PETROL INJECTION
Fault finding – Introduction17B
17B-4V12 MR-372-J84-17B000$045.mif
SAGEM 3000
Program No.: A7
Vdiag No.: 44, 48
4. FAULT FINDING PROCEDURE
Check the battery charge and the
condition of the fuses
Print the system fault finding log
(available on CLIP and in the
Workshop Repair Manual or
Technical Note)
Connect CLIP
no
Dialogue with
computer?
yes
Read the faults
no
Faults present
yes
Deal with present faults
Deal with stored faults
no
The cause is
still presentFault
solved
yes
See ALP no. 1
Conformity check
no
The cause is
still presentFault
solved
Use Fault Finding Charts (ALPs)
no
The cause is
still presentFault
solved
Contact the Techline with the
completed fault finding log
JSAA741.0
PETROL INJECTION
Fault finding – Fault Finding Chart17B
17B - 176V12 MR-372-J84-17B000$900.mif
SAGEM 3000
Program No.: A7
Vdiag No.: 44, 48PETROL INJECTION
Fault finding – Fault Finding Chart
ALP 1 No dialogue with the computer
NOTESNone
Test the diagnostic tool on another vehicle in perfect working order.
Check that the sensor's green indicator light comes on.
Communication with the second vehicle is impossible, follow the instructions in the CLIP diagnostic tool check
section.
If you establish dialogue with the second vehicle, follow the instructions in the Vehicle check section.
CLIP
DIAGNOSTIC
TOOL CHECK
CLIP VEHICLE
CHECK
Check the cleanliness and condition of the diagnostic socket contacts which
connect to the vehicle.
Check the condition of the cable from the diagnostic socket to the sensor, and the
cleanliness and condition of the connections.
Check the sensor connections.
Check the condition of the cable from the sensor to the CLIP tool, and the
cleanliness and condition of the connections.
Check the cleanliness and condition of the CLIP socket.
If the fault is still present, contact Techline.
Check the electrical voltage of the battery.
Check the cleanliness and condition of the battery terminals.
Check the condition and tightness of the cable going from the battery + terminal to
the Protection and Switching Unit.
Check the condition of the battery earth cable and ensure that there is a good
electrical connection with the bodywork.
Check the injection computer earth terminal for cleanliness and make sure it is
properly connected to the bodywork.
Check the Protection and Switching Unit's main 30A power supply fuse, plus the
condition and cleanliness of the contacts (see Protection and Switching Unit fault
finding).
Check the injection computer after ignition feed 5A fuse, plus the condition and
cleanliness of the contacts.
AFTER REPAIRRepeat the conformity check from the start.
JSAA741.0
