Page 3 of 561
2
Quick Reference Guide
Quick Reference Guide
Visual Index
❙System Indicators (P 72)
❙Gauges (P 92)
❙Navigation System *
() See Navigation System Manual
❙Audio System (P 175, 197, 230)
❙POWER Button (P 133)
❙Rear Window Defogger (P 142)
❙Front Seat Heater Switches *
(P 163)
❙ECON Button (P 422)
❙Multi-Information Display (P 94)
❙Heated Mirror Button (P 142)
❙Climate Control System (P 165)
❙Lane Departure Warning (LDW) Button *
(P 441)
❙Hazard Warning Button
❙Audio with Touch Screen *
(P 198, 231)
❙Audio/Information Screen
(P 176, 201, 233)
❙Acoustic Vehicle Alerting System Button *
(P 423)
❙ (Vehicle Stability Assist (VSA ®) System OFF) Button (P 444)
Main Menu
Page 4 of 561
3
Quick Reference Guide
❙(+ / (- / / Buttons (P 174)
❙SOURCE Button (P 174)
❙Bluetooth® HandsFreeLink ® System
Voice Control Buttons (P 333, 370)
❙Navigation System Voice Control Buttons *
(P 239) , () See Navigation System Manual
❙Steering Wheel Adjustments (P 145)
❙SEL/RESET Button (P 95)
❙ (Information) Buttons (P 94)
❙Adaptive Cruise Control (ACC) Buttons *
(P 427)
❙Cruise Control Buttons *
(P 424)
❙Wipers/Washers (P 140)
❙Brightness Control (P 141)
❙ (Select/Reset) Knob (P 141)
❙Horn (Press an area around .)
❙ (Display) Button (P 176, 201, 233)
❙LaneWatchTM
(P 445)
❙Headlights/Turn Signals (P 136)
* Not available on all models
Main Menu
Page 18 of 561
17
Quick Reference Guide
Controls (P 109)
Clock (P 110)
a Enter the Clock Adjustment screen.
2 Adjusting the Clock (P 110)
b Rotate to change hour, then press
.
c Rotate to change minute, then
press .
The navigation system receives signals from
GPS satellites, updating the clock automatically.
Models without navigation system
Models with navigation system
POWER Button (P 133)
Press the button to change the vehicle’s
power mode. Turn Signals (P 136)
Turn Signal Control Lever
Right
Left Lights
(P 136)
Wipers and Washers (P 140)
Light Control Switches
Low Beam High Beam
Flashing
Wiper/Washer Control Lever Adjustment Ring: Long Delay: Short Delay
MIST OFF
INT : Low speed with intermittent
LO : Low speed wipe
HI : High speed wipe Pull toward
you to spray
washer fluid.
*
Not available on all models
Main Menu
Page 20 of 561
19
Quick Reference Guide
Climate Control System (P 165)
● Press the AUTO button to activate the climate control system.
● Press the button to turn the system on or off.
● Press the button to defrost the windshield.
The climate control system is voice operable. (P 239)
Models with navigation system
Driver’s Side
Temperature Control
Buttons
(Rear Window Defogger/Heated Mirror)
Button
(Windshield Defroster) Button
SYNC (Synchronized) Button
Air flows from floor and windshield
defroster vents.
Air flows from floor vents.
Air flows from floor and dashboard
vents, and back of the center console.
Air flows from dashboard vents and
back of the center console.
AUTO
Button
(On/Off) Button
(Recirculation) ButtonMODE Control Button
/ (Fan Control) Buttons
A/C (Air Conditioning) Button
Passenger’s Side Temperature Control Buttons
Main Menu
Page 23 of 561
22
Quick Reference Guide
*1: Icons that appear on the screen vary by the source selected.
CD Slot (CD Eject) Button
MENU Button
Interface Dial/ ENTER Button
(Skip/Seek) Icon
*1
(P 230)Models with navigation system
Audio/Information Screen
Audio with Touch Screen
Button
Source *1
VOL (Volume) Knob
(Skip/Seek) Icon *1
Presets*1 (Tune Up) Icon
*1More*1
(Power) Button
(Tune Down) Icon *1
INFO
Button
AUDIO Button
SETTINGS Button
BACK
Button
NAV
Button
PHONE
Button
Main Menu
Page 91 of 561

