2015 PEUGEOT 2008 Owners Manual

327
2008_en_Chap12d_RDE1_ed01-2015
QUESTIONANSWER SOLUTION
The quality of reception of
the radio station listened
to gradually deteriorates
or the stored stations do
not function (no sound,
87.5

MHz is displayed...). The vehicle is too far from the transmitter used by the station
listened to or there is no transmitter in the geographical area
through which the vehicle is travelling.
Switch on the RDS function to enable the system
to check whether there is a more power ful
transmitter in the geographical area.
The environment (hills, buildings, tunnels, basement car parks...)
block reception, including in RDS mode. This phenomenon is normal and does not
indicate a failure of the audio equipment.
The aerial is absent or has been damaged (for example when going
through a car wash or into an underground car park). Have the aerial checked by a PEUGEOT dealer.
Sound cut-outs of 1 to
2

seconds in radio mode. During this brief sound cut-out, the RDS searches for any frequency
permitting better reception of the station. Switch off the RDS function if the phenomenon is
too frequent and always on the same route.
The traffic announcement
(TA) is displayed. I do
not receive any traffic
information. The radio station does not broadcast traffic information.
Tune to a radio station which broadcasts traffic
information.
The stored stations are not
found (no sound, 87.5 MHz
is displayed...). An incorrect waveband is selected.
Press the SRC button to return to the waveband
(AM, FM1, FM2) on which the stations are stored.
.
Audio and Telematics

328
2008_en_Chap12d_RDE1_ed01-2015
QUESTIONANSWER SOLUTION
The CD is ejected
automatically or is not
played by the player. The CD is inserted upside down, is unplayable, does not contain
any audio data or contains an audio format which the player cannot
p l ay.
The CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment. -

C
heck that the CD is inserted in the player
the right way up.
-

C
heck the condition of the CD: the CD
cannot be played if it is too damaged.
-

C
heck the content in the case of a recorded
CD: consult the advice in the "Audio" section.
-

T
he audio system's CD player does not play
DVDs.
-

D
ue to their quality level, certain writeable
CDs will not be played by the audio system.
The CD player sound is
p o o r. The CD used is scratched or of poor quality.
Insert good quality CDs and store them in
suitable conditions.
The audio settings (bass, treble, ambiance) are unsuitable. Set the treble or bass level to 0, without selecting
an ambiance.
In "Random all" play, not
all of the tracks are played. In "Random all" play, the system can only take into account up to
999 tracks.
With the engine off, the
audio system switches off
after a few minutes of use. When the engine is switched off, the audio system operating time
depends on the battery charge.
The switch-off is normal: the audio system switches to economy
mode and switches off to prevent discharging the vehicle's battery. Start the vehicle's engine to increase the battery
charge.
The message "the audio
system is overheated"
appears on the display. In order to protect the installation if the surrounding temperature
is too high, the audio system switches to an automatic thermal
protection mode leading to a reduction of the volume or stopping of
the playing of the CD. Switch the audio system off for a few minutes to
allow the system to cool.
Audio and Telematics

329
2008_en_Chap13_index-alpha_ed01-2015
Accessories .................................................. 208
AdBlue® ............................... ..........................16 4
Additive, AdBlue .............................. 24, 16 4, 168
Adjusting headlamps


.................................... 118
Adjusting head restraints


................................ 56
Adjusting seat


................................................. 55
Adjusting seat belt height
............................. 13

8
Adjusting the air distribution


...........................66
Adjusting the air flow


....................................... 66
Adjusting the date


........................................... 41
Adjusting the height and reach of the steering wheel


.................................... 58
Adjusting the temperature
.............................. 66
A

djusting the time

........................................... 41
Advice on care and maintenance


........................................ 207
Advice on driving


............................................ 78
Airbags


.................................................... 2 7, 1 41
Airbags, curtain
..................................... 14

3, 14 4
Airbags, front ......................................... 141, 14 4
Airbags, lateral


...................................... 143, 14 4
Air conditioning


............................................... 12
Air conditioning, automatic


................62, 63, 66
Air conditioning, digital


................................... 69
Air conditioning, manual


.....................62- 64, 69
Air distribution adjustment


.............................. 66
Air filter

.......................................................... 217
Air flow adjustment


......................................... 66
Air intake


......................................................... 66
Air recirculation


............................................... 66
Air vents


.......................................................... 61
Alarm


......................................................... 42 , 51
Anti-lock braking system (ABS)

.............................................. 13

3
Anti-theft


......................................................... 44
Assistance call


...................................... 129, 23 3
Assistance, emergency braking
...............

