2014 TOYOTA PRIUS C engine oil capacity

499
6-1. Specifications
6
Vehicle specifications
Hybrid battery (Traction battery)
Lubrication system
*: The engine oil capacity is a reference quantity to be used when changing the
engine oil. Warm up the engine and turn off the hybrid system, wait more
than 5 minutes, and check the oil level on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
TypeNickel-metal hydride battery
Voltage7.2 V/module
Capacity6.5 Ah (3HR)
Quantity 20 modules
Overall voltage 144 V
Oil capacity (Drain and
refill reference*)
With filter
Without filter 3.9 qt. (3.7 L, 3.3 Imp. qt.)
3.6 qt. (3.4 L, 3.0 Imp. qt.)
Outside temperature

500 6-1. Specifications
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allowscold startability. Oils with a lower value before the W allow for easier
starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the oil is at high temperature. An oil with a higher viscosity (one with a
higher value) may be better suited if the vehicle is operated at high
speeds, or under extreme load conditions.
How to read oil container label:
The International Lubricant Spec ification Advisory Committee
(ILSAC) Certification Mark is added to some oil containers to help
you select the oil you should use.
Cooling system
Capacity Gasoline engine
Power control unit 5.6 qt. (5.3 L, 4.7 Imp. qt.)
1.7 qt. (1.6 L, 1.4 Imp. qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life
hybrid organic acid technology
Do not use plain water alone.

516 6-1. Specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of hybrid
transmission, power steering, power brakes,
power windows, power seats, radio and heater,
to the extent that these items are available as
factory-installed equipment (whether installed
or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second co
lumn of Table 1* that
follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1* below

550 Alphabetical index
Engine oilCapacity ................................ 499
Checking ............................... 369
Preparing and checking before winter ....................... 231
Engine/power control unit coolantCapacity ................................ 500
Checking ............................... 373
Preparing and checking before winter ....................... 231
Engine switch ................... 160, 164
EPS ............................................ 221
EV drive mode .......................... 172
Event data recorder ...................18
Exclusive jump starting terminal .................... 481
Floor mat................................... 341
Fluid Brake ..................................... 503
Washer .................................. 378
Fog lights Replacing light bulbs ............. 415
Switch.................................... 208
Wattage ................................. 505
Front fog lights Replacing light bulbs ............. 415
Switch.................................... 208
Wattage ................................. 505
Front passenger occupant
classification system ............ 130 Front passenger’s seat
belt reminder light ................. 439
Front seats Adjustment .............................. 76
Front side marker lights
Replacing light bulbs ............. 415
Switch ................................... 204
Wattage................................. 505
Front turn signal lights Replacing light bulbs ............. 415
Switch ................................... 178
Wattage................................. 505
Fuel Capacity ................................ 498
Fuel gauge ............................ 181
Gas station information ......... 560
Information ............................ 506
Refueling ............................... 105
Type ...................................... 498
Fuel door .................................. 105
Fuel filler door .......................... 105
Fuses ........................................ 404
Gas station information .......... 560
Gauges...................................... 181
Glove box ................................. 325
Hazard lights
Switch ................................... 428
Head restraints
Adjusting ................................ 81
Headlights Replacing light bulbs ............. 415
Switch ................................... 204
Wattage................................. 505
F
G
H

560
GAS STATION INFORMATION
Fuel filler door openerP. 105Tire inflation pressureP. 504Hood lock release lever P. 364
Auxiliary catch leverP. 364Fuel filler doorP. 1 0 5
Fuel tank capacity
(Reference) 9.5 gal. (36 L, 7.9 Imp. gal.)
Fuel type
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Cold tire inflation
pressure
P. 5 0 4
Engine oil capacity
(Drain and refill
 reference)qt. (L, Imp. qt.)
With filter 3.9 (3.7, 3.3)
Without filter 3.6 (3.4, 3.0)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: P. 499
ILSAC GF-5 multigrade engine oil
Recommended oil viscosity: SAE 0W-20
