Instrument s and warning /indicator lights 13
can be switched on for about 30 seconds by
pressing the
I CH ECKi button ¢ fig. 6.
Starting the Auto-Check sequence
The Auto-Check system ¢ page 30 constant­
l y monitors certai n ind iv idual funct ions and
components of the ve hicl e when the ignit ion
is t urned on and when the vehicle is moving.
W ith the ignition turned on, you can start the
"Au to-C hec k seque nce" by p res sing the
I CH ECKi button. Yo u ca n pe rform an A uto­
Check sequence when the vehi cle is stationary
and the ign ition is turned on or when the vehi­
cle is mov ing not faster than
3 mph (5 km/h).
The number of keys progr ammed to the vehi­
cle is also displayed. The disp lay
3 \3 indicates
that th ree keys have been programmed . This
allows yo u to make sure you have rece ived a ll
of the keys when you purchase a used vehicle.
F or exam ple, if you on ly receive two keys, you
should take those keys to your a uth orized
Aud i dea ler to have the miss ing key deactivat­
ed so it cannot be used. You sho uld also re­
port the m issi ng key to your insurance compa­
ny.
Calling up the driver informati on
A yellow or red symbol appears in the instru­
ment cluster display, usua lly w ith a driver
message . T he driver message display disap­
pears after about 5 seconds. The driver mes­
sage can be displayed agai n by briefly press ­
in g the
!CHECK I button.
Setting the speed warning
By pressing the ICHECK I button briefly, yo u
can set thres ho ld 1 of the speed warning
while you are driving
o page 29 . By main­
tain ing press ure on the
I CHECK I button, you
de lete th e warning threshold .
Instrument cluster illumination
The basic brightness of the illumination for
the instruments, the center console and the
display can be adjusted.
Fi g. 7 In strument cluster ill um ination
.,. Press the"+" but ton to in cr ease the b right ­
ness during the hours of darkness.
... Press t he "-" button to dec rease the bright-
ness dur ing the hours of darkness.
A lig ht sensor in the instrument cl uster con­
tro ls t he illumination for the instrument clus­
te r, the center conso le and the displays . In a
bright env ironment, us ing the b uttons to
c hange the brightness has no effect .
{l) Tips
The illumination for the inst rument cluster
lights up w henever you switch on the igni­
tion with the vehicle headlights off. As the
day light fades, the inst rument cluste r illu­
mination l ikewise dims automa tica lly and
will go out comp let ely when the o utsi de
li g ht is very low. T his feature is meant t o
r emi nd you t o switch on t he he adlight s
whe n outs ide lig ht con ditions become
p oor .

34 Driver in formation d isplay
An additional driver message can also be dis ­
p layed by pressing the
! CHECK I button:
Ignit ion lo ck d efec tive. C ontact w ork sh op !
.. Do
not turn the eng ine off .
.. Drive immed iate ly to an authorized Audi
dealer to have the ma lfunction co rrected .
If there is a malfunction in the electronic igni­
tion lock, the ign ition cannot be turned off .
Drive immediately to an authorized Audi dea l­
e r to have the cause of the ma lfunction co r­
rected.
On vehicles w ith Convenience key*, the engine
should not be sw itched off using the
! STOP !
button because the eng ine cannot be started
aga in after the ignition is switched off.
Yellow symbols
Fig. 26 Disp lay: low fuel level warning (p riority 2)
When a yel low warning symbol appears, one
warn ing tone sounds . A dr iver message ap­
pea rs as well to explain the malfunc tion in
mo re deta il. The driver warning goes o ut after
about 5 seconds, but it can be brought up
again at any time by pressing the
I CHECK I but ­
ton .
Chec k the displayed funct ion as soon as poss i­
b le . If
more than one pr iority 2 malfunction is
detected, all symbo ls wi ll appea r one after
the other for about 2 seconds.
