Light bulbs You may replace the following bulbs by yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb replacement
seems difficult to perform, contact your Lexus dealer.
For more information about replacing other light bulbs, contact your Lexus
dealer.
■ Preparing for light bulb replacement
Check the wattage of the light bulb to be replaced. (  P. 8 0 9 )
■ Removing the engine compartment covers
 P. 6 5 5
■ Turning off the power back door main switch
 P. 7 7
■ Front bulb locations
Vehicles with halogen headlights Headlight high beamHeadlight low beam
Front turn signal light

7104-3. Do-it-yourself maintenance
Replacing light bulbs
■ Headlight high beams (except vehicles with LED headlights)
Unplug the connector while
depressing the lock release.■ Rear bulb locations
Rear turn signal lightBack-up light
Rear side marker light Tail light
Tail light
STEP 1

7114-3. Do-it-yourself maintenance
4
Maintenance and care Turn the bulb base counterclock-
wise.
Replace the light bulb, and install
the bulb base. Align the 3 tabs on the light bulb
with the mounting, and insert.
Turn and secure the bulb base.
Connect the connector. Shake the bulb base gently to
check that it is not loose, turn the
headlight high beams on once and
visually confirm that no light is leak-
ing through the mounting.STEP 2
STEP 3
STEP 4

7124-3. Do-it-yourself maintenance
■ Headlight high beams (vehicles with LED headlights)
Turn the cover counterclockwise
and remove it.
Unplug the connector while pull-
ing the lock release.
Turn the bulb base counterclock-
wise.
Replace the light bulb, and install
the bulb base.
Align the 3 tabs on the light bulb
with the mounting, and insert.STEP 1
STEP 2
STEP 3
STEP 4

7134-3. Do-it-yourself maintenance
4
Maintenance and care Turn and secure the bulb base.
Connect the connector. Shake the bulb base gently to
check that it is not loose, turn the
headlight high beams on once and
visually confirm that no light is leak-
ing through the mounting.
Turn the cover clockwise.STEP 5
STEP 6

7144-3. Do-it-yourself maintenance
■ Halogen headlight low beams (if equipped)
Turn the bulb base counterclock-
wise.
Unplug the connector while
depressing the lock release.
Replace the light bulb, and install
the bulb base. Align the 3 tabs on the light bulb
with the mounting, and insert.
Turn and secure the bulb base.
Shake the bulb base gently to
check that it is not loose, turn the
headlight low beams on once and
visually confirm that no light is leak-
ing through the mounting.STEP 1
STEP 2
STEP 3
STEP 4