90
uuIndicatorsuMulti-Information Display Warning and Information Messages
Instrument Panel
MessageConditionExplanation
●
Appears when the washer fluid gets low.●Refill the washer fluid.
2Refilling Window Washer Fluid P. 483
●
Appears when the turn-by-turn direction comes on
the multi-information display.
2 Refer to the Navigation System Manual
●
Appears when the power system temperature is
high.●Your vehicle has less ability to accelerate and may be
harder to start on an incline.
● Park in a safe place, and cool the system down.
2Overheating P. 525
●
Appears when the High Voltage battery temperature is low.●Your vehicle has less ability to accelerate and may be
harder to start on an incline.
● Goes off once you start driving as the High Voltage
battery warms up.
●Appears after the 12-volt battery charging system
indicator comes on.●Your vehicle has less ability to accelerate and may be
harder to start on an incline.
● Contact a dealer immediately.
Canadian models
Main MenuTable of Contents
Page 98 of 561

Continued97
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Shows the average speed in mph (U.S.) or km/h (Canada) since Trip A or Trip B was
reset.
Shows the instant fuel economy as a bar graph in mpg (U.S.) or l/100 km (Canada).
Shows the remaining oil life and Maintenance MinderTM
.
2 Maintenance Minder TM
P. 467
Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada). ■ Adjusting the outside temperature display
Adjust the temperature reading up to ±5°F or ±3°C if the temperature reading seems incorrect.
Shows you turn-by-turn driving directions to your destination linked with the
navigation system *
.
2 Refer to the Navigation System Manual
■Average Speed
■Instant Fuel Economy
■Engine Oil Life
■Outside Temperature
■Turn-by-Turn Directions *
1Average Speed
You can change when to reset the average speed.
2 Customized Features P. 101, 293
1Outside Temperature
The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).
It may take several minutes for the display to be
updated after the temperature reading has stabilized.
Use the multi-information display's customized
features to correct the temperature.
2 Customized Features P. 101, 293
1Turn-by-Turn Directions*
You can select whether the turn-by-turn display
comes on during the route guidance. 2 Customized Features P. 101, 293
* Not available on all models
Main MenuTable of Contents
Page 106 of 561

105
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
*1: Default Setting
*2: Refer to the navigation system manual for complete details.Setup Group Customizable Features Description Selectable Settings
Meter Setup
Fuel Efficiency BacklightTurns the ambient meter feature on and off.On
*1
/Off
Turn by Turn Display *, *2Selects whether the turn-by-turn display comes on
or not during the route guidance.On*1
/Off
Driving
Position
Setup * Memory Position Link
Changes the driver's seat position to a stored setting. On
*1
/Off
Keyless
Access
Setup
Door Unlock ModeChanges which doors unlock when you grab the
driver’s door handle.Driver Door Only *1
/All Doors
Keyless Access Light FlashCauses some exterior lights to blink when you
unlock/lock the doors.On *1
/Off
Keyless Access BeepSets the beeper sound or not when you grab either
front door handle.On *1
/Off
Lighting
Setup Interior Light Dimming
Time
Changes the length of time the interior lights stay on
after you close the doors.
60sec
/30sec *1
/15sec
Headlight Auto Off
Timer Changes the length of time the exterior lights stay
on after you close the driver's door.
60sec
/30sec /15sec *1
/0sec
Auto Light Sensitivity Changes the timing for the headlights to come on. Max/High /Mid *1
/Low /Min
* Not available on all models