......................................... 13 3Battery


...........................................198-200, 217
Battery, charging


...........................................200
Battery, remote control
............................. 4

5, 46
Blind


..............................................................127
BlueHDi


.........................................................16 4
Bluetooth (hands-free)
................. 2

84, 285, 306
Bluetooth (telephone)


...........................284, 285
Bonnet


...........................................................2 11
Boot


...........................................................4 9 , 74
Brake discs
.................................................... 2

18
Brake lamps
...............................

...........189, 19 0
Brake pads


....................................................218
Brakes


...........................................................218
Braking assistance system

...........................13

3
Bulbs (changing)
........................... 18

5, 189, 19 0
A
B
Capacity, fuel tank ........................................159
CD ................................................................. 264
CD, MP3
........................................ 2

64, 302-304
Central locking


.......................................... 43, 50
Changing a bulb


............................ 185, 189, 19 0
Changing a fuse


............................................ 192
Changing a wheel


................................. 17 7, 178
Changing a wiper blade


................................................... 123, 202
Changing the remote control battery ............................................... 45
Checking levels
...................................... 21

4 -216
Checking the engine oil level


.......................................................... 31
Checking tyre pressures (using the kit)
..............................

................172
Checks
...............

....................212, 213, 217, 218
Child lock
...............................

........................15 8
Children
...............................

...........151, 15 4 -157
Child seats

................... 1

45, 146, 150, 151, 153
Child seats, conventional
............................................... 15

0
Child seats, ISOFIX

...................................... 15

6
Cleaning (advice)
.......................................... 2

07
Closing the boot
.............................................. 49
Closing the doors


............................................ 47
Connection, Bluetooth


.........................284, 285
Control, electric windows


................................53
Control, emergency boot release


.................................................. 49
Control, heated seats


...................................... 56
Controls, at steering...................................... 299
Control stalk, wipers
.............................121, 12 2
Coolant level


................................................. 215
Courtesy lamps
............................................. 125
Cover, load space

........................................... 76
C

ruise control
........................................ 10

1, 103
Cup holder

...............................
........................70
Audible warning
............................................ 129
Audio streaming (Bluetooth) ........ 2
64, 266, 305
Audio system (radio)

..................................... 317
Automatic illumination of headlamps


.............................................. 112
Automatic operation of hazard warning lamps


............................................ 128
Auxiliary


........................................................ 264
Cable, audio


.................................................. 264
Cable, jack


.................................................... 264
C
.
Alphabetical index

330
2008_en_Chap13_index-alpha_ed01-2015
Emergency warning lamps .....................7 7, 1 2 8
Emissions control system, SCR


.............................................................. 25
Energy economy mode


.................................201
Engine compartment


............................212, 213
Engine, Diesel
............... 1

62, 163, 213, 224, 226
Engine oil level indicator


...................................................... 214
Engine, petrol


........................ 162, 212, 220, 222
Engines


................................................. 220, 224
Environment
...............................

...............12, 4 5
Filling the fuel tank

........................1

59, 161, 162
Fitting a wheel

...............................
................180
Fitting roof bars


............................................. 207
Fittings, boot
................................................... 74
F

ittings, interior

......................................... 70, 71
Flap, fuel filler

...............................
.........159, 161
Flashing indicators


........................116, 128, 186
Foglamp, rear
...............................

