2014 HONDA CROSSTOUR Owners Manual

488
uuReplacing Light BulbsuFront Side Marker Light Bulb
Maintenance
Front Side Marker Light BulbWhen replacing, use the following bulbs.
1.Turn the steering wheel all the way to the
opposite side from the light being replaced.
Passenger side: Turn the steering wheel
to the left.
Driver side: Turn the steering wheel to the
right.
2.Remove the holding clips and screw, and
pull the inner fender back.
3.Turn the socket to the left and remove it,
then remove the old bulb.
4.Insert a new bulb.Front Side Marker Light: 5 W
1Front Side Marker Light Bulb
Remove the clip by using a flat-tip screwdriver.
2Low Beam Headlights P. 485
Holding Clip
Screw
Bulb
Socket

489
uuReplacing Light BulbsuFront Turn Signal/Parking Light BulbsContinued
Maintenance
Front Turn Signal/Parking Light BulbsWhen replacing, use the following bulbs.
1.Unlock the holding clips, then remove the
upper part of the air intake duct and the air
intake tube.
1.Remove the engine coolant reservoir.Front Turn Signal/Parking: 24/2.2CP
Tube Holding Clip
Holding Clip
Driver side6-cylinder modelsPassenger sideAll models

490
uuReplacing Light BulbsuBrake/Taillights, Back-Up Light, Rear Turn Signal Light and Rear Side Marker Light Bulbs
Maintenance
2.Turn the socket to the left and remove it.
3.Push in the old bulb, rotate to the left until
it unlocks, and remove.
4.Insert new bulb.
Brake/Taillights, Back-Up Light, Rear Turn Signal Light and Rear Side Marker Light BulbsWhen replacing, use the following bulbs.
1.Pry on the edge of the cover using a flat-tip
screwdriver to remove the covers.
uWrap the flat-tip screwdriver with a cloth
to prevent scratches.
Bulb Socket
Brake/Taillight: 21/5 W
Back-Up Light: 21 W
Rear Turn Signal Light: 21 W (Amber)
Rear Side Maker Light: 3 CPCover

491
uuReplacing Light BulbsuBrake/Taillights, Back-Up Light, Rear Turn Signal Light and Rear Side Marker Light Bulbs
Maintenance
2.Use a Phillip-head screwdriver to remove
the bolts.
3.Pull the light assembly out of the rear pillar.
4.Turn the socket to the left and remove it.
Remove the old bulb.
5.Insert a new bulb.
BoltBulb
Socket

492
uuReplacing Light BulbsuRear License Plate Light Bulb
Maintenance
Rear License Plate Light BulbWhen replacing, use the following bulb.
1.Push the left edge of the lens to the right
and pull out the licence light assembly.
2.Push the tabs to remove the lens.
3.Remove the old bulb.
4.Insert a new bulb.High-Mount Brake Light BulbHigh-mount brake light bulbs are LED type. Have an authorized Honda dealer
inspect and replace the light bulbs.Rear License Plate Light: 5 W
Bulb TabTab
Lens

493
Continued
Maintenance
Checking and Maintaining Wiper BladesChecking Wiper BladesIf the wiper blade rubber has deteriorated, it will leave streaks and the metal wiper
arm may scratch the window glass.Changing the Front Wiper Blade Rubber
1.Lift the driver side wiper arm first, then the
passenger side.
2.Pry on the edge of the lock tab using a flat-
tip screwdriver to push it up.
uWrap the flat-tip screwdriver with a cloth
to prevent scratches.
3.Slide the blade from the wiper arm.
1Changing the Front Wiper Blade RubberNOTICEAvoid dropping the wiper arm; it may damage the
windshield.
Lock Tab

494
uuChecking and Maintaining Wiper BladesuChanging the Front Wiper Blade Rubber
Maintenance
4.Slide the wiper blade out from its holder by
pulling the tabbed end out.
5.Remove the retainers from the rubber blade
that has been removed, and mount to a
new rubber blade.
uCorrectly align the rubber protrusion and
the retainer grooves.
6.Slide the new wiper blade onto the holder
from the bottom end.
uThe tab on the holder should fit in the
indent of the wiper blade.
7.Slide the wiper blade onto the wiper arm,
then push down the lock tab.
8.Lower the passenger side wiper arm first,
then the driver side.
BladeTop
Retainer
Blade
Tab
Indent

495
uuChecking and Maintaining Wiper BladesuChanging the Rear Wiper Blade Rubber
Continued
Maintenance
Changing the Rear Wiper Blade Rubber
1.Raise the wiper arm off.
2.Pry on the edge of the lock tab using a flat-
tip screwdriver to push it up.
uWrap the flat-tip screwdriver with a cloth
to prevent scratches.
3.Slide the wiper blade out from the end with
the indent.
1Changing the Rear Wiper Blade RubberNOTICEAvoid dropping the wiper arm; it may damage the
rear window.
Lock Tab
Blade
