2015 Ram 2500 Owner's Manual

7. Pull down on the clamp wire and push the clamp upinto the proper released position. 8. Be sure to clip both stowage straps together to insure
the cover stays together.
Semi Clamped PositionProper Released Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271

9. With two people remove the cover.
NOTE:Be sure the Tonneau Cover has been folded
completely before removing.
Tri-Fold Tonneau Cover Installation
To install the Tonneau Cover follow the following steps: 1. Position the folded Tonneau Cover on the truck bed
and push the Cover forward against the front of the
truck bed. The Tonneau Cover centers itself when
placed on the vehicle.
2. Pull down on the first set of clamp handles to release the clamps from the stowed position.
Stowage Strap
Stowed Position
272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Push clamp wires up and under the flange of box (orflange of Ram Box rail, if equipped) to the semi
clamped position.
4. Push clamp handles upward to the clamped position to properly engage the clamps. NOTE:
Once clamped, be sure the clamps are not par-
tially clamped to the truck bed flange.
Semi Clamped Position
Clamped Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273

5. Disengage the stowage straps.
6. Unfold Tonneau Cover to the intermediate position.NOTE:
The vehicle cannot be driven when the Tonneau
Cover is in this position.
Improper Clamp Position
Intermediate Position (Vehicle Cannot Be Driven)
274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. Completely unfold the Tonneau Cover.8. Pull down on the second set of clamp handles to
release the clamps from the stowed position.
Fully Unfolded Position
Stowed Position
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275

9. Push clamp wires up and under the flange of box (orflange of Ram Box rail, if equipped) to the semi
clamped position.
10. Push clamp handles upward to the clamped position to properly engage the clamps. NOTE:
Once clamped, be sure the clamps are not par-
tially clamped to the truck bed flange.
Semi Clamped Position
Clamped Position
276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The Tonneau Cover clamps can be locked when in the
clamped position by placing a lock through the locking
hole.
Improper Clamp PositionLocking Hole
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277

CAUTION!
It is the driver ’s responsibility to ensure the Tonneau
Cover is properly installed on the vehicle. Failure to
follow this procedure can result in detachment of the
Tonneau Cover from the vehicle and/or damage to
the vehicle/Tonneau Cover.
Tri-Fold Tonneau Cover Cleaning
For proper cleaning of the Tonneau Cover use MOPAR®
Whitewall & Vinyl Top Cleaner and MOPAR® Leather &
Vinyl Conditioner/Protectant.
