2015 INFINITI QX60 Quick Reference Guide

15
REVERSE TILT-DOWN FEATURE (if so equipped)


The reverse tilt-down feature will turn both outside mirror surfaces downwa\
rd to provide
better rear visibility close to the vehicle.
1. Apply the brake.
2. Push the ignition switch to the ON position.
3. Move the shift lever to the R (REVERSE) position.
4. The outside mirror surfaces move downward. (The mirror control switch
1 must be out
of the center (neutral) position.)

The outside mirror surfaces will return to their original positions when\
one of the following
conditions has occurred:
• The shift lever is moved to any position other than R (REVERSE).
• The outside mirror control switch
1 is set to the center (neutral) position.
• The ignition switch is pushed to the OFF position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Starting/Stopping the Engine

It is important to make sure the INFINITI Intelligent
Key is with you (that is, in your pocket or purse).

Depress the brake pedal.

Press the ignition switch START/STOP button to
start the engine.
TURNING THE ENGINE OFF

Move the shift lever to the P (PARK) position and
apply the parking brake.

Press the ignition switch START/STOP button to turn the engine off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1923535_15c_Infiniti_QX60_QRG_061815.indd 156/18/15 2:16 PM

16
Headlight Control Switch
HEADLIGHT CONTROL

Turn the headlight control switch to the
position
1 to turn on the front parking, tail, license
plate and instrument panel lights. Turn the switch to
the
position
2 to turn on the headlights.
AUTOLIGHT SYSTEM

The autolight system will automatically turn the headlights on when it i\
s dark and off when
it is light. The system will keep the headlights on for a period of time\
after you turn the
ignition off and all doors are closed.

To activate the autolight system, turn the headlight control switch to t\
he AUTO position
3
then push the ignition switch to ON. To deactivate the autolight system, turn the headlight
control switch to the OFF,
position 1 or
position
2.
HIGH BEAM SELECT

Push the headlight control switch forward
4 to
select the high beam function. The blue indicator
light
illuminates in the instrument panel. Pull
the headlight switch back to the original position
to select the low beam. The blue indicator light
will extinguish.

Pull and release the headlight control switch
5
to flash the headlight high beams on and off.
FOG LIGHT SWITCH

The headlights must be on and the low beams

selected for the fog lights to operate.

Turn the switch (inside collar) to the position
6
to turn the fog lights on.

Turn the switch (inside collar)
to the OFF position to turn the fog lights off.
LANE CHANGE SIGNAL

Move the lever up or down until the turn signal begins to flash but the \
lever does not latch
to signal a lane change. Hold the lever until the lane change is complet\
ed.

Move the lever up or down until the turn signal begins to flash but the \
lever does not latch,
and release the lever. The turn signal will automatically flash 3 times.\


Choose the appropriate method to signal a lane change based on the road \
and
traffic conditions.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
3
4
6
1
5
2
first drive features
1923535_15c_Infiniti_QX60_QRG_061815.indd 166/18/15 2:16 PM

17
Windshield Wiper and Washer Switch
Move the lever to one of the following positions to
operate the windshield wipers:

1 Mist (MIST) – One sweep operation of the
front wipers.

2 Auto (AUTO) – Operates the speed-sensing
and rain-sensing (if so equipped) front
wipers intermittently. To increase or decrease
wiper sensitivity, twist the control ring
3.

4 Low (LO) – Front wipers operate at a
continuous low-speed.

5 High (HI) – Front wipers operate at a
continuous high-speed.

6 Pull the lever toward you to activate the
front washer. The front wipers will operate
several times.
REAR WINDSHIELD WIPER AND WASHER

7 Intermittent (INT) – Rear wiper operates
intermittently.

8 Low (ON) – Rear wiper operates at a
continuous low-speed.

9 Push the lever forward to activate the
rear washer. The rear wiper will operate
several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
MIST
OFFAUTO LO
HI
INT
ON
1
2
4
6
7
8
5
9
3
1923535_15c_Infiniti_QX60_QRG_061815.indd 176/18/15 2:16 PM

18
first drive features
Automatic Climate Controls
1 AUTO BUTTON

The auto mode may be used year-round. Press the AUTO button to turn the system on.
The system will automatically control the inside temperature (automatic\
cooling and/or
dehumidified heating), air flow distribution and fan speed.
2 CLIMATE BUTTON

Press the CLIMATE button to adjust your automatic climate controls using the climate
settings on the control panel display screen.
3 DRIVER’S SIDE TEMPERATURE CONTROL BUTTONS

Press the driver’s side temperature control buttons up for warmer air or down
for
cooler air.
4 DRIVER’S SIDE MANUAL AIR FLOW CONTROL BUTTON

Press the driver’s side manual air flow control button to manually control the driver’s side
air flow modes.

