Black plate (84,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
84 Infotainment System
3. If autocomplete does not showthe results needed, press the
delete screen button to clear the
autocomplete from the entered
field.
If there are no matches, a
pop-up displays in response to
show how the system
understood the entered text and
attempts to show how the text
could be entered to help find the
destination.
Multiple Matches
.If the search results in multiple
matches, a list of matches is
shown.
.Address search results are
grouped by result type, in the
order of Full Addresses, States,
Cities, Intersections, and
Streets. If no results are found in
a particular group, that group is
not shown. If only one type of
result is found, the single type
result screen is shown. Within
each group, they are listed in
Confidence order. This means
that the closest match result will
be at the top.
.Address searches can be sorted
by Confidence, Distance,
or Alphabetical order.
Spelling Mistakes
The system is able to offer
alternatives if the searched term is
not found exactly. The system uses
the closest term it finds and
provides those results. The system first searches the
entered term exactly. If no matches
are found, partial words are used.
For example, when entering an
address, the system attempts to do
a full match on the entire string. If it
does not find a match, the house
number is then considered an
optional term and the system
attempts to find the street and city
name. The prefix and suffix of street
names are also treated as optional
terms. The search is first done by
trying to match the prefix and/or
suffix. If there is no match found,
these terms are removed from the
search to make the search more
generic.

Black plate (85,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
Infotainment System 85
Places of Interest (POI)
While at the Home Page, press the
Nav screen button to display a view
of the map. Press the Destination
screen button to go to the
destination entry views.
1. Press the POIs screen button todisplay a list of POI categories.
The first list item in every POI
list is a search function. For the
highest level of categories, press
the Spell Name screen button or
select a category and search
within that selection.
2. Select a POI category to display subcategories.
3. If a selected subcategory has no results in the surrounding area,
the search is expanded until a
result is found.
4. When a category is selected, thenearest locations are shown on
the map and it lists the nearest 20 matches. If the limit is
reached and no further matches
display, there is a Show Next
Results button to expand the
search by another 10 results.
The currently selected category
or search term is shown in the
title bar along with the number of
matches shown in the list in
parentheses.
5. Pan the map using the finger gestures to minimize the POI list
and to interact with the map. The
icons that were shown before
continue to be displayed and
updated. The list is also updated
based on where the map was
panned or zoomed. The search
for POIs is constrained to where
the map has been moved to.
Press the list reveal button,
which is the arrow pointing right,
near the left edge of the screen,
to display the list again.
6. If the search map is pressed to recenter, the crosshairs are
shown to indicate the center
of the new search location.

Black plate (86,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
86 Infotainment System
If a POI icon is pressed on while
in the full expanded map, a
callout for that location displays.
Press the callout to display the
destination details view.
7. Press the map reset button to return the map to automatic
zooming and searching. It is
recentered around the vehicle’s
position, the route, the
destination, or another location
that was specified for the
search. The map RESET button
is only displayed if the map was
manually adjusted.Press the List All screen button to
display all of the matching results in
a particular category with its
subcategories.
Using the Keyboard
The POI can be searched by
entering a POI name, category,
name and category, or phone
number on the keyboard.
For example, enter the
information as:
POI Name: Worldwide Food
POI Category: Restaurants
POI Name and Category:
Worldwide Food Restaurants
POI Phone Number: 0001222555
Additionally, a location may be
entered if the POI is not nearby.
This search will then be made
around the location that is given. For example, enter the
information as:
POI Name and Location:
Worldwide Food Chicago IL
The POI keyboard search results
will display in the order in which
they were found. Press the Sort
button to change the sorting order
by Confidence, Alphabetical,
or Distance.

Black plate (87,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
Infotainment System 87
POI Search Location
If browsing for POIs or searching for
results on a keyboard in a different
location than what was searched
previously, press the Search
Options button to specify a different
location.
If not under route guidance, the
search area options are:
.Nearby (default)
.Another Location
If under route guidance, the search
area options are:
.Along Route (default)
.Nearby
.Near My Destination
.Another Location
Favorite POIs
Locations, categories, or a particular
POI chain ID can be saved as
Favorites in the POIs view.
Press and drag up on the row of
Interaction Selector buttons to
reveal the Favorite buttons. Press and hold on a favorite
location, then press on the category
to be saved. Whenever a set of
POIs is grouped, as in a category or
a set of POIs that all belong to the
same chain ID, the whole category
or chain ID is saved in the favorites
for recall. Whenever a set of POIs
that belong to the same chain ID is
saved in the favorites, a POI chain
saving pop-up message displays
asking to save only that location,
or to save the entire chain.
POIs are only grouped by chain
when the sorting order is
Alphabetical.
A POI search can also be saved as
a favorite. While in the POI search
keyboard view, press and hold on a
favorite location and the text that is
currently typed in the keyboard will
be saved.
Press the Sort button to change the
sorting order.

