2015 TOYOTA TUNDRA Owners Manual

3696-3. Using the storage features
6
Interior features
Ty p e A
Pull the strap
Ty p e B
Pull the lever up and fold down
the seatback
Push the knob and lift the lid
Auxiliary boxes (front bench type seat)
1
2

3706-3. Using the storage features
Ty p e C
Pull the lever up and fold down
the seatback
Push the knob and lift the lid
1
2

3716-3. Using the storage features
6
Interior features
■Using the storage box
Pull the lever up and raise the
rear seat cushion
Open the lidTurn the knob in the “OPEN”
direction
Lift the lid
■Remove the storage box
Pull the lever up and raise the
rear seat cushion
Open the lidTurn the knob in the “OPEN”
direction
Lift the lid
Storage box (if equipped)
1
2
1
2
1
2
1
2

3726-3. Using the storage features
Remove the storage box
Remove the lids
Turn the knobs counterclock-
wise
Remove the storage box3
1
2
3
CAUTION
■To prevent damage to the storage box
Do not put heavy loads on the lids.

3736-3. Using the storage features
6
Interior features
Luggage compartment features
Deck hooks are provided for
securing loose items.
Deck hooks

3746-4. Other interior features
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover
The light turns on when the cover
is opened.
Sun visors
1
2
3
Vanity mirrors (if equipped)
NOTICE
Do not leave the vanity lights on for extended periods while the engine is
stopped.

3756-4. Other interior features
6
Interior features
The clock is displayed on the
screen.
■Setting the clock
Vehicles with Entune Audio (Multimedia system types: P. 250)
 P. 2 5 8
Vehicles with Entune Audio Pl us or Entune Premium Audio
(Multimedia system types: P. 250)
Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
■ The clock is displayed when
The engine switch is in the “ACC” or “ON” position.
■ When disconnecting and reco nnecting battery terminals
The clock data will be reset.
Clock

3766-4. Other interior features
■The outside temperature is displayed when
The engine switch is in the “ON” position.
■ Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change:
●When the vehicle is stopped, or moving at low speeds (less than 12 mph
[20 km/h])
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When “– –” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
■ Changing display units
The unit of measurement can be changed using the multi-information display
customization. ( P. 92)
Outside temperature display
The temperature display shows
temperature within the range of
-40°F (-40°C) to 122°F (50°C).