Yellow symbols mean: Convenience key*
Key not in vehicle
¢
page 110
USA models: Defect ive
brake light
¢ page 23
Canada model s: Defective
brake light
¢ page 23
Defect ive light bulb
¢ page 23
Light/ra in sensor defective
¢ page35
Windsh ield washer fluid lev­
el low
¢ page35
Low fue l level
¢page 35
Refill Ad Blue *
¢page 252
AdBlue malfunct ion*
¢ page252
Battery vo ltage
¢ page35
Worn brake pads
¢page36
Dynamic headlight range
control defective
¢ page36
Check engine o il level
¢ page 36
Engine o il sensor malf unc­
tion
¢ page 36
Engine speed limitation*
¢page36
Diesel particulate f ilter*
clogged
¢ page36
Adaptive light * defective
¢ poge37
Ign ition lock ma lfunction
¢ page 37

M N
0 ...J
'SI: ,...., \!) 1.1'1 ,...., 1.1'1 ,....,
Windshield wiper defective
¢ page37
Tire pressure monitoring
system
Loss of air pressure
¢ page302
Tire pressure monitoring
system
System not avai lab le
¢page302
Battery in remote contro l
key
¢ page39
Automatic transmission
malfunct io n
¢ page 143
-7e Key not in vehicle
Applies to vehicles: with Convenie nce key
!I Key not in vehicle
This remi nder appea rs along with the !!I sym­
bo l if the maste r key is removed from the ve­
hi cle with the engine running . It is intended
to remind you (e.g . when changing drivers)
not to continue the journey without the mas­
ter key .
I f the master key is no longer in the vehicle,
you cannot switch off the ignition after stop­ p ing the engine and yo u also cannot start the
engine again. What is more, you cannot lock
the vehicle from the outside.
~ o Light/rain sensor defective
II Automatic headlights / autom atic w ipers
d efect iv e
If the symbo l illuminates, the light sensor has
fa iled. For safety reasons the low beams are
turned o n permanently with the switch in
AU­
TO . Howeve~youcancontinuetoturnthe
lights on and off us ing the light switch . In the
case of a defe ct in the ra in senso r, the w ind­
sh ie ld w iper lever f unctions are st ill available .
H ave the light/ra in sensor checked as soon as
possible by an autho rized Audi dea le r.
Dri ver information di spla y 35
O Windshield washer fluid level too low
lffl Please refill w asher fluid
If the symbol illuminates, add w indshie ld
washe r flu id to the washer system and also to
the headlight washer system¢
page 270.
Bu Fuel supply too low
D Please refuel
When this symbol llD illuminates for t he first
time, the fuel reserve in your vehicle is still
betwee n
2.6 and 3 .2 ga llons (1 0- 12 liters).
Ref uel as soo n as poss ib le
¢ page 250.
If the symbol lights up, even when there is
amp le fue l in the tank, and the text
Tank sys­
tem malfun ction
! Contact work shop appears
in the disp lay, there is a fa ult in the system .
C ont act a qua lified wor kshop to have the fault
re ct ified.
0 Battery voltage
If the batte ry's state of charge is not in the
optimal range, the(•) symbol is shown in the
display and the driver message
Low battery
charge: battery will be charged while driving
appears .
While th is driver notification is disp layed, you
have to be prepared for limited starting capa­
bility.
Driver message appear s and goes out
ag ain
If this driver message appears after the ign i­
tion is turned on or while dr iv ing and it goes
out again after a while, the battery has been
adequately recharged .
Driver message appears and d oes not go
out again
If this driver notification appears after the ig­
nition is t urned on o r whi le dr iving and does
not go out again, the batte ry's state of charge
is not in the op tima l range. S tarting capab il ity
is restr icted. Have the ba ttery checked by an
authorized Aud i dea ler as soon as possible.

36 Driver in formation d isplay
(0 ) Worn brake pads
rlJ Br ake pa ds !
If the warn ing light illum inates, immediately
contact your authorized Audi dealer or quali­
fied workshop to have all brake pads inspect­
ed. On USA models the wa rning light
rlJ
comes on together wi th the warn ing ligh t
1111 -Both sets of b rake pads on an axle
must always be replaced at the same time .
A WARNING
Driving with bad brakes can cause a colli­
sion and serious personal injury .
- If the warning light
rlJ and the warning
light
11111 ) with the message B rake
pads !
comes on in the instr ument cluster
display, immediately contact your au­
thorized Aud i dealer or qualified work­
shop to have all brake pads checked or
replaced if necessary .
~(]) Headlight range control
El Head light rang e control d efe ctiv e !
