2016 Citroen DS5 Audio and telematics

1
18
19
1
21
20
22
23
79 Audio and Telematics


Level 1

Level 2

Level 3

Comments


Settings



Secondary page



Setting
the time- date

Date
Date
Enter the date and select the date format.
Date format:

Time
Time Set the time.
Time Zone Define the time zone.
Time format: Select the time format: 12h / 24h.
Synchronisation with
GPS (UTC): Activate or deactivate synchronisation with GPS.

Confirm
Save the settings.

Settings



Secondary page



Setting of the
profiles

Profile 1

Enter settings for the profiles.
Profile 2


Profile 3


Common profile


Confirm
Save the settings.

4
2
5
6
7
8
81 Audio and Telematics


Select a " Profile
" (1 or 2 or 3) to
associate the " Audio settings
" with
it.

Select " Audio settings
".

Select " Ambience
".

Or

" Distribution
".

Or

" Sound
".

Or

" Voice
".

Or

" Ringtone
".
The location for the photograph is
square; the system deforms the original
photograph if in another format.
Initialisation of the profile selected
activates the English language by default.

Press on " Confirm
" to save the
settings.

Press on " Confirm
" to accept the
transfer of the photograph.

Press on " Confirm
" again to save the
settings.
Press on this button to add a
photograph to the profile.

Insert a USB memory stick containing
the photograph in the USB port.
Select the photograph.
Press on this button to initialise the
profile selected.

1
18
19
3
83 Audio and Telematics


Press on Settings
to display the
primary page.

Press on the " OPTIONS
" button to
go to the secondary page.
Select " Date
".

Select " Time
".
Select " Setting the time- date
".

Every time the color scheme is
changed, the system restarts,
temporarily displaying a black screen.

Adjustment of the time and date is only
available if synchronisation with GPS is
deactivated.
The change between winter and
summer time is done by changing the
time zone.

The system does not automatically
manage the change between winter
and summer time (depending on
country).


As a safety measure, the procedure
for changing the color scheme is only
possible with the vehicle stationary.

Press on Settings
to display the
primary page.

Select " Color schemes
".

Select a color scheme in the list then
" Confirm
".


Color schemes









Setting the time


Press on this button to define the
date.

Press on this button to adjust the
time using the virtual keypad.
Press on " Confirm
".
Press on " Confirm
".

Press on " Confirm
".

Press on this button to define the
time zone.
Select the display format of the date.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

85 Audio and Telematics



QUESTION



ANSWER



SOLUTION


Certain traffic jams along
the route are not indicated
in real time. On starting, it is several minutes before the system begins to
receive the traffic information. Wait until the traffic information is being received
correctly (display of the traffic information icons
on the map).
In certain countries, only major routes (motor ways...) are listed for
the traffic information. This phenomenon is normal. The system is
dependent on the traffic information available.
The altitude is not
displayed. On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly. Wait until the system has started up completely
so that there is GPS coverage by at least
4 satellites.
Depending on the geographical environment (tunnel...) or the
weather, the conditions of reception of the GPS signal may vary. This phenomenon is normal. The system
is dependent on the GPS signal reception
conditions.

87 Audio and Telematics


Media



QUESTION



ANSWER



SOLUTION


Playback of my USB
memory stick starts only
after a very long wait
(around 2 to 3 minutes). Some files supplied with the memory stick may greatly slow down
access to reading the memory stick (multiplication by 10 of the
catalogue time). Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.
The CD is ejected
automatically or is not
played by the player. The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play. Check that the CD is inserted in the player the
right way up.
Check the condition of the CD: the CD cannot be
played if it is too badly damaged.
Check the content in the case of a recorded CD:
refer to the advice in the "AUDIO" section.
The audio system's CD player does not play
DVDs.
Some recorded CDs will not be played by the
audio system because they are not of adequate
quality.
The CD has been recorded in a format that is not compatible with the player (udf,...).

The CD is protected by an anti-pirating protection system which is
not recognised by the audio system.
There is a long waiting
period following the insertion
of a CD or connection of a
USB memory stick. When a new medium is inserted, the system reads a certain
amount of data (directory, title, artist, etc.). This may take from a few
seconds to a few minutes. This phenomenon is normal.
The CD player sound is
poor. The CD used is scratched or of poor quality. Insert good quality CDs and store them in
suitable conditions.
The audio equipment settings (bass, treble, ambiences) are
unsuitable. Set the treble or bass level to 0, without selecting
an ambience.

89 Audio and Telematics



QUESTION



ANSWER



SOLUTION


I cannot connect my
Bluetooth telephone. The telephone's Bluetooth function may be switched off or the
telephone may not be visible. Check that your telephone's Bluetooth function is
switched on.
Check in the telephone settings that it is "visible
to all".
The Bluetooth telephone is not compatible with the system. You can check the compatibility of your
telephone at the brand's website (services).
The volume of the
telephone connected
in Bluetooth mode is
inaudible. The volume depends both on the system and on the telephone. Increase the volume of the audio system, to
maximum if required, and increase the volume of
the telephone if necessary.
The ambient noise level has an influence on the quality of
telephone communication. Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, ...).
Some contacts are
duplicated in the list. The options for synchronizing contacts are synchronizing the
contacts on the SIM card, the contacts on the telephone, or both.
When both synchronizations are selected, some contacts may be
duplicated. Select "Display SIM card contacts" or "Display
telephone contacts".
Contacts are not shown in
alphabetical order. Some telephones offer display options. Depending on the settings
chosen, contacts can be transferred in a specific order. Modify the display setting in the telephone
directory.
The system does not
receive SMS text messages. The Bluetooth mode does not permit sending SMS text messages
to the system.

Te l e p h o n e

91 Audio and Telematics



QUESTION



ANSWER



SOLUTION


There is a difference in
sound quality between the
different audio sources. For optimum sound quality, the audio settings for Loudness,
Ambience, Treble, Bass, Volume can be adapted to the different
sound sources, which may result in audible differences when
changing source. Check that the audio settings for (Loudness,
Ambience, Treble, Bass, Volume) are adapted
to the sources listened to. Adjust Balance,
Treble, Bassto the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.
With the engine off, the
system switches off after a
few minutes of use. When the engine is switched off, the system's operating time
depends on the state of charge of the battery.
The switch-off is normal: the system switches to economy mode
and switches off to prevent discharging of the vehicle's battery. Start the vehicle's engine to increase the battery
charge.
