2015 TOYOTA AVALON HYBRID Owners Manual

1052. Instrument cluster
2
Instrument cluster
AVALON_HV_U (OM41457U)■
Audio system
Press “APPS”. ( P. 102)
Select “Eco”.
If “Energy Monitor” screen is displayed, touch “Fuel Consumptio\
n”.
If “Past Record” screen is displayed, touch “Trip Information”.
Fuel consumption in the past
15 minutes
Displays the average vehicle
speed since the hybrid sys-
tem was started.
Displays the elapsed time
since the hybrid system was
started.
Cruising range
Regenerated energy in the
past 15 minutes
One symbol indicates 50 Wh.
Up to 5 symbols are shown.
The image is example only, and may va ry slightly from actual condi-
tions.
Trip Information
1
2
1
2
3
4
5

1062. Instrument cluster
AVALON_HV_U (OM41457U)■
Audio system
Press “APPS”. ( P. 102)
Select “Eco”.
If “Energy Monitor” screen is displayed, touch “Fuel Consumptio\
n”.
If “Trip Information” screen is displayed, touch “Past Record”.
Best past fuel consumption
Update
The average fuel consumption
and graph are updated, and a
new average fuel consumption
record begins.
Average fuel consumption
Displays a maximum of five past
record of the average fuel con-
sumption.
Previous fuel consumption
record
The image is example only, and may va ry slightly from actual condi-
tions.
■ Resetting the consumption data
Selecting “Clear” on the “Trip Information” screen will reset the fuel consump-
tion and the regenerated energy for the past 15 minutes. Selecting “Clear” on
the “Past Record” screen will reset the past records and best past fuel con-
sumption. Selecting “Yes” on the following screen will confirm resetting of all
the data.
■ Customization
The touch button sensitivity can be changed.
(Customizable features P. 469)
Past record screen
1
2
1
2
3
4

107
Operation of
each component
3
AVALON_HV_U (OM41457U) 3-1. Key information
Keys .................................. 108
3-2. Opening, closing and locking the doors and
trunk
Smart key system ............. 111
Wireless remote control ............................. 126
Doors ................................ 129
Trunk ................................. 132
3-3. Adjusting the seats Front seats ........................ 136
Driving position memory ........................... 138
Head restraints.................. 143
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 146
Inside rear view mirror ...... 147
Outside rear view mirrors ............................. 149
3-5. Opening, closing the windows and
moon roof
Power windows ................. 152
Moon roof .......................... 155

108
AVALON_HV_U (OM41457U)
3-1. Key information
The following keys are provided with the vehicle.Electronic keys
• Operating the smart key system (P. 1 1 1 )
• Operating the wireless remote control function ( P. 126)
Mechanical keys
Key number plate
To take out the mechanical key,
push the release button and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the entry
function does not operate properly,
you will need the mechanical key.
( P. 430)
Keys
The keys
1
2
3
Using the mechanical key

1093-1. Key information
3
Operation of each component
AVALON_HV_U (OM41457U)
■When required to leave the vehicle’s key with a parking attendant
Turn the trunk opener main switch off and lock the glove box as circum-
stances demand. ( P. 133, 278)
Remove the mechanical key for your own use and provide the attendant with
the electronic key only.
■ If you lose your mechanical keys
New genuine mechanical keys can be made by your Toyota dealer using the
other mechanical key and the key number stamped on your key number
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
■ When riding in an aircraft
When bringing an electronic key onto an aircraft, make sure you do not press
any buttons on the electronic key while inside the aircraft cabin. If you are
carrying an electronic key in your bag etc., ensure that the buttons are not
likely to be pressed accidentally. Pressing a button may cause the electronic
key to emit radio waves that could interfere with the operation of the aircraft.

1103-1. Key information
AVALON_HV_U (OM41457U)
NOTICE
■To prevent key damage
● Do not drop the keys, subject them to strong shocks or bend them.
● Do not expose the keys to high temperatures for long periods of time.
● Do not get the keys wet or wash them in an ultrasonic washer etc.
● Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
● Do not disassemble the keys.
● Do not attach a sticker or anything else to the surface of the electronic key.
● Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems and induction cooker s, or medical electrical equip-
ment, such as low-frequency therapy equipment.
■ Carrying the electronic key on your person
Carry the electronic key 3.9 in. (10 cm) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.
■ In case of a smart key system malfunction or other key-related prob-
lems
Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.
■ When an electronic key is lost
If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit your Toyota dealer imm ediately with all remaining electronic
keys that was provided with your vehicle.

111
3
Operation of each component
AVALON_HV_U (OM41457U)
3-2. Opening, closing and locking the doors and trunk
The following operations can be performed simply by carrying the
electronic key on your person, for example in your pocket. (The driver
should always carry the electronic key.)
■ Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: once; Unlocked: twice)
■ Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
Smar t key system
Function summary
Locks and unlocks the doors ( P. 1 1 2 )
Unlocks the trunk ( P. 11 2 )
Starts the hybrid system ( P. 177)1
2
3

1123-2. Opening, closing and locking the doors and trunk
AVALON_HV_U (OM41457U)
Grip the driver’s door handle to
unlock the door. Some models,
grip the passenger’s door handle
to unlock all the doors.
*
Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for
3 seconds after the doors are
locked.
*: The door unlock settings can bechanged. ( P. 1 1 8 )
Touch the lock sensor (the inden-
tation on the upper part of the
door handle) to lock all the doors.
Check that the door is securely
locked.
Press the button to unlock the
trunk.
Unlocking and locking the doors
Unlocking the trunk
