2015 LEXUS RX450h ignition

1
2
3
4
5
6
7
31-8. Safety information
Correct driving posture ............. 130
SRS airbags ..................................... 132
Front passenger occupant
classification sy stem .................. 145
Child restraint systems ............... 150
Installing child re straints ............. 154
2-1. Driving procedures
Driving the vehicle ........................ 166
Power (ignition) switch ................ 177
EV drive mode ............................... 183
Hybrid transmission ..................... 186
Turn signal lever ............................ 193
Parking brake ................................. 195
Horn.................................................... 196
2-2. Instrument cluster
Gauges and meters ..................... 197
Indicators and warning
lights................................................. 201
Multi-information display.......... 206
Head-up display ............................ 212
2-3. Operating the lights and
windshield wipers
Headlight switch ............................. 217
Fog light switch .............................. 221
Windshield wipers and
washer............................................ 223 Rear window wiper and
washer ........................................... 229
Headlight cleaner switch ........... 231
2-4. Using other driving systems
Cruise control ............................... 232
Dynamic radar cruise
control............................................ 236
Intuitive parking assist ................ 248
Rear view monitor system
(rear view mirror-attached
type) ............................................... 258
Rear view monitor system
(vehicles with the Lexus
Display Audio system) ............ 266
Driving assist systems................... 271
Hill-start assist control ............... 276
Pre-Collision System.................. 278
BSM (Blind Spot Monitor) ....... 286
2-5. Driving information
Utility vehicle pre cautions ........ 292
Cargo and luggage ..................... 296
Vehicle load limits ......................... 301
Winter driving tips ....................... 302
Trailer towing (AWD models
with towing package) ............. 306
Trailer towing
(without towing package)...... 323
Dinghy towing ............................... 3242
When driving

14Pictorial index Instrument panelHeadlight switch
Turn signal lever
Fog light switch P. 217
P. 193
P. 221
Windshield wipers and washer switch
Rear window wiper and washer switch P. 223
P. 229Power back door main
switch P. 77
Tilt and telescopic steering control switch P. 105Power (ignition) switch P. 177
Hood lock release
lever P. 651 Gauges and meters
Multi-information display P. 197
P. 206
Glove box P. 586
Horn P. 196
Parking brake pedal P. 195

1221-6. Refueling
CAUTION■
When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do so may
result in death or serious injury. ●
After exiting the vehicle and before opening the fuel door, touch an unpainted
metal surface to discharge any static electricity. It is important to discharge static
electricity before refueling because sparks resulting from static electricity can
cause fuel vapors to ignite while refueling.●
Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened. Wait until
the sound cannot be heard before fully re moving the cap. In hot weather, pressur-
ized fuel may spray out of the filler neck and cause injury.●
Do not allow anyone that has not discharged static electricity from their body to
come close to an open fuel tank.●
Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.●
Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.●
Do not return to the vehicle or touch an y person or object that is statically
charged.
This may cause static electricity to build up , resulting in a possible ignition hazard.■
When refueling
Observe the following precautions to prevent fuel overflowing from the fuel tank: ●
Securely insert the fuel nozzle into the fuel filler neck●
Stop filling the tank after the fuel nozzle automatically clicks off●
Do not top off the fuel tank
■
When replacing the fuel cap
Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle.
Doing so may cause a fire or other incident which may result in death or serious
injury.

When driving
2
1652-1. Driving procedures
Driving the vehicle.................. 166
Power (ignition) switch .......... 177
EV drive mode.......................... 183
Hybrid transmission ............... 186
Turn signal lever ....................... 193
Parking brake ........................... 195
Horn ............................................ 196
2-2. Instrument cluster
Gauges and meters ................ 197
Indicators and warning
lights ......................................... 201
Multi-information display .... 206
Head-up display ...................... 212
2-3. Operating the lights and
windshield wipers
Headlight switch...................... 217
Fog light switch ........................ 221
Windshield wipers and
washer ................................... 223
Rear window wiper and
washer .................................... 229
Headlight cleaner switch...... 231 2-4. Using other driving
systems
Cruise control......................... 232
Dynamic radar cruise
control .................................... 236
Intuitive parking assist .......... 248
Rear view monitor system
(rear view mirror-attached
type) ........................................ 258
Rear view monitor system
(vehicles with the Lexus
Display Audio system) ....... 266
Driving assist systems ............. 271
Hill-start assist control .......... 276
Pre-Collision System ............ 278
BSM
(Blind Spot Monitor) .......... 286
2-5. Driving information
Utility vehicle
precautions ........................... 292
Cargo and luggage ............... 296
Vehicle load limits ................... 301
Winter driving tips ................. 302
Tr a i l e r t o w i n g ( AW D m o d e l s
with towing package)......... 306
Trailer towing (without
towing package).................. 323
Dinghy towing ......................... 324