-
If the symbol illuminates, the dynamic head­
light range control is no longer working prop ­
erly . Have the system checked and repaired at
your author ized Audi dealer.
'I=?; , Engine oil level
Ill Pleas e che ck oil l evel
When the symbol illuminates, check the en­
gine o il level as soon as poss ible
¢ page 260 .
Top off the oil at you r earliest oppo rtunity
~ page 261.
't'.:r .., Engine oil sensor defective
• Oil l evel ! Sensor d efe ctive
If the symbol illuminates, contact your au­
thor ized A udi dealer and have the o il sensor
i nspected. Un til you have th is done, check the
l ) - : USA mod els onl y
oil level each time you refue l just to be on the
safe side ¢
page 260.
!?' Engine speed limitation
Applies to vehicles: wit h engine speed li mitatio n
(Pl Do not e xceed ma x. engine speed of
XXXX rpm
The (Pl symbol illuminates when there is an
engine contro l malfunction. The indicator
li ght
GB in the instrument cluster also illumi­
nates. The engine speed is limited to the
speed displayed in the driver informa tion sys­
tem . Keep in mind that the engine speed w ill
not exceed the value d isplayed in the dr iver in­
format ion system, for example when down­
shifting.
Please go to an author ized Audi dealer or oth ­
er qualified workshop to have the malfunct ion
repaired.
~ Diesel particulate filter clogged
Applies to vehicles: wi th diese l eng ine a nd diese l par ticu ­
late filter
II Particulate filt er See o wner' s manua l
When the II symbol illuminates, you can a l­
ter your driving style to ass ist the filter sel f­
cleaning process . Drive for approximately 15
minutes with the selector lever in the S posi ­
t ion at a m inimum speed of 37 mph (60 km/
h) and an eng ine speed of approximately
2,000 RP M. T he temperat ure increase that
will res ult from this can burn off the soo t in
the fi lter . The symbol will switch off when the
cleaning is successful. After a successful
cleaning, there is no need to bring the car to
an authori zed dea ler or qualified workshop
because th is is part of normal vehicle opera­
t ion .
If the symbol
II does not switch off, see your
authori zed dea ler or other qualified workshop
to have the problem corrected.
For more information on the diesel particu­
l ate fi lter, refer to ¢
page 231.

42 Openin g and clo sing
readiness light, located in the upper part of
the driver's door panel, will start to blink.
- T he vehicle interior lights turn off.
Unlocking and l ocking with Conven ience
k ey*
On vehicles which a re equipped w ith the C o n­
ve nience k ey*
authorization system, the
doors are unlocked without a key by means of
a proximity sensor in the door handle. The
doors are simi larly locked without a key using
the locking button. Each door has a proximity
sensor and a locking button .
Automatic l ock ing
The automatic locking feature locks all the ve­
hicle doors and the rear lid when you drive
faster than 9 mph (15 km/h). This function can be turned on and off in the MMI
C entr al
lo cking
Menu c:> page 44.
You can un lock the vehicle from the inside by :
- removing the key from the ign it ion sw itch
(the vehicle will automat ica lly unlock itself)
or
- pressing the unlock part of the power lock
switch @or
- pull ing the door handle (twice to open the
rear doors).
Unintent ionall y locking yourself out
In the following cases there safeguards to
prevent you locking your remote master key in
the vehicle :
- The veh icle does not lock with the power
locking sw itch
c:> page 44 if the driver's
door is open.
- On vehicles with Convenience key* , if the
most recently used master key is in the lug­
gage compartment, the rear lid is automati­
cal ly unloc ked aga in after it is closed.
Do not lock your vehicle with the
r e mot e m as ­
t e r k ey or Convenienc e key*
until all doors
and the rea r lid are closed. In t his way you
avoid locking yourse lf out accidenta lly.
A WARNING
- When you lock your vehicle from outside,
nobody- espec ially children -should re ­
main inside the vehicle . Remember,
when you lock the vehicle from the out­
side the windows cannot be opened from
the inside.
- When you leave the veh icle, always re­
move the ignition key and take it with
you . This will prevent passengers (chil­
dren, for example) from accidentally be ­
ing locked in the vehicle should they acci­
dentally press the power locking switch
in the front doors.
