
5
6
2.4.2 Position markers
2.4.2.1 Selected map location (Cursor) and selected map object
You can mark a map location in the following ways:
• Select the map during route guidance.
• Select the map when asked so that the destination can be confi rmed after the
search is completed.
• Select the destination from the map. (page 55)
When a map location is selected, the Cursor appears at the selected poin\
t on the
map. A symbol
with a combined crosshair and red circle is displayed for easy
visibility of any map scale size.
The location of the Cursor can be used as the destination of the route.
You can search for a POI (point of interest), or you can save it as one\
of your
Favorites destinations.
You can also select some of the objects on the map. If you select the map\
at the icon
of a POI (point of interest) or a traf fi c event, the object will be selected. You can
then get information about this object or use it as a route point.
Some functions are not available depending on some countries and regions\
.
2.4.3 Objects on the map
2.4.3.1 Streets and roads
The navigation system shows the roads in different widths and colors so that they
can be easily identi fi ed. A highway/freeway will be thicker and a different color than
a small street.
/"7$76&&JOEC


 /"7$76&&JOEC











14
2.4.3.2 Turn preview and Next street
When navigating a route, the top section of the Map screen shows informa\
tion about
the next maneuver, street or city.
There is an area at the top left part of screen which indicates the next\
operation.
Displays both the event type (such as turning, detouring, exiting expre\
ssways) and
the distance from the current position.
When the next event approaches, the second event is displayed using a sm\
all icon. If
there is no second event, only the next event is displayed.
Most of these icons are very intuitive. The same symbols are used in both
fi elds:
Icon Description
Turn left.
Turn right.
Turn back.
Bear right.
Turn sharp left.
Keep left.
Continue straight in the intersection.
/"7$76&&JOEC


 /"7$76&&JOEC











16
2.4.3.3 Lane information and Signposts
When navigating on multilane roads, it is important to take the appropri\
ate lane
in order to follow the recommended route. If lane information is availab\
le in
the map data, the navigation system displays the lanes and their directi\
ons using
small arrows at the bottom of the map. Highlighted arrows represent the \
lanes and
direction you need to take.
Lane guidance is provided constantly if there is map information. Signpo\
sts are
displayed at the top of the map. The color and style of the signposts are similar
to the real ones you see above road or by the roadside. They show the available
destinations and the number of the road the lane leads to.
When navigating a route, only the signpost that points to the lane(s) \
to be taken is
displayed in bright colors; all others are darker. All signposts and lane guidance
arrows are displayed in vivid colors while driving (when there is no re\
commended
route).
If you want to hide the currently displayed signposts, touch anywhere an\
d the
normal Map screen returns until new signpost information is received.

/"7$76&&JOEC


 /"7$76&&JOEC












17
1
2
3
4
5
6
2.4.3.4 Junction view
If you are approaching a highway/freeway exit or a complex intersection \
and the
needed information exists, the map is replaced with a 3D view of the jun\
ction. The
optimum driving lane is indicated by an arrow, and road signs are displayed as
additional information at the top of the screen.
2.4.3.5 Highway/Freeway exit services
You may need a gasoline station or a restaurant during your journey. This feature
displays a new button on the map when you are driving on highways/freewa\
ys.
