2015 Ram ProMaster display

Balance
The display will show the messageBAL 00to indicate
that the balance function can be set. Turn the ROTARY
knob clockwise to transfer the sound to the right-hand
side; the display will show BAL R 01. Turn the ROTARY
knob counterclockwise to transfer the sound to the
left-hand side; the display will show BALL01. The
balance levels can be set between 0 and 15.
Fader
The display will show FA D 0 0to indicate that you can
set the Fader function. Turn the ROTARY knob clockwise
to transfer the sound to the front; the display will show
FADF01 . Turn the ROTARY knob counterclockwise to
transfer the sound to the back; the display will show
FADR01 . The fader levels are set from 0 to 15. Loudness
The display will show
LOUD 00to indicate that you can
set the loudness (enhanced sound) function. Turn the
ROTARY knob clockwise to enable the loudness function
at level 1; the display will show LOUD 01and the
LOUD flag will be enabled. The radio supports three
loudness levels.
Volume
Turn the ROTARY knob clockwise to increase the vol-
ume. Turning it counterclockwise will lower the volume.
The volume can be set between 0 and 30.
Tuner Mode (AM/FM Radio)
When you enter TUNER mode, the radio tunes to the
most recently selected station and will remain on the
most recently selected frequency band.
156 UNDERSTANDING YOUR INSTRUMENT PANEL

In this mode of operation the display will show one of the
following 5 codes:
CH (Channel)
When this is on, it indicates that the current radio station
preset is stored in memory. The code is only shown when
the tuned frequency is showing on the display.
ST (Stereo)
When this is on, it indicates the radio station is transmitting.
Searching for Stations In Automatic Mode
When you push
orfor less than two seconds, the
radio will search for the next valid station. While the
radio is searching for the new station, the display will
show SEEKING. When the search is complete, the
display will show the tuned frequency band and
station in the format F1 106.9or, if the station was
previously stored in memory, the display will show
the channel where it is stored and the tuned station.
Searching for Stations In Manual Mode
Pushing
orfor more than two seconds displays
the selected radio station frequency. Each time a
button is pushed, the radio station frequency is in-
creased or decreased according to the default search
pattern for the selected band (100 kHz for FM and 10k
Hz for AM). When the search button is pushed and
held, the radio station frequency will continue to be
increased or decreased. If the buttons are not pushed
for five seconds, the display will show the message
AUTO and manual search mode will be canceled.
When the search is complete, the display will show the
tuned band and station in the format F1 106.9,or,if
the station found was previously stored in memory,
the display will show the channel where it is stored
and the tuned station. 4
UNDERSTANDING YOUR INSTRUMENT PANEL 157

Mute/Pause
Pushing this button mutes the sound. The display will
switch betweenMUTE ONand the previous display (3
seconds).
Pushing the button again restores the audio without
changing the original volume setting. The display will
show MUTE OFF for three seconds, and then return to
the previous display mode.
When the
or, Audio, 1, 2, 3, 4, 5, 6, BAND/AS
buttons and SRC are pushed in Mute/Pausedmode,
these will be implemented and the audio will be
restored without changing the original volume.
Turn the ROTARY knob to restore the audio and change
the volume to the level selected. The display will show
the settings described in the volume function.
The other buttons should be implemented when pushed,
but the radio will remain in MUTE ONmode. Storing Stations In Memory
Push and hold the memory buttons (1 through 6) for
more than two seconds to associate the tuned station
with the pushed button. The display will show a message
in
MEMO 2 format for three seconds to confirm that the
station has been tuned in. The CH signal is then activated
and the display will show the preset number and station
frequency for three seconds 2 106.9. The display will
then return to the previous view.
Accessing Preset Stations
When the preset buttons (1 through 6) are pushed for less
than two seconds the radio will tune in to the station
associated with that particular memory location. The
display shows the preset number and frequency of the
associated station for three seconds. The display will then
return to the previous view.
158 UNDERSTANDING YOUR INSTRUMENT PANEL

Retuning the band: When the BAND/AS button is
pushed for less than two seconds, the radio will alternate
between bands in the sequence: FM1
FM2FM3
AM1AM2FM1. While changing bands from
the FM3 band to
AM1, the display will show AM
for two seconds and when changing from the AM2
band to
FM1, the display will show FMfor two
seconds.
The display will then show the selected band and fre-
quency in the format F1 106.9for two seconds and then
return to the previous view.
Presetting stations with a strong signal: when the
BAND/AS button is pushed for more than two seconds,
the radio will search for the 6 best stations and automati-
cally store them in the 6 memory positions of the current
band. During the search, the display will indicate FM
AST orAM AST, depending on the band selected. To
record the stations that are found, these are sorted in
ascending order of frequency and the first one is stored in memory position 1, and so on, until positions 1-6 are all
in use. If fewer than 6 stations are found, the unused
channels will be allocated to the 107.9 MHz frequency for
FM and AM 1710 KHz for the AM band. At the end of the
search process, the radio tunes in to the first preset
position and the display will indicate the associated
preset number (1) and the station frequency for three
seconds. The display will then return to the previous
view.
Setup Menu
You can use the Setup menu to change the various factory
settings to suit your own preferences.
Push MENU to activate the Maximum Volume function.
Repeatedly pushing this button will activate the other
functions in the following sequence: Maximum Volume
(MVOL)
Auto Switch (AUTO)Beep (BEEP)
Set ClockMaximum Volume (MVOL). If this
button or the button for adjusting the selected function 4
UNDERSTANDING YOUR INSTRUMENT PANEL 159

