2014 TOYOTA PRIUS C air filter

TABLE OF CONTENTSIndex
4
3-4. Using the interior lightsInterior lights list ................. 321
• Interior lights/personal lights .................. 322
3-5. Using the storage features List of storage features....... 324
• Glove box ......................... 325
• Console box ..................... 325
• Auxiliary boxes ................. 327
• Cup holders ...................... 329
• Bottle holders ................... 330
3-6. Other interior features Sun visors .......................... 332
Vanity mirrors ..................... 333
Outside temperature display .............................. 334
Power outlet ....................... 336
Seat heaters ....................... 337
Coat hooks ......................... 339
Assist grips ......................... 340
Floor mat ............................ 341
Luggage cover ................... 343 4-1. Maintenance and care
Cleaning and protecting the vehicle exterior ........... 346
Cleaning and protecting the vehicle interior ............ 349
4-2. Maintenance Maintenance requirements .................... 352
General maintenance ......... 355
Emission inspection and maintenance (I/M)
programs .......................... 359
4-3. Do-it-yourself maintenance
Do-it-yourself service precautions ....................... 360
Hood ................................... 364
Positioning a floor jack........ 366
Engine compartment .......... 368
12-volt battery ..................... 379
Tires.................................... 384
Tire inflation pressure ......... 392
Wheels................................ 396
Air conditioning filter ........... 399
Wireless remote control/ electronic key battery ....... 401
Checking and replacing fuses ................................. 404
Light bulbs .......................... 415
4Maintenance and care

246 3-1. Using the air conditioning system and defogger
■Air conditioning filter
P. 399
■ When operating the steering switches
P. 188
■ Customization
The air conditioning control of Eco drive mode can be changed to the same
setting as that used in normal drive mode.
(Customizable features P. 522)
CAUTION
■To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, blocking
your vision.
NOTICE
■To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.

Maintenance and care4
345
4-1. Maintenance and careCleaning and protecting the vehicle exterior ......... 346
Cleaning and protecting the vehicle interior .......... 349
4-2. Maintenance Maintenance requirements .................. 352
General maintenance....... 355
Emission inspection and maintenance (I/M)
programs........................ 359
4-3. Do-it-yourself maintenance
Do-it-yourself service precautions .................... 360
Hood ................................ 364
Positioning a floor jack ..... 366
Engine compartment ........ 368
12-volt battery .................. 379
Tires ................................. 384
Tire inflation pressure ...... 392
Wheels ............................. 396
Air conditioning filter......... 399
Wireless remote control/ electronic key battery ..... 401
Checking and replacing fuses .............................. 404
Light bulbs........................ 415

363
4-3. Do-it-yourself maintenance
4
Maintenance and care
CAUTION
■
Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc. from
getting in your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear
due to dirt in the air.

399
4-3. Do-it-yourself maintenance
4
Maintenance and care
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air
conditioning efficiency.
■ Replacement method
Vehicles without a smart key system
Turn the engine switch to the “LOCK” position.
Vehicles with a smart key system
Turn the “POWER” switch off.
Open the glove box. Slide off
the damper.
Push in each side of the glove
box to disconnect the upper
claws.
Pull out the glove box and dis-
connect the lower claws.
STEP1
STEP2
STEP3
STEP4

400 4-3. Do-it-yourself maintenance
■Checking interval
Inspect and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, more frequent
cleaning or early replacement may be required. (For scheduled maintenance
information, please refer to the “Scheduled Maintenance Guide” or “Owner’s
Manual Supplement”.)
■ If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
NOTICE
■When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the
system.
Remove the filter cover.
Remove the air conditioning
filter and replace it with a new
one.
The “  UP” mark shown on the
filter should be pointing up.
STEP5
STEP6

546
Alphabetical index
Alphabetical index
A/C ............................................. 238
ABS ........................................... 221
Air conditioning filter............... 399
Air conditioning systemAir conditioning filter .............. 399
Automatic air conditioning system ................................ 238
Airbags Airbag operating conditions............................ 120
Airbag precautions for your child ............................ 125
Airbag warning light............... 438
Curtain shield airbag
operating conditions............ 121
Curtain shield airbag
precautions ......................... 125
Front passenger occupant classification system ........... 130
General airbag precautions ......................... 125
Indicators............................... 130
Knee airbag precautions ....... 125
Locations of airbags .............. 116
Modification and
disposal of airbags .............. 129
Proper driving posture ........................ 114, 125
Seat cushion airbag precautions ......................... 125
Side airbag operating
conditions............................ 121
Side airbag precautions ........ 125
SRS airbags .......................... 116 Antenna .................................... 255
Anti-lock brake system ........... 221
Assist grips .............................. 340
Audio input ............... 268, 276, 287
Audio system
Antenna................................. 255
Audio input ............ 268, 276, 287
AUX port ............................... 287
CD player .............................. 256
Cord hook ............................. 272
iPod ....................................... 268
MP3/WMA disc ..................... 261
Optimal use ........................... 284
Portable music player .................. 268, 276, 287
Radio..................................... 254
Steering wheel audio
switch.................................. 288
Type ...................................... 248
USB memory......................... 276
USB port ............................... 276
Automatic air conditioning
systemAir conditioning filter.............. 399
Automatic air conditioning system ................................ 238
AUX port ................................... 287
Auxiliary boxes ........................ 327A