The following air flow modes will display on the control panel display s\
creen:

Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the defroster and foot vents.
5 PASSENGER’S SIDE TEMPERATURE CONTROL BUTTONS

To manually adjust the passenger’s side temperature, press the passen\
ger’s side
temperature control buttons up
for warmer air or down
for cooler air.
6 DUAL BUTTON

Press the DUAL button to turn the passenger’s side temperature controls on or off. This
will allow the passenger’s side temperature to be adjusted independen\
tly from the
driver’s side by pressing the passenger’s side temperature control\
buttons.
7 FAN SPEED CONTROL BUTTONS

Press the left button to decrease the fan speed or press the right
button to
increase the fan speed.
46
89127110112
35
1923535_15c_Infiniti_QX60_QRG_061815.indd 186/18/15 2:16 PM

19
Rear Climate Controls
To activate the system:
1. Turn on the front climate control system by
pressing the AUTO button
1.
2. Press the REAR button

2 on the front control
panel until the Rear Air-conditioning screen
is displayed.
• The indicator light will illuminate.
8 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the defroster button
to turn the system on. The A/C automatically turns on
when the defroster mode is selected. This feature removes humidity from \
the air.

To defrost the front and side windows, set the temperature controls
3 and fan speed
controls 7 to their maximum settings.
9
DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS

Push the rear window defroster button
to turn the system on or off.
This function automatically turns off after approximately 15 minutes.
10 REAR AIR CONDITIONER
To control the rear automatic air conditioning
system with the front air conditioner control panel:
1. Turn on the front climate control system by
pressing the AUTO button
1.
2. Press the REAR button.

When the rear automatic air conditioning system
is on, the indicator light on the REAR button will
illuminate and the front display will switch to the Rear Air-conditioning screen. Use the
driver’s temperature and fan speed buttons to adjust the settings.

To adjust the front air conditioning system, press the REAR button again.

To turn off the rear automatic air conditioning system from the front co\
ntrols, press
the REAR button until the Rear Air-conditioning screen is displayed. Then press the
OFF button.

The rear control buttons will not function when the Rear Air-conditioning screen is
shown on the front display.
11 AIR RECIRCULATION BUTTON

Press the intake air control button to recirculate interior air inside the vehicle. The indicator light on the button will illuminate. This system is used to a\
void certain
outside odors and to help adjust the inside vehicle temperature more eff\
ectively.

The air recirculation mode cannot be activated when the climate control \
system is in the
front defroster mode

.

Press the intake air control button again to change the air circulation from the
intake air to the outside air. The
indicator light on the button will turn off.
12 OFF BUTTON
Press the OFF button to turn the climate control system off.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
21
1923535_15c_Infiniti_QX60_QRG_061815.indd 196/18/15 2:16 PM

20 • The OFF
3, Fan Speed 4, Temperature 5
and AUTO
6 but tons will now control the rear
climate control system.
3. Press the REAR button

2 again, and the screen
will return to what was previously displayed.
• The indicator light will stay illuminated to
indicate that the rear climate control system
is active.

OFF button
3 – Turns of f the rear climate control
system and REAR button indicator light.

Fan speed control but tons
4 – Press
or

to increase or decrease fan speed.

Temperature increase and decrease but tons 5 – Adjust the rear temperature up

or down .

AUTO button
6 – System automatically works to keep air f low and fan speed at a
constant temperature.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
first drive features
21
356
4
FM/AM/SiriusXM®* Satellite Radio with CD/DVD Player (if so equipped)
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB

Press the ON•OFF button to turn the system on or off.

Turn the VOL (volume) control knob right or left to increase or decrease the volume\
.
2 AUDIO BUTTON/TUNE/FOLDER CONTROL KNOB

Press the AUDIO button to access the audio settings screen.

To manually tune the radio, turn the TUNE/FOLDER control knob left or right.
3 SEEK•CAT/TRACK BUTTONS
To scan quickly and stop at the previous or next broadcast station, pres\
s the or
end of the SEEK•CAT/TRACK button.