- Do not leave children inside the vehicle
unsupervised. In an emergency it would
be imposs ible to open the doors from
the outside without the key.
(D Tips
- In the event of a crash with airbag de­
ployment all locked doors will be auto­
matically unlocked to give access to the
vehicle occupants from the outside.
- If the power locking system sho uld mal­
function, you can lock each door individ­
ually using the vehicle key
c:> page 45 .
-If the power locking system shou ld fa il,
you can still open the fuel tank flap in an
emergency
c:> page 2 52 .
-You are well advised not to keep va lua­
bles inside an unattended vehicle, v is ible
or not. Even a properly locked vehicle
cannot p rov ide the secur ity of a safe .

50 Openin g and clo sing
When a door is unlocked, the driver 's door is
a lways unlocked as we ll.
It depends on the
settings in the central locking menu in the
MMI whether the entire vehicle is unlocked or
only certain doors ¢
page 44.
{O) Tips
If your vehicle has been stand ing for an ex­
tended period, please note the following:
- The proximity sensors are deactivated af-
ter a few days to save power. You then
have to pull on the door handle once to
unlock the vehicle and a second time to
open the veh icle.
- To prevent the battery from being dis­
charged and to preserve your veh icle's
ability to start for as long as possible,
the energy management system gradu­
a lly switches off unnecessary co nven­
i ence f unct io ns.
It is possible that you
will not be able to unlock your vehicle us­
ing these convenience f unctions.
Locking the vehicle
A ppl ies to vehicles: with Conve nie nce key
The vehicle can be locked without operating
the master key.
Fig . 45 Conve nience key: Lock ing th e ve hicle
.. Move the se lector lever to the P position .
.. Press the locking button in the door handle
to lock the vehicle¢,&.. Do not reach inside
the door handle .
The vehicle can be locked at any door. The au­
thor ized master key on ly has to be within a
range of about 5 feet (1.5 meters) from the
pa rticular door . T
he selec tor lever must be in the P position,
otherwise the ve hicle cannot be locked .
A WARNING
--When you lock yo ur vehicle from o utside,
nobody - espec ia lly children - shou ld re­
main inside the vehicle. Remember,
when you lock the vehicle from the out­
side the wi ndows cannot be opened from
the inside.
- When you leave the veh icle, always re­
move the ign ition key and take it with
you. This will prevent passengers (chil­
d ren, fo r ex ample) from acci dentally be­
i n g lo cked in the vehicle shou ld they acci­
denta lly press the power locking switch
in the front doors.
- Do not leave ch ildren inside the vehicle
unsupervised. In an emergency it would
be impossible to open the doors from
the o utside witho ut the key.
(J} Tips
It i s no t possible to re -open the doo r fo r a
brief pe riod directly after closing it. This
allows you to ensure that the doo rs are
properly locked.
Anti-theft alarm system
The anti-theft alarm triggers an alarm if any­
one attempts to break into the vehicle.
The anti-theft alarm system triggers an audi­
ble ala rm and turns on the emergency flashe r
if an unautho rized interfe rence with the veh i­
cl e is sensed by the sys tem.
How is the anti-theft alarm system
switched on?
T he anti-theft alarm system is switched on
whe n you lock the ve hicle. The system is ac ti­
vated approximate ly 30 seconds after the ve­
hicle is locked. The indicato r ligh t on top o f
the door trim start flashing rapid ly for 30 sec -
onds and then blink slowly. ..,.

60 Clear vision
Clear vision
Lights
Switching the headlights on and off
In the "AUTO" position, a light sensor auto­
matically switches the head -and taillights on
and off in response to light conditions .
Fig. 56 Instrument pane l: lig ht sw it ch
The light switch must not be overturned past
the stops in
either direction.
Switching on automatic headlight control
.,. Turn the light switch to AUTO ¢ fig. 56.
Switching on the side marker lights
... Turn the light switch to :o o:.
Switching on the headlights and high
beam
... Turn the light switch to tD .
... Push the high beam lever forward towards
the instrument panel¢
page 63 .
Switching off the lights
... Turn the light switch to 0.
The headlights only work when the ignition is
switched on. While starting the engine or
when switching off the ignition, the head­
lights will go off and on ly the side marker
lights will be on.