is not pushed for five seconds or if the ROTARY knob
is pushed, the display returns to the previous view
and the changes will be saved.
Maximum Volume
This function allows you to set the maximum permissible
volume. Turn the ROTARY knob to set the volume. The
display will show a message in the formatMVOL 26
indicating the maximum volume selected. When the
maximum volume selected is the maximum radio vol-
ume, the display will show MVOL OFF.
Auto Switch
This function changes the on/off sequence of the radio as
described in the section: Turning the device on and off.
To enable it, turn the ROTARY knob clockwise. The
display will show AUTO ON. To disable it, turn the
ROTARY knob counterclockwise and the display will
show AUTO OFF. Beep
With this feature is enabled, the radio will emit a beep
when any knob is activated.
Clock settings
When you select this function, the display will show the
clock. To select the field to be set, push
or. Turn
the ROTARY knob to adjust the selected field.
Clock
Pushing the DISP button for more than two seconds
enables or disables the clock display. When this feature is
enabled, the display shows CLK ONand the clock is
displayed whenever the ignition is switched on, even if
the radio is off. This function takes priority in the display
whenever you access any of the radio functions. If no
buttons are pushed within 10 seconds, the display will go
back to showing the clock. When this function is dis-
abled, the display shows CLK OFF.
160 UNDERSTANDING YOUR INSTRUMENT PANEL

USB Mode (MP3/WMA/AAC)
CAUTION!
To remove devices connected to the USB port, first
select the other audio source. Failure to follow this
procedure can cause damage to the connected device.
Due to the extensive range of makes and models of
storage devices available on the market, not all
devices have compatibility required for proper func-
tioning of Car Radios. Use only quality USB devices.
Due to the extensive range of brands and models of
storage devices available on the market, not all devices
are compatible with proper functioning of the car radio.
NOTE: The car radio is only compatible with USB mass
storage devices that are fully compatible with the USB 2.0
standard. Use quality USB devices only. In USB mode, the radio plays MP3, WMA and AAC files
stored on the device connected to the USB port that is
located on the lower right side of the steering wheel on
the instrument panel.
To enter USB mode, you must push the SRC button.
When you enter USB mode, the display shows
LOAD-
ING while the radio checks whether the connected
device is valid.
If there is no USB device, an invalid USB device, or a
valid device that is defective, the display will show ERR
USB for two seconds and the radio remains in TUNER
mode. If a valid device does not contain any playable
files (i.e. MP3, WMA or AAC), the display will show NO
MUSIC for two seconds and the radio remains in
TUNER mode.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 161

When these buttons are pushed, the display will show a
TRKyyymessage, where yyy is the track number. If any
of these buttons is briefly pushed again, the number in
the display will continue changing according to the
selected track. While the track is being selected, that is,
when
orare pushed briefly, the information
contained in the ID3 tag will not be processed (the ID3
tag can store information such as the title, artist,
album, track number, etc.). If neither
orare
pushed down and held, the track will be selected and
the ID3 tag will be processed and begin playing. In
this case, the display will show TRKyyyfor two
seconds and then return to the DISP function view.
Whenever the radio switches from one folder to
another, the display will show the name of the folder
you are moving to for at least 500 ms (seek button
movements are ignored during this time), and no
longer than three seconds.
When you reach the final song in the last folder and push
again, the radio will advance to the first song in the
first folder on the USB device. When you reach the
first song in the first folder and push
again, the
radio will advance to the final song in the last folder
on the USB device.
Forward/Reverse Along The Track:
When
oris pushed for more than two seconds,
the radio will reverse or forward the music for as long
as the button is held down. The display shows the
runtime of the music in the format 003 01:32(track
number and runtime). When the operation is com-
pleted, the display will continue to display the music
runtime for two seconds. After that it returns to the
previous view. 4
UNDERSTANDING YOUR INSTRUMENT PANEL 165

Mute/Pause
Pushing this knob stops music playback and mutes the
sound. The display will switch betweenPAUSEDand
the current view (three seconds).
Push this button again to resume music playback from
the point where it left off, without changing the original
volume level. The display will show PLAYfor three
seconds. It then returns to the previous mode.
When
or, Audio, 1, 2, and SRC are pushed in
Mute/Paused mode, playback (where applicable)
will resume and the sound will be restored without
changing the original volume level.
Turn the ROTARY knob to resume playing the music and
change the volume accordingly. The display will feature
the information described in the volume function. Pushing the F-TRACK button will not resume play, but
using the (F-TRK + rotation) function will start or resume
play.
The other buttons should be implemented when pushed,
but the radio will remain in
Mute/Pausedmode.
Fast Track: Pushing the F-TRK button activates FAST
TRACK mode and the display will show the name of the
current folder. If the ROTARY knob is not activated, the
radio returns to its previous state.
If the ROTARY knob is turned, the display shows the
TRKyyy message, where yyy is the track number.
Turning the knob clockwise will forwards the tracks and
turning it counterclockwise will reverse the tracks. While
this is being performed, the information contained in the
ID3 tag is not processed. As the knob is turned, the
TRKyyy message changes to the track selected.
166 UNDERSTANDING YOUR INSTRUMENT PANEL
