2015 VOLKSWAGEN JETTA HYBRID Owners Manual

If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

HomeLink® Universal Transmitter

WARNING
Improper use of the HomeLink® Universal Transmitter can cause serious or even fatal per-sonal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink® Universal Transmitter, you may be operating a garage door or estate gate. Always make sure that people and objects are out of the way to help prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and serious injury.
x Never use the HomeLink® Universal Transmitter with any garage door opener that does not have the safety stop-and-reverse feature, as required by federal safety standards. This includes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using a garage door opener without these features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer when using the remote-controlled garage door opener or electrical drive.
Programming the HomeLink® Universal Transmitter

Fig. 33 In the driver side sun visor: The remote control and buttons for the HomeLink Universal Transmitter.

Fig. 34 To program: Simultaneously press the buttons for the HomeLink Universal Transmitter and the remote control.

Please carry out each step only in the order specified:
3. Using both hands, simultaneously press and hold both the
HomeLink button you want to program ( 1 , 2 , or 3 ) and the hand-
held transmitter button, as shown ⇒ fig. 34. Do not release the
buttons until the HomeLink indicator light flashes slowly and
then rapidly. When the indicator light flashes rapidly, release both
buttons. The rapid flashing indicates successful programming.
4.
Press and hold the programmed HomeLink button and watch the
indicator light.
If the indicator light comes on and does not flash, programming is
complete and your garage door opener or other device should acti-
vate when the HomeLink button is pressed and released.
If the indicator light blinks rapidly for 2 seconds and then stays on,
proceed with the following programming instructions for a rolling
code device. A second person may make the following steps
quicker and easier. Please use a ladder or other device. Do not
stand on your vehicle to perform the next steps ⇒  in Operating
the HomeLink® Universal Transmitter.
5.
At the garage door opener receiver (overhead unit) in the garage,
locate the “learn” or “training” button. The name and color of the
button may vary by manufacturer. This button is usually located
near the hanging antenna wire attachment point on the unit. If you
cannot locate the “training” button, refer to the garage door open-
er’s user manual.
6. Press and release the “training” button.
Once the button is pressed, you have 30 seconds to initiate
the next step.
7. Return to the vehicle. Firmly press and hold the programmed
HomeLink button for 2 seconds and release.
8. Repeat the “press/hold/release” sequence up to 3 times to com-
plete the programming process for that button.

Repeat the steps to program the other buttons for the HomeLink® Universal Transmitter on the sun visor keypad to control other devices.

Deleting programming for all buttons
Be sure to delete programming on all buttons on the sun visor keypad before selling the vehicle or turning it over to people you do not know.
x Complete the programming preparation steps described above.
x Press and hold buttons 1 and 3 at the same time, for about 20 seconds.
x When the indicator light above button 2 begins to flash, immediately release buttons 1 and 3. This step deletes all old settings.
After programming
Test the garage door opener
Operating the HomeLink® Universal Transmitter

WARNING
Improper use of the HomeLink® Universal Transmitter can cause serious or even fatal per-sonal injury.
x Garage doors operate with enough force to cause serious personal injury.
x Never let anyone get in the way of a garage door when it is opening or closing.
x When programming the HomeLink® Universal Transmitter, you may be operating a garage door or estate gate. Always make sure that people and objects are out of the way to help prevent serious personal injury or property damage.
x When operating the “training” button on a garage door opener with a rolling code, you will need to stand on a ladder or step-stool. Always take extra precautions to prevent falls and serious injury.
x Never use the HomeLink® Universal Transmitter with any garage door opener that does not have the safety stop-and-reverse feature, as required by federal safety standards. This includes any garage door opener model manufactured before April 1, 1982.
x A garage door opener that cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using a garage door opener without these features increases the risk of serious injury or death.
x Follow the installation manual and the included safety information from the manufacturer when using the remote-controlled garage door opener or electrical drive.
NOTICE
The wrong batteries can damage the hand-held remote control. Replace a dead battery with one that has the same voltage, size, and specifications.
Please dispose of old batteries properly and in an environmentally responsible manner. Always keep them out of the reach of children.
Certain batteries used in hand-held remote controls are classified as Perchlorate Material. Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal requirements regarding proper disposal. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that you have them perform this service for you.

Adjusting the seating position