After starting the engine, the headlights are
automatically adjusted* to the load and angle
of the vehicle (for example, during accelera­
tion, braking). This prevents oncoming traff ic
from experiencing unnecessary headlight
glare from your headlights. If the
system is not ope rating properly, a
warn ing symbol in the Auto-Check Control is
displayed
¢ page 36.
With the side marker lights or headlights
switched on, the symbol next to the light
switch i lluminates
:oo :.
Daytime running lights
- USA models :
The daytime running lights
w ill come on automatically when the igni­
tion is turned on and the light switch
¢ fig. 56 is in the O position or the AUTO po­
sition (only in daylight conditions). The
Day­
time running lights
function can be turned
on and off in the MMI menu
Exterior light­
ing
c> page 61.
- Canada models: The daytime running lights
w ill come on automatically when the igni­
tion is turned on and the light switch
¢ fig. 56 is in the O position or the AUTO po ­
sition (only in daylight condit ions) ¢
.&..
Automatic headlight control
In the switch position AUTO the automatic
headlight control
is turned on. The low
beams and tail lights are turned on automati­
cally through
a light sensor as soon as ambi­
ent brightness (e .g . when driving into
a tun­
nel) falls below
a value preset at the factory .
When ambient brightness increases again,
the low beams are turned off again automati­
cally ¢
A.
In the AUTO position the low beams are
switched off automatically when the ignition
is turned off.
Light Sensor Malfunction
In the event of a light sensor malfunction , the
driver is notified in the instrument cluster dis­
play:
£I Automatic headlights / automatic wipers
defective
For safety reasons the low beams are turned
on permanently with the sw itch in
AUTO.
However, you can conti nue to turn the lights
on and off using the light switch . Have the ..,.

light sensor checked as soon as possible at an
authorized Audi dealer or qualified workshop.
A WARNING
- Daytime running lights and automatic
headlights are only intended to assist
the driver. They do not relieve the driver
of his responsibility to check the head­
lights and to turn them on manually ac­
cording to the current light and visibility
conditions. For example, fog cannot be
detected by the light sensors*. So always
switch on the headlights
~D under these
weather conditions and when driving in
the dark.
- Crashes can happen when you cannot see
the road ahead and when you cannot be
seen by other motorists. Always turn on
the headlights so that you can see ahead
and so that others can see your car from
the back.
- Please obey all laws when using the
lighting systems described here.
@ Tips
-With the switch in AUTO front fog lights
and rear fog lights cannot be turned on in addition.
- The light sensor for headlight control is
located in the rear view mirror mount.
You should therefore not apply any stick­
ers to the windshield in this area in order
to prevent malfunctions or failures.
- Some exterior lighting functions can be
adjusted ¢
page 61.
-When you remove your key from the igni­
tion while the vehicle's lights are turned
on, a buzzer sounds as long as the driv­
er's door is open.
- In cool or damp weather, the inside of
the headlights, turn signals and tail
lights can fog over due to the tempera­
ture difference between the inside and
outside. They will clear shortly after
M "' switching them on. This does not affect 0
~ the service life of the lighting.
rl I.O
"' rl
"' rl
Clear vision 61
-In the event of a light sensor malfunc­
tion, the driver is notified in the instru­
ment cluster display¢
page 35.
Adjusting exterior lighting
The functions are set in the MMI.
.,. Select: !CAR ! function button > Systems*
control button > Exterior lighting. Or
.,. Select:
I CAR I function button > Car systems*
control button > Vehicle settings > Exterior
light ing.
Coming home (Lights when leaving car),
Leaving home (Lights when unlocking car)
The coming home function illuminates the
area outside the vehicle when you turn the ig­
nition off and open the driver's door. Depend­
ing on vehicle equipment, the function can be
switched on and off or the length of ti me the lights remain on* can be adjusted .
The leaving home illuminates the area outside
the vehicle when you unlock the vehicle . This
function can be switched on and off .
The Coming home and Leaving home func­
tions only operate when it is dark and the light switch is in the
AUTO position.
Daytime running lights
USA models: The daytime running lights can
be turned on or off using this function.
Canada models: The function cannot be
turned
off. It is activated automatically each
time the ignition is turned on. This menu item is shown "greyed out" .
Front fog lights
Fig. 57 Instrument panel: light switch
