Vehicle Dynamic Control(VDC) OFF indicator light
This indicator light comes on when the VDC off
switch is pushed to OFF. This indicates the VDC
system is not operating.
Push the VDC off switch again or restart the
engine and the system will operate normally. For
additional information, refer to “Vehicle Dynamic
Control (VDC) system” in the “Starting and driv-
ing” section of this manual.
The VDC light also comes on when you place the
ignition switch in the ON position. The light will
turn off after about 2 seconds if the system is
operational. If the light stays on or comes on
along with the
indicator light while you are
driving, have the VDC system checked by a
NISSAN dealer.
While the VDC system is operating, you might
feel slight vibration or hear the system working
when starting the vehicle or accelerating, but this
is normal.
AUDIBLE REMINDERS
Brake pad wear warning
The disc brake pads have audible wear warnings.
When a disc brake pad requires replacement, it
makes a high pitched scraping sound when the
vehicle is in motion, whether or not the brake pedal is depressed. Have the brakes checked as
soon as possible if the warning sound is heard.
Key left reminder chime
A chime sounds if the driver’s door is opened
while the ignition switch is placed in the ACC or
OFF position with the Intelligent Key left in the
vehicle. Make sure the ignition switch is placed in
the LOCK position, and take the Intelligent Key
with you when leaving the vehicle.
Light reminder chime
With the ignition switch placed in the OFF posi-
tion, a chime sounds when the driver’s door is
opened if the headlights or parking lights are on.
Turn the headlight control switch off before leav-
ing the vehicle.
NISSAN Intelligent Key® Lock-in
Prevention
The Intelligent Key buzzer sounds if the Intelligent
Key is left inside the vehicle when the doors are
closed and locked. When the buzzer sounds, be
sure to take the Intelligent key with you when
leaving the vehicle. For additional information,
refer to “NISSAN Intelligent Key®” in the “Pre-
driving checks and adjustments” section of this
manual.
The vehicle information display is located to the
left of the speedometer. It displays such items as:
● Vehicle settings
● Trip computer information
● Drive system warnings and settings
● Forward Emergency Braking system (if so
equipped)
● Predictive Forward Collision warning system
(if so equipped)
● Blind Spot Warning system (if so equipped)
● Rear cross traffic alert system (if so
equipped)
LIC2205
VEHICLE INFORMATION DISPLAY
2-14Instruments and controls

●Cruise control system information
● Intelligent Cruise Control system information
(if so equipped)
● NISSAN Intelligent Key® operation informa-
tion
● Indicators and warnings
● Tire Pressure information
The display will be interrupted when a text mes-
sage is received, and can be operated via steer-
ing wheel mounted switch (models with Naviga-
tion) .
HOW TO USE THE VEHICLE
INFORMATION DISPLAY
The vehicle information display can be changed
using the buttons
and OK located on the
steering wheel.
1. OK — change or select an item in the vehicle information display
2.
— go back or forward through
the vehicle information menu items or to
change from one display screen to the next
(i.e. trip, TPMS, Fuel economy) 3.
— scroll up or down the vehicle infor-
mation menu items.
The OK,
andbuttons also
control audio and control panel functions. For
additional information, refer to “Steering wheel
switch for audio control” in “Display screen,
heater, air conditioner, audio and phone systems”
section of this manual.
STARTUP DISPLAY
When the vehicle in placed in the ON or ACC
position the screens that display in the vehicle
information display include:
● Active system status (if so equipped)
● Trip computer
● Tire pressure information
● Fuel economy
● Warnings
● Outside air temperature
● Odometer/Twin Trip Odometer
● Audio
● Navigation
● Settings
LIC3010
Instruments and controls2-15