1772-1. Driving procedures
2
When driving Power (ignition) switch Performing the following operations when carrying the electronic key on
your person starts the hybrid system or changes “POWER” switch modes.
■ Starting the hybrid system
Check that the parking brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal. The “POWER” switch indicator will turn green. If the indicator does
not turn green, the hybrid system cannot be started.
Press the “POWER” switch. After a while, the “READY” indi-
cator comes on with a beep
sound.
The vehicle can move when the
“READY” indicator is on even if
the engine is stopped.
Continue depressing the brake
pedal until the hybrid system is
completely started.
The hybrid system can be
started from any “POWER”
switch mode.
Check that the “READY” indicator is on.
The vehicle will not move when the “READY” indicator is off.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

8046-1. Specifications
Cooling system
* : With towing package
Ignition systemCapacity
Gasoline engine
Power control unit 12.0 qt. (11.4 L, 10.0 Imp. qt.)
12.4 qt. (11.7 L, 10.3 Imp. qt.)*
1.9 qt. (1.8 L, 1.6 Imp. qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili-
cate, non-amine, non-nitrite, and non-borate cool-
ant with long-life hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
Gap DENSO FK20HR11
0.043 in. (1.1 mm)
NOTICE■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

864Alphabetical index
Engine
Accessory mode ................................. 177
Compartment .....................................654
Hood......................................................... 651
How to start the hybrid
system .................................................... 177
Identification number....................... 799
If the hybrid system will
not start ................................................777
Ignition switch........................................ 177
Overheating.........................................788
“POWER” switch ................................ 177
Engine compartment cover .............655
Engine coolant
Capacity ................................................ 804
Checking ...............................................659
Preparing and checking
before winter .................................... 302
Engine coolant temperature
gauge....................................................... 197
Engine oil
Capacity .................................................802
Checking ...............................................656
Preparing and checking
before winter .................................... 302
EPS ...............................................................271
EV drive mode ........................................ 183
Event data recorder ............................... 25 Floor mat ................................................... 610
Fluid
Brake .......................................................806
Washer................................................... 663
Fog lights
Replacing light bulbs ....................... 708
Switch .........................................................221
Wattage .................................................809
Footwell light .......................................... 582
Front fog lights
Replacing light bulbs ....................... 708
Switch .........................................................221
Wattage .................................................809
Front passenger occupant
classification system ...........................145
Front passenger's seat belt
reminder light ..................................... 736
Front seats
Adjustment .............................................. 86
Driving position memory ..................93
Flattening seatbacks ............................87
Front side marker lights
Replacing light bulbs ....................... 708
Front turn signal lights
Replacing light bulbs ....................... 708
Wattage .................................................809F

866Alphabetical index
I/M test ...................................................... 647
Identification
Electric motor ..................................... 800
Engine .................................................... 800
Vehicle .................................................... 799
Ignition switch........................................... 177
Illuminated entry system ....................582
Immobilizer system ............................... 124
Indicator lights......................................... 201
Initialization
Items to initialize ................................. 837
Inside rear view mirror ........................ 107
Instrument panel light control
buttons .................................................... 198
Interior lights
Interior lights.........................................582
Switch ......................................................583
Wattage................................................. 809
iPod* ................................................. 391, 501
Jack
Positioning a floor jack.................... 652
Vehicle-equipped jack ................... 764
Jack handle .............................................. 764 Keyless entry ............................................. 69
Keys
Electronic key .......................................... 51
If the electronic key does not
operate properly.............................. 781
If you lose your keys ........................ 780
Key number............................................... 51
Keyless entry............................................69
Keys............................................................... 51
Mechanical key ......................................52
“POWER” switch .................................177
Wireless remote control key...........69
Lexus Display Audio controller...... 328
Lexus Display Audio system............ 328
Lexus Enform with
Safety Connect*
Light bulbs
Replacing .............................................. 708
Wattage .................................................809
Lights
Door courtesy lights ........................ 582
Emergency flasher switch.............. 724
Fog light switch .....................................221
Hazard light switch ........................... 724
Headlight switch ...................................217
Interior light switch ........................... 583
Luggage compartment light ........... 77
Outer foot lights................................. 582
Overhead courtesy light ............... 582
Personal light switch ........................ 583
Replacing light bulbs ....................... 708
Scuff lights ............................................. 582I
J K
L