.........189, 191
Foglamps, front


............................................. 188
Folding/unfolding the door mirrors
............................................ 59
Frequency (radio)


.................................. 260, 261
Front foglamps


...................................... 113 , 11 9
Fuel .......................................................... 12, 162
Fuel consumption
............................................ 12
Fu

el tank ................................................ 159, 161
Fusebox, dashboard


..................................... 192
Fusebox, engine compartment
.............................................. 19

2
Fuses


............................................................. 192Hazard warning lamps


............................7 7, 1 2 8
Headlamps, automatic illumination


..................................................117
Headlamps, dipped beam


.............................18 6
Headlamps, main beam
................................ 18

6
Head restraints, front
......................................56
Head restraints, rear
.......................................58
Heating


................................................12, 63, 64
Hill start assist

.................................................98
G
FH
EBA (Emergency braking assistance) ..........13 3
Eco-driving ..................................................... 12
Eco-driving (advice)


........................................ 12
Economy mode


............................................. 201
Electronic brake force distribution (EBFD)


........................................................ 13 3
Electronic gearbox system
...............83, 86, 218
Emergency call
..................................... 12

9, 232
E
DAB (Digital Audio Broadcasting) - Digital radio ......................................... 262, 263
Date (setting)
...............................

....................41
Daytime running lamps


.................................115
Daytime running lamps, LED


........................115
Deactivating the passenger airbag
.......................................................... 1

41
Defrosting


..................................................64, 69
Demisting
...............................

...................64, 69
Dials and gauges


...................................... 14, 15
Diesel additive level


...................................... 216
Dimensions


................................................... 229
Dipped beam
...............................

..................111
Dipstick
................

.................................... 31, 214
Directional lighting


........................................ 11 9
Direction indicators


.......116, 128, 186, 189, 190
Display screen, instrument panel


....................................................... 14, 15
Door pockets
................................................... 70
D

oors

............................................................... 47
Driving economically ....................................... 12
Dynamic stability control (DSC)


.................................... 23, 13 3, 13 5, 13 6 Gauge, fuel
.................................................... 159
Gearbox, automatic
..................12, 90, 200, 218
Gearbox, electronic


..........................12, 95, 200
Gearbox, manual


........................12, 82, 95, 218
Gear lever
..............................

.........................12
Gear lever, automatic gearbox
....................... 90
G

ear lever, manual gearbox

...........................82
Gear shift indicator


.........................................94
Glove box
........................................................71
Grip control
...................................................13 6
Guide-me-home


............................................117
D
Identification plates .......................................23 0
Ignition ................ ............................................. 80
Ignition switch
................................................. 79
Imm

obiliser, electronic

..............................44, 46
I
Alphabetical index

331
2008_en_Chap13_index-alpha_ed01-2015
Main beam .................................................... 111
Maintenance (advice) .................................... 207
Maintenance, routine


...................................... 12
Map reading lamps


....................................... 125
Markings, identification


.................................230
Mat


.................................................................. 73
Menu


.................................... 240, 242, 246, 254,
256, 258, 268, 280, 282
Menus (audio)


......240, 242, 246, 254, 256, 258
Menus (Touch screen)
......................... 23

5, 239Net, high load retaining


...................................
75
Net, storage ..................................................... 74
Number plate lamps
...................................... 19
1
Oil filter
...............
...........................................
217
Oil level .......................................................... 214
Opening the bonnet
...................................... 2
11
Opening the boot
..............................
..............
49
Opening the doors ............................... ...........
47
Opening the fuel filler flap .............................159
Opening the shutter


......................................127
M
N
O
Labels, identification .....................................23 0
LED daytime running lamps .........................187
LEDs - light-emitting diodes


.........................189
Level, AdBlue
® additive ................................. 16 4
Level, brake fluid ........................................... 2
14
Level, engine coolant


...................................... 32
Level, engine oil

...............................
...............31
Levels and checks
................................. 212-216
Light-emitting diodes - LEDs


........................ 189
Lighting control stalk


.............................. 111, 11 6
Lighting dimmer
..............................

..............124
Lighting, guide-me home


................ 4 4 , 11 6 , 117
Lighting, interior


.................................... 125, 126
Lighting, mood


.............................................. 126
Lighting on reminder


..................................... 114
Loading


................................................... 12, 207
Load reduction mode


.................................... 201
Locating your vehicle
...................................... 44
Lo

cking


............................................................ 42
Locking the boot.............................................. 49
Low fuel level

................................................ 159
Luggage retaining strap


.................................. 74
L
Mirror, rear view .............................................. 60
M irrors, door .................................................... 59
Misfuel prevention
...............................