Warnings will only display if there are any pres-
ent. For additional information on warnings and
indicators, refer to “Vehicle information display
warnings and indicators” in this section.
To control what items display in the vehicle infor-
mation display, refer to “Main menu selection” in
this section.
SETTINGS
The setting mode allows you to change the infor-
mation displayed in the vehicle information dis-
play:● Driver Assistance
● Customize Display
● Vehicle Settings
● Maintenance
● Clock
● TPMS Settings
● Unit / Language
● Key-Linked Settings
● Factory Reset
Driver Assistance
To change the status, warnings or turn on or off
any of the systems/warnings displayed in the
“Driver Assistance” menu:
Use the
button to select and the OK but-
ton to change a menu item:
● Driving Aids (if so equipped)
– Emergency Brake ON/OFF (if so equipped)
– Blind Spot ON/OFF (if so equipped)
– Driver Attention Alert ON/OFF (if so equipped)
– Timer Alert
– Low Temperature Alert ON/OFF
● Parking Aids (if so equipped)
– Moving Object ON/OFF (if so equipped)
Customize Display
The Customize Display allows the customer to
choose from various meter selections.
The meter settings can be changed using
the
and the OK button. Main Menu Selection
The items that display can be enabled/disabled
when the ignition switch is placed in the ON
position. To change the items that display.
Use the
button to select and the OK but-
ton to change a menu item:
● Home
● Audio
● Navigation
● Drive computer
● Fuel Economy
● Driving Aids
● Tire Pressures
Car Icon Color
The color of the vehicle that displays in the ve-
hicle information display when the ignition switch
is placed in the ON position can be changed.
ECO Info Settings
The following information can be
enabled/disabled to display in the vehicle infor-
mation display when the ignition switch is placed
in the ON posi tion.
2-16Instruments and controls

From the “Customize Display” select “ECO Info
Settings” to display the information when the
ignition switch is placed in the ON position.● ECO Drive Report – select “On” or “Off” to
display the information when the ignition
switch is placed in the ON position.
● View History - select to display the vehicle’s
information history.
Navigation (if so equipped)
This setting allows the customer to
enable/disable the alert for navigation in the ve-
hicle information display.
1.
Use thebuttons to select “Navigation”.
2. Press the OK button to turn ON/OFF the alert.
3. Press the OK button to change the “View Mode” between “City” and “Arrow”.
Welcome Effects
The welcome screen display can be adjusted
when the ignition switch is placed in the ACC or
ON position. Press the
orbutton to
toggle through the menu options. Press the OK
button to turn ON/OFF the following:
● Gauges
● Animation
Vehicle Settings
The vehicle settings allows the customer to
change settings for interior lights, turn signals,
intelligent key settings, unlock settings and other
vehicle settings.
The vehicle settings can be changed using
the
,, and the OK buttons.
Lighting
Select the Lighting menu option to adjust the
following: ● Accent Lighting
● Light Sensitivity - The light sensitivity can be
set to illuminate earlier based on the bright-
ness outside the vehicle. Press OK to
change the sensitivity timing.
● Light Off Delay - The duration of the auto-
matic headlights can be changed from 0 to
180 seconds. Press OK to change the du-
ration.
Turn Indicator
The 3 flash pass can be set to be ON or OFF.
From the Turn Indicator menu, select “3 Flash
Pass”. Use the OK button to turn this feature ON
or OFF. Exterior Door Switches
When this item is turned on, the request switches
on the doors are activated. From the Vehicle
Settings menu, select “Ext. Door Switch”. Use
the OK button to toggle between on and off.
When “ON is highlighted, Ext. Door Switch is
turned on. When “ON” is greyed-out, this item is
turned off.
I-Key Door Unlock (if so equipped)
When this item is turned on, the request switch
on the doors is activated. From the Vehicle Set-
tings menu, select “I-Key Door Unlock”. Use the
OK button to activate this function.
Answer Back Horn (if so equipped)
When the answer back horn is on, the horn will
chirp and the hazard indicators will flash once
when locking the vehicle with the Intelligent Key.
Selective Unlock
When this item is turned on and when the door
handle request switch on the driver’s or front
passenger’s side door is pushed, only the corre-
sponding door is unlocked first. The remaining
doors can be unlocked if the door unlock opera-
tion is performed again within 1 minute. When
this item is turned to OFF, all the doors will be
unlocked after the door unlock operation is per-
formed once. From the Vehicle Settings menu,
Instruments and controls2-17

