2014 TOYOTA YARIS HYBRID Owners Manual

3778-2. Steps to take in an emergency
8
When trouble arises
Interior
buzzerExterior
buzzerWarning
lightWarning light/Details/Actions
ContinuousContinuous(Flashes in
yellow)
Smart entry & start system indicator light
The electronic key was carried outside the
vehicle and the driver’s door was opened
and closed while any shift position other
than P was selected without turning off the
power switch.
Change the shift position to P.
Bring the electronic key back into the
vehicle.
Once3 times(Flashes in
yellow)
Smart entry & start system indicator light
The electronic key was carried outside the
vehicle and the driver’s door was opened
and closed while the shift position P was
selected without turning off the power
switch.
Turn the power switch off or bring the
electronic key back into the vehicle.
Once3 times(Flashes in
yellow)
Smart entry & start system indicator light
Indicates that a door other than the driver’s
door has been opened and closed with the
power switch in any mode other than off
and the electronic key outside of the detec-
tion area.
Confirm the location of the electronic
key.
OnceContinuous
(5 seconds)
(Flashes in
yellow)
Smart entry & start system indicator light
An attempt was made to exit the vehicle
with the electronic key and lock the doors
without first turning the power switch off.
Turn the power switch off and lock the
doors again.

3788-2. Steps to take in an emergency
Once(Flashes in
yellow for
15 seconds.)
Smart entry & start system indicator light
Indicates that the electronic key is not pres-
ent when attempting to start the hybrid sys-
tem.
Confirm the location of the electronic
key.
9 times(Flashes in
yellow)
Smart entry & start system indicator light
An attempt was made to drive when the
regular key was not inside the vehicle.
Confirm that the electronic key is inside
the vehicle.
Once(Flashes in
yellow for
15 seconds.)
Smart entry & start system indicator light
Indicates that the electronic key battery is
low.
Replace the battery. (P. 335)
Once(Flashes quickly
in green for
15 seconds.)
Smart entry & start system indicator light
Indicates that the steering lock has not
been released.
Release the steering lock. (P. 183)
Once(Flashes in yellow
for 30 seconds.)
Smart entry & start system indicator light
• When the doors were unlocked with the
mechanical key and then the power
switch was pressed, the electronic key
could not be detected in the vehicle.
• The electronic key could not be detected
in the vehicle even after the power switch
was pressed two consecutive times.
Touch the electronic key to the power
switch while depressing the brake
pedal.
Interior
buzzerExterior
buzzerWarning
lightWarning light/Details/Actions

3798-2. Steps to take in an emergency
8
When trouble arises
If you have a flat tire (vehicles with a spare
tire)
Stop the vehicle on a hard, flat surface.
Set the parking brake.
Shift the shift lever to P.
Stop the hybrid system.
Turn on the emergency flashers. (P. 360)
Your vehicle is equipped with a spare tire. The flat tire can be
replaced with the spare tire.
For details about tires: P. 3 1 5
WARNING
If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair, which could result in an accident.
Before jacking up the vehicle

3808-2. Steps to take in an emergency
Location
Location of the spare tire, jack and tool bag
Jack
Spa re ti r e
Tool bag
Jack handleLuggage floor cover
Wheel nut wrench
Towing eyelet1
2
3
4
5
6
7

3818-2. Steps to take in an emergency
8
When trouble arises
WARNING
Using the tire jack
Observe the following precautions.
Improper use of the tire jack may cause the vehicle to suddenly fall off the
jack, leading to death or serious injury.
Do not use the tire jack for any purpose other than replacing tires or install-
ing and removing tire chains.
Only use the tire jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, and do not use other tire jacks for replac-
ing tires on this vehicle.
Put the jack properly in its jack point.
Do not put any part of your body under the vehicle while it is supported by
the jack.
Do not start the hybrid system or drive the vehicle while the vehicle is sup-
ported by the jack.
Do not raise the vehicle while someone is inside.
When raising the vehicle, do not put an object on or under the jack.
Do not raise the vehicle to a height greater than that required to replace
the tire.
Use a jack stand if it is necessary to get under the vehicle.
When lowering the vehicle, make sure that there is no-one near the vehi-
cle. If there are people nearby, warn them vocally before lowering.

3828-2. Steps to take in an emergency
Move the front left seat to the
front most position and remove
the cover.
Take out the jack.
For tightening
For loosening
Taking out the jack
1
2
1
2

3838-2. Steps to take in an emergency
8
When trouble arises
Vehicles with a compact spare tire
Vehicles with a deck board: Lift the deck board and pull it toward
you to remove it. (P. 278)
Remove the luggage floor
cover.
Remove the spare wheel cush-
ion, then loosen the center fas-
tener.
Vehicles with a full-size spare tire
Lift the deck board and pull it toward you to remove it. (P. 278)
Remove the spare wheel cush-
ion, then loosen the center fas-
tener.
Taking out the spare tire
1
2
3
1
2

3848-2. Steps to take in an emergency
Chock the tires.
For vehicles with steel wheels,
remove the wheel ornament
using the wrench.
To protect the wheel ornament,
place a rag between the wrench
and the wheel ornament.
Slightly loosen the wheel nuts
(one turn).
Replacing a flat tire
1
Flat tireWheel chock positions
FrontLeft-hand sideBehind the rear right-hand side tire
Right-hand sideBehind the rear left-hand side tire
RearLeft-hand sideIn front of the front right-hand side tire
Right-hand sideIn front of the front left-hand side tire
2
3