Black plate (88,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
88 Infotainment System
Recalling a POI Category or
Chain
If a POI category or chain favorite is
recalled, the system displays a list
of matching results defaulting to
Nearby, but allows a search of other
locations. Press the Search Options
button to specify a different location.
Creating and Downloading
Predefined POIs (My POIs)
In addition to the POIs already
stored in the infotainment system,
predefined POIs can be created.
While creating a predefined POI, the
GPS coordinates for longitude and
latitude of the POI’s location and a
descriptive name will need to be
entered.
After creating the predefined POIs,
they can be downloaded to the
infotainment system from either a
USB stick or SD card.
Once downloaded, the POI data
becomes a selectable destination in
the My POIs menu.Creating a Text File with
Information
Create a text file by using a simple
text editor software. Save this file
with a name and extension of .csv,
for example,
“TomsPOI.csv.”
Enter the POI information into the
text file in the following format:
.Longitude coordinate, Latitude
coordinate, “Name of POI,”
“Additional information,” “Phone
number.”
Example: 7.0350000,
50.6318040, “Michaels Home,”
“123 Maple Lane,”
“02379234567.”
.The GPS coordinates must be
expressed in decimal degrees
and can be taken from a
geographical map. The
additional information and phone
number strings are optional.
.The POI name and the
additional information string may
not exceed 60 characters.
.POI information for each
destination address must be
entered in a single separate line.
Storing the POI on a USB Drive
In the root directory of a USB drive,
create a folder name “myPOIs”; for
example, “F:\”is the root directory of
the USB drive.
In the “myPOIs” folder, store the text
file with your POIs; for example,
“F:\myPOIs\TomsPOIs.csv.”
Downloading the POI to the
Infotainment System
Connect the USB drive or SD card
containing the POI information to
the USB port or SD card slot of the
infotainment system. A message
displays prompting whether or not to
download the POI information from
the USB stick. All POIs found are
saved even if they are in multiple
folders.
Subfolders can also be created to
organize the POIs into categories;
for example, “F:\myPOIs\
Restaurants\TomsPOIs.csv.”

Black plate (89,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
Infotainment System 89
If the message is dismissed or
ignored, no POI information is
downloaded. This prompt will not
reoccur for the current ignition cycle.
When the system is finished
downloading, a pop-up displays
asking to specify a category for the
new POIs, if desired.Importing and Overwriting
Categories
When POIs are found on a media
device, the date of the file is
examined and compared to the date
for the files already in the system.
If the file being downloaded is
newer than the one in the system,
that particular category of POIs is
overwritten. Any other POIs that had
previously been saved in other
categories are not affected.
Address Book Download
If an Address Book is found on the
connected USB device, the same
alert is used to indicate that
locations have been found and they
can be downloaded. If there is
already content in the vehicle
Address Book, the system prompts
if the stored content should be
overwritten. Select Save to
overwrite the existing Address Book
information. Select Cancel to abort
the import of information.
Browsing Downloaded POIs
Access the downloaded POIs by
selecting the My POIs list item in the
POIs list.
Edit My POIs
Downloaded POIs can be edited at
a category level. These POIs can
either be deleted as an entire
category or reassigned as another
category. To edit the categories:
.Select the EDIT button at the
main category view to edit the
POIs. EDIT buttons display next
to each category name. There is
no POI browsing in this mode;
only edit functions are available.

Black plate (90,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
90 Infotainment System
.Once an action such as deleting
or reassigning has been
selected, the changes are saved
immediately.
Changing POI Categories
POI categories can be assigned to a
different category by using the same
method as assigning a category for
an Address Book entry. When
editing, the right side of the screen
displays the current category name.
Deleting POI
POI categories can be deleted by
selecting Edit and then Delete.
A pop-up displays to confirm the
deletion. Saved Destinations
Select a saved destination from the
Contacts or Recent Destinations.
ContactsSelect the Contacts button to view
the vehicle’
s contact list or a
connected Bluetooth device. Press
the Change Contacts List screen
button to switch between the
vehicle’s contact list and the
Bluetooth device’ s contact list. If a
particular contact has a single
address associated with it, that
contact has a Quick Route list item
function button next to it. Contacts
without this Quick Route button
either have multiple addresses or no address at all. Press the Quick
Route button to go to the
Destination Details view.
Press on an address, either from
the Quick Route on the contact list
or a specific address from the
contact detail list, to go to the
destination view showing that
address on the map.
Trips from Contacts can be saved
and recalled. The order is based on
when the trip was last used. When
the trips are saved, they are given a
default title of the final destination
name. If there are no saved trips,
this list item is hidden.

Black plate (91,1)Cadillac CUE Infotainment System (GMNA-Localizing-U.S./Canada-
7639728) - 2015 - CRC - 9/3/14
Infotainment System 91
Favorite Destinations
.Destinations can be saved as
Favorites for recall later.
Depending on the favorite, when
an address or POI favorite is
recalled, the Destination Details
View is shown.
.When a favorite address is being
routed to, it is shown active.
Press on the active favorite to
suspend that route.
.Save locations as Favorites for
recall later in the Destination
Details View.
.Save trips from the
Address Book.Storing Favorites from the Contact
Details List
A contact name or any of the
contact’
s information such as phone
number, e-mail address, or address
from Contact Details can be stored
as a Favorite.
.Press and drag up on the row of
Interaction Selector buttons to
reveal the Favorite buttons.
.Press and hold on the favorite
location while viewing a contact
on the Contact Details List. The
contact name and all contact
information can be stored.
.Press to save as a favorite. The
favorite label will be the name of
the contact.
.Press on the Favorite to display
the destination view. Storing Favorites from Map
Favorite locations can be stored
from the Map View.
If not under route guidance, the
current vehicle location will be
saved as a Favorite. If under route
guidance, the final destination will
be saved.
Press and drag up on the row of
Interaction Selector buttons to
reveal the Favorite buttons. Press
and hold on the favorite location
from the Map View to save it.