select ”Locking” then “Selective Unlock”. Use the
OK button to toggle between on and off. When
“ON” is highlighted, “Selective Unlock” is turned
on. When “ON” is greyed-out, this item is turned
off.
Wipers
The speed dependent feature can be set to be
ON or OFF. From the Wipers menu, select
“Speed Dependent”. Use the OK button to turn
this feature ON or OFF.
Driving Position (if so equipped)
The driving position has two features that can be
set to be ON or OFF. From the Driving position
menu, select “Exit Seat Slide” or “Exit Steering
Up”. Use the OK button to turn this feature ON or
OFF.
Remote engine start (if so equipped)
The remote engine start feature can be set to be
ON or OFF. From the Remote engine start menu,
use the OK button to turn this feature ON or OFF.Maintenance
The maintenance mode allows you to set alerts
for the reminding of maintenance intervals. To
change an item:1. Push the
orbutton to toggle
through the menu items, and select “Set-
tings” and press OK.
2. Select “Maintenance” using the
but-
ton and press OK.
Oil and Filter
This indicator appears when the customer set
distance comes for changing the engine oil and
filter. You can set or reset the distance for check-
ing or replacing these items. For scheduled main-
tenance items and intervals, see your “NISSAN
Service and Maintenance Guide.”
Tire
This indicator appears when the customer set
distance is reached for replacing tires. You can
set or reset the distance for replacing tires.
WARNING
The tire replacement indicator is not a
substitute for regular tire checks, includ-
ing tire pressure checks. For additional
information, refer to “Changing wheels
and tires” in the “Maintenance and do-it-
yourself” section of this manual. Many fac-
tors including tire inflation, alignment,
driving habits and road conditions affect
tire wear and when tires should be re-
placed. Setting the tire replacement indi-
cator for a certain driving distance does
not mean your tires will last that long. Use
the tire replacement indicator as a guide
only and always perform regular tire
checks. Failure to perform regular tire
checks, including tire pressure checks
could result in tire failure. Serious vehicle
damage could occur and may lead to a
collision, which could result in serious
personal injury or death.
Other
This indicator appears when the customer set
distance is reached for checking or replacing
maintenance items other than the engine oil, oil
filter and tires. Other maintenance items can in-
clude such things as air filter or tire rotation. The
distance for checking or replacing the items can
be set or reset.
2-18Instruments and controls

Clock
To set the clock for system with navigation, press
the “MENU” button. For systems without naviga-
tion, press the “SETTING” button. For additional
information on how to set the clock, refer to the
“Display screen, heater, air conditioner, audio
and phone systems” section of this manual or the
separate Navigation Owner’s Manual.
TPMS Settings
The unit for tire pressure that displays in the
vehicle information display can be changed to:● psi
● kPa
● bar
● kgf/cm
2
Use thebuttons and the OK button to
select and change the unit.
Unit/Language
Select “Unit/Language” to adjust vehicle units
and language on the Vehicle Information Display.
The vehicle information display language can
also be changed by operating the navigation unit
(if so equipped) . For additional information, refer to the separate Navigation Owner’s Manual. Use
the
buttons to choose from he following
menu options:
● Mileage/Fuel
● Tire Pressures
● Temperature
● Language
Mileage/Fuel
The unit for the mileage that displays in the ve-
hicle information display can be changed to: ● miles, MPG
● km/h, km/l
● km/h, l/100km
Use the
buttons and the OK button to
select and change the unit.
Tire Pressures
The unit for tire pressure that displays in the
vehicle information display can be changed to:
● psi
● kPa
● bar
● kgf/cm
2
Use thebuttons and the OK button to
select and change the unit.
Temperature
The temperature that displays in the vehicle infor-
mation display can be changed from:
● °F (Fahrenheit)
● °C (Celsius)
Use the OK button to toggle choices.
Language
The language of the vehicle information display
can be changed to: ● English
● French
● Spanish
Use the
buttons and the OK button to
select and change the language of the vehicle
information display.
Key-Linked Settings
The Key-Linked Setting can be turned
ON/OFF/Later using the OK button. It will display
the key synchronized and in use for this vehicle.
Instruments and controls2-19

Factory Reset
The settings in the vehicle information display can
be reset back to the factory default. To reset the
vehicle information display:1. Use the
buttons to select “Set-
tings”, and press the OK button.
2. Select “Factory Reset” using the
but-
tons and press the OK button.
3. Select “YES” to return all settings back to default by pressing the OK button.
2-20Instruments and controls

LIC3248
Instruments and controls2-21
