2016 Lexus GS350 Owner's Manual

GS350_200t_GS F_OM_OM30E86U_(U)
3455-2. Using the air conditioning system and defogger
5
Interior features
■Seat ventilators (without seat heaters) (if equipped)
Seat ventilator switches
Level indicator lights
The seat ventilator fan speed level is
displayed.
●Modes and indicators
The mode changes each time the switch is pressed as follows:
■The seat heaters/seat ventilators can be used when
The engine switch is in IGNITION ON mode.
■Seat heater control (vehicles without automatic mode)
The seat heater automatically changes operatio ns. If the engine switch is turned off while
the seat heater is operating, the starting operation of the heater differs depending on the
amount of time that elapses before it is turned back on.
1
2
ModeLevel indicator lights
OffOff
Hi3
Mid2
Lo1
Current operation
Starting operation mode and amount of time
elapsed until engine swit ch in IGNITION ON mode
0 to 15 minutesOver 15 minutes
HiHiHi
MidMidHi
LoLoHi

346
GS350_200t_GS F_OM_OM30E86U_(U)5-2. Using the air conditio
ning system and defogger
■Automatic operation of the seat heater during Eco drive mode
If the driving mode select swit ch is switched to Eco drive mo de in cold temperatures, the
seat heater may be automatically oper ated to assist heating performance.
■Automatic operation during S-FLOW mode
The front seat heater and ventilator or the rear seat heater may automatically turn off
when S-FLOW mode is turned on during automatic mode. ( P. 3 2 9 )
■Button lock function (vehicle s with rear control panel)
To prevent inadvertent operation, some buttons on the rear armrest can be locked.
(  P. 3 4 1 )
■When the switch is disabled (vehicles with rear control panel)
When the rear control panel switch cannot be operated even though the button lock
function is released, check whether the sw itch is disabled due to selecting on
Remote Touch screen. ( P. 335)
■Rear control panel illumination off functi on (vehicles with rear control panel)
Control panel illumination on the re ar armrest can be turned off. (P. 3 4 1 )
■Customization
The automatic mode settings for the front seat heaters and ventilators or the rear seat
heaters can be changed. (Customizable features: P. 5 6 8 )

347
GS350_200t_GS F_OM_OM30E86U_(U)5-3. Using the interior lights
5
Interior features
Interior lights list
When the instrument panel light control switch is turned to minimum and the tail lights
are on, the inside door handle lights, the
ornament lights and the footwell lights will
turn off. ( P. 8 9 )
Outer foot lights
Shift lever light
Front interior light ( P. 3 4 8 )
Front personal lights ( P. 3 4 8 )
Inside door handle lights Rear personal lights (
P. 3 4 8 )
Rear interior light
Ornament lights
Door courtesy lights
Power window switch lights
Footwell lights1
2
3
4
5
6
7
8
9
10

348
GS350_200t_GS F_OM_OM30E86U_(U)5-3. Using the
interior lights
Tu r n s t h e l i g h t s o n /o f f
The rear interior light is also turned on/
off.
Turns the door position on/off
■Front
Tu r n s t h e l i g h t o n /o f f
■Rear
Tu r n s t h e l i g h t o n /o f f
Interior lights
1
2
Personal lights

GS350_200t_GS F_OM_OM30E86U_(U)
3495-3. Using the interior lights
5
Interior features
●Illuminated entry system: The lights automatically turn on/off according to engine
switch mode, the presence of the electronic key, whether the doors are locked/
unlocked, and whether the doors are opened/closed.
●If the interior lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes.
●Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 5 6 8 )
NOTICE
To prevent battery discharge, do not leave the lights on longer than necessary when the
engine is off.

350
GS350_200t_GS F_OM_OM30E86U_(U)5-4. Using the storage features
List of storage features
Cup holders (
P. 3 5 2 )
Glove box ( P. 3 5 1 )
Auxiliary boxes (if equipped) (P. 3 5 3 )
Ashtrays (if equipped) ( P. 3 5 9 ) Auxiliary boxes (
P. 3 5 3 )
Console box ( P. 3 5 1 )
WA R N I N G
●Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with other
stored items.
• Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
●When driving or when the storage compartmen ts are not in use, keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside.
1
2
3
4
5

GS350_200t_GS F_OM_OM30E86U_(U)
3515-4. Using the storage features
5
Interior features
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
●The glove box light turns on when the tail lights are on.
●The trunk opener main switch is located in the glove box. (P. 1 4 5 )
●The insert inside the glove box can be removed.
●An SRS knee airbag for the front passenger’s seat is built into the glove box door.
( P. 4 1 )
Using with half-open
Grip the knob to release the lock,
and slide the armrest as far back.
Using with fully open
Grip the knob to release the lock,
and lift the armrest to open.
●The console box light turns on when the tail lights are on.
Glove box
1
2
3
Console box
1
2
●The tray slides forward/backward and can be
removed.

352
GS350_200t_GS F_OM_OM30E86U_(U)5-4. Using the storage features
■Front
To open, press down and release the
cup holder lid.
■Rear
To open, pull down the armrest and
press in and release the rear cup
holder on the armrest.
●Rear cup holder: When stowing the cup holder, stow the cup holder with the armrest
down. The cup holder cannot be stowed if the armrest is not down.
WA R N I N G
When using the console box with half-open,
do not apply too much load on the arm-
rest. Doing so may damage the armrest and may cause you to injure yourself.
Cup holders
●Front cup holder: The cup holder insert may
be removed for cleaning.