..........161
Motorway function (direction indicators)


...................................128
Mountings for ISOFIX seats


.........................15 4
Mountings, Isofix


........................................... 15 6
MP3 CD
................................................. 302-304
Jack
........

....................................... 17 7, 178 , 2 6 4
Jukebox (c opy)


.............................................. 267
Jukebox (playing)


.......................................... 267
Jump starting
..............................

.................. 19 9
Keeping children safe
............. 1

41, 145, 146, 151, 154, 155, 157
Key


............................................................ 42, 43
Key in ignition warning


.................................... 80
Key with remote control

............................ 44, 46
Kit, hands-free


............................. 284, 285, 306
Kit, temporary puncture repair


...................... 172
Indicator, coolant temperature ........................
32
I
ndicator, engine oil level

................................ 31
Indicator lamps, operation


........................ 16, 20
Indicators, direction


.............................. 128, 18 6
Inflating tyres


.................................................. 12
Inflating tyres and accessories (using the kit)
..............................

................ 172
Input, auxiliary
...............................

................ 322
Instrument panels


..................................... 14, 15
Instrument panel screen


........................................................... 94
Interactive help


.............................................. 275
ISOFIX child seats

........................ 15

4, 155, 157
Isofix mountings
...............................

............. 15 6
ISOFIX mountings ......................................... 15 4
J
K
Paint colour code .......................................... 23 0
Panoramic glass sunroof ..............................127
P
.
Alphabetical index

332
2008_en_Chap13_index-alpha_ed01-2015
Seats, front ......................................................55
Seats, heated .................................................. 56
Seats, rear


....................................................... 57
Selector lever, electronic gearbox system
.............................. 83, 86, 218
Serial number, vehicle
.................................. 23

0
Service indicator


............................................. 28
Servicing
...............................

..........................12
Settings (Menus)


........................................... 268
Settings, system


............................................ 276
Sidelamps


...................... 111, 115, 116, 187, 189
Side repeater
..............................

..................188
Snow chains
.................................................. 18

4
Socket, 12 V accessory

..................................71
S

ocket, auxiliary

............................................ 264
Socket, JACK


..........................................72, 264
Sockets, audio


........................................ 72, 322
Sockets, auxiliary


.......................................... 322
Speed limiter


........................................... 99, 103
Starting the engine


......................................... 79
Starting the vehicle


............................83, 86, 90
Starting using another battery
......................................................... 19

9
Station, radio
......................................... 26

0, 261
Stay, bonnet


.................................................. 2 11
Steering mounted controls, audio


........................................................... 238
Steering wheel, adjustment
.................................................... 58
S

topping the vehicle

..........................83, 86, 90
Stop & Start


................................ 39, 69, 95, 107,
159, 198, 211, 217
Storage


...................................................... 70, 71
Stowing rings


.................................................. 74
Switching off the engine


..................................................... 79
Synchronising the remote control
........................................................... 45
R

emote control ....................................
4
2, 43, 46
Removing a wheel

........................................ 180
Removing the mat


........................................... 73
Replacing bulbs


............................ 185, 189, 19 0
Replacing fuses
..............................

.............. 192
Replacing the air filter


................................... 217
Replacing the oil filter
................................... 2

17
Replacing the passenger compartment filter


...................................... 217
Replacing wiper blades .................................123
Resetting the service indicator


....................... 30
Resetting the trip recorder


.............................. 40
Reversing lamp
..................................... 18

9, 191
Risk areas (update)

....................................... 2 51
Roof bars
....................................................... 2

07
Routine checks


..................................... 217, 218
Running out of fuel (Diesel)

.......................... 16

3
Radio


.................................... 260, 261, 264, 300
Radio, digital (Digital Audio Broadcasting - DAB)


........................... 262, 263
RDS


............................................................... 261
Rear foglamp ................................................. 113
Rear screen, demisting


................................... 69
Recharging the battery
................................. 20