For satellite radio, press the or end of the SEEK•CAT/TRACK button to switch
to the first channel of the previous or next category.

To change tracks on a CD, press the or end of the SEEK•CAT/TRACK button.
To rewind or fast forward a track on a CD, press and hold the or end of the
SEEK•CAT/TRACK button.
3
6
45
*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional\
satellite radio subscription service.
1923535_15c_Infiniti_QX60_QRG_061815.indd 206/18/15 2:16 PM

21
USB (Universal Serial Bus) Connection Port/iPod® Interface
The USB port
1 is located in the center console
under the arm rest.

When a compatible USB memory device or
iPod® is plugged into the USB port, compatible
audio and video files stored on the device can
be played through the vehicle’s audio system
and front display.
For more information, refer to the “Monitor, climate, audio, phone and
voice recognition systems (section 4)” of your Owner’s Manual.
Conventional (Fixed Speed) Cruise Control
The cruise control system enables you to set a
constant cruising speed once the vehicle has
reached 25 mph (40 km/h).

The system will automatically maintain the set speed
until you tap the brake pedal, accelerate, cancel or
turn the system off.

To activate the cruise control, push the
CRUISE

ON/OFF switch

1. The
CRUISE
indicator light in
the instrument panel will illuminate.

To set a cruising speed, accelerate the vehicle to the desired speed, pu\
sh the COAST/SET
switch
2 and release. The
SET indicator light
in the instrument panel will illuminate. Take
your foot off the accelerator pedal. Your vehicle will maintain the set \
speed.

To reset at a faster cruising speed, push and hold the ACCEL/RES switch 3. When the
vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch 2. Release the
switch when the vehicle slows to the desired speed.
12
3
4
1
4 STATION PRESET BUTTONS

Twelve stations can be set for the FM band, six for the AM band and 18 f\
or
satellite radio.

To store a station in a preset, you must first select a radio band by pr\
essing the FM•AM

5 or XM
6 button then tune to the desired FM, AM or satellite radio station.

Then press and hold the desired station preset button (1-6) until the preset number is
updated on the display and the sound is briefly muted. The channel indic\
ator will then
display, and the sound will resume. Programing is now complete.

To retrieve a previously set station, select the radio band where the pr\
eset was stored
then press the corresponding station select button (1-6).
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
1923535_15c_Infiniti_QX60_QRG_061815.indd 216/18/15 2:17 PM

22
first drive features
Intelligent Cruise Control (ICC) System (if so equipped)
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE

To set Vehicle-To-Vehicle Distance Control mode,
press the CRUISE ON/OFF button
1 for less than
1.5 seconds. The CRUISE indicator light 2
will illuminate.

Accelerate to the desired speed.

Push down on the COAST/SET switch
3 and

release it. Intelligent Cruise Control will be set to
the desired speed.

Press the distance button 4 repeatedly to change
the set distance between long, middle and short.

When a vehicle is not detected ahead of you in
the lane, the set distance and set vehicle speed
indicator lights will illuminate

5 in set mode.

When a vehicle is detected ahead of you in the lane,
the vehicle ahead detection, set distance and set
vehicle speed indicator lights will illuminate
6 in set mode.

To reset at a faster cruising speed, push and hold the ACCEL/RES
switch

7. When the vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch
3.
Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, push the CANCEL switch
8 or tap the brake pedal. The set
vehicle speed indicator
5 will extinguish.
To turn off Intelligent Cruise Control, press the CRUISE ON/OFF button
1. The CRUISE
indicator light
2 in the instrument panel will extinguish.
To set conventional (fixed speed) cruise control mode:

While Intelligent Cruise Control is off, press the CRUISE ON/OFF
button 1
and hold it
down for more than 1.5 seconds. The CRUISE indicator light will illuminate.

Accelerate to the desired speed.

Push down on the COAST/SET switch and release it. The SET indicator light will illuminate.
Cruise control will be set to the desired speed.
To switch between the two cruise control modes:

When one of the two cruise modes is in use, you must turn the system off\
, and then turn it
on again to select the other cruise control mode.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1
43
78
25
6
To cancel the preset speed, push the CANCEL switch
4.

To turn off cruise control, push the CRUISE
ON/OFF switch
1. Both the
CRUISE indicator
light
and the SET indicator light in the instrument panel will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1923535_15c_Infiniti_QX60_QRG_061815.indd 226/18/15 2:17 PM