0
Recirculation, air


............................................. 66
Reduction of electrical load


.......................... 201
Regeneration of the particle emissions filter


............................................ 217
Reinitialising the remote control
..................... 45
R
Park Assist .................................................... 10 7
Parking brake .......................................... 81, 218
Parking lamps


............................................... 11 6
Parking sensors, front


...................................10 6
Parking sensors, rear .................................... 105
Particle emission filter


..........................216, 217
Passenger compartment filter


......................217
PEUGEOT Connect Apps
.............................279
P
E

UGEOT
C
onnect Assistance

...................233
P
E

UGEOT
C
onnect Packs

...........................233
P
E

UGEOT
C
onnect SOS
............................. 2

32
Player, Apple
® .............................. .................266
Player, MP3 CD ............................. 264, 302-304
Player, USB

................................................... 264
Port, USB

....................................... 7

2, 264, 303
Pressures, tyres


............................................ 176
Priming the fuel system
................................ 163
Protecting children


................ 141, 145, 146, 151, 154-157
Puncture


........................................................ 172
Safety, children
............................................. 15

6
Safety for children
.........................................15 8
Screen, instrument panel


..........................3 7, 3 8
Screen menu


........................240, 242, 246, 254,
256, 258, 268, 280, 282
Screen menu map


.......240, 242, 246, 254, 256,
258, 268, 280, 282, 311, 325
Screenwash


..................................................120
Screenwash fluid level
..................................215
Screenwash, rear


..........................................121
Screen-wash reservoir


.................................215
SCR (Selective Catalytic Reduction)
.................................................. 16

4
SCR system
..................................................16 4
Seat belts
....................................... 1

3 8 -14 0, 15 0
S
Alphabetical index

333
2008_en_Chap13_index-alpha_ed01-2015
Under-inflation (detection) ............................13 0
Unlocking .............................. ..........................42
Unlocking the boot
.......................................... 49
Updating risk areas
....................................... 2

51
Updating the date


............................................ 41
Updating the time


............................................ 41
UREA


.................................................... 16 4, 165
USB


............................................................... 264
U
Vehicle identification ..................................... 230
Ventilation .............................. .............12, 61- 6 4
V
Table of weights ................................... 2 22, 226
Tables of engines .................................. 220, 224
Tables of fuses
.............................................. 192
Tank, AdBlue
®
additive
............................................... 16 4, 169
Ta n k , f u e l


............................................... 159, 161
Technical data


...................... 220, 222, 224, 226
Telephone


............................. 280, 282, 284-286
Temperature adjustment
................................. 66
T

emperature, coolant

...................................... 32
Third brake lamp


............................................................ 191
Time (setting)
..............................

....................41
TMC (Traffic info)

.......................................... 2

52
To o l s


...................................................... 17 7, 178
Total distance recorder


........................................................ 40
Touch screen ........................ 33, 35, 36, 38, 132
Touch screen ( M e nu s)


.............................................. 235, 239
To w b a r


........................................................... 205
Towed loads


......................................... 222, 226
Towing another vehicle


......................................................... 203
Towing eye

.................................................... 203
Traction control (ASR)


............................ 23, 13 3
Traffic information (TA)


.........................253, 301
Traffic information ( TM C)
...............................

........................... 252
Tr a i l e r


............................................................ 205
Trajectory control systems

....................................................... 13

3
Triangle, warning ............................................. 77
Trip computer


.............................................37- 3 9
Trip distance recorder


..................................... 40
Tyre pressures


.............................................. 230
Ty r e s


................................................................ 12
Tyre under-inflation detection


.......13 0, 132, 176
T
Warning and indicator lamps ..............16, 20, 21
Warning lamps ................................................ 21
Warning lamp, SCR emissions control system

.............................................. 25
W

ashing (advice) ........................................... 207
Weights


................................................ 222, 226
Wheel, spare


......................................... 17 7, 178
Window controls


............................................. 53
Wiper blades (changing)
............................... 2

02
Wiper control stalk
........................................ 120
Wiper, rear ..................................................... 121
Wipers


............................................. 19, 120, 12 2
Wipers, automatic rain sensitive
....................................... 12

0, 12 2
W
.
Alphabetical index
