Page 393 of 561
392
uuBluetooth® HandsFreeLink ®uHFL Menus
Features
5.Rotate to select New Voice Tag, then
press .
6. Move or and rotate to select a
contact name, then press .
uThe pop-up menu appears on the screen.
7. Rotate to select Modify, then press .
8. Using the button, follow the prompts to
complete the voice tag.
9. You will receive a confirmation message on
the screen. Rotate to select OK, then
press .
Main MenuTable of Contents
Page 394 of 561
Continued393
uuBluetooth® HandsFreeLink ®uHFL Menus
Features
■To modify a voice tag
1. Press the SETTINGS button.
2. Rotate to select System Settings, then
press .
3. Rotate to select Phonebook Phonetic
Modification , then press .
4. Rotate to select the phone you want to
add phonetic modification to, then press
.
5. Rotate to select a contact name you
want to modify, then press .
uThe pop-up menu appears on the screen.
6. Rotate to select Modify, then press .
7. Using the button, follow the prompts to complete the voice tag.
8. You will receive a confirmation message on
the screen. Rotate to select OK, then
press .
1Phonebook Phonetic Modification
You can only modify or delete contact names for the currently connected phone.
Main MenuTable of Contents
Page 395 of 561
394
uuBluetooth® HandsFreeLink ®uHFL Menus
Features
■To delete a modified voice tag
1. Press the SETTINGS button.
2. Rotate to select System Settings, then
press .
3. Rotate to select Phonebook Phonetic
Modification , then press .
4. Rotate to select the phone you want to
delete phonetic modification, then press
.
5. Rotate to select a contact name you
want to delete, then press .
uThe pop-up menu appears on the screen.
6. Rotate to select Delete, then press .
7. Move and rotate to select OK, then
press .
Main MenuTable of Contents
Page 396 of 561
395
uuBluetooth® HandsFreeLink ®uHFL Menus
Continued
Features
■To delete all modified voice tags
1. Press the SETTINGS button.
2. Rotate to select System Settings, then
press .
3. Rotate to select Phonebook Phonetic
Modification , then press .
4. Rotate to select the phone you want to
delete phonetic modification, then press
.
uThe contact name list appears.
5. Move and rotate to select Delete All,
then press .
6. You will receive a confirmation message on
the screen. Rotate to select Yes, then
press .
Connect phone Connect phone Phone#2
Phone#1 Phone#3
Main MenuTable of Contents
Page 397 of 561
uuBluetooth® HandsFreeLink ®uHFL Menus
396
Features
You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, speed dial entries, or
redial.
■Making a Call1Making a Call
Any voice-tagged speed dial entry, phonebook name,
or number can be dialed by voice from most screens.
Press the button and say “Call” and the
phonebook name, phone number, or stored voice
tag.
The maximum range between your phone and
vehicles is 30 feet (10 meters).
Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.
Main MenuTable of Contents
Page 398 of 561
Continued397
uuBluetooth® HandsFreeLink ®uHFL Menus
Features
■To make a call using the imported
phonebook
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate to select Phonebook, then
press .
4. The phonebook is stored alphabetically.
Move to Search.
uYou can use the keyboard on the touch
screen for an alphabetical search.
5. Rotate to select a number, then press
.
uDialing starts automatically.
1To make a call using the imported phonebook
This function is disabled while the vehicle is moving.
However, you can call a stored voice-tagged speed
dial number, phonebook name, or number using
voice commands.2 Limitations for Manual Operation P. 371
2 Speed Dial P. 388
You can use the keyboard on the audio with touch
screen for an alphabetical search.
Main MenuTable of Contents
Page 399 of 561
uuBluetooth® HandsFreeLink ®uHFL Menus
398
Features
■ To make a call using a phone number
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate to select Dial, then press .
4. Rotate to select a number, then press
.
5. Rotate to select , then press .
uDialing starts automatically.
■ To make a call using redial
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate to select Redial, then press .
uDialing starts automatically.
1To make a call using a phone number
This function is disabled while the vehicle is moving.
However, you can call a stored voice-tagged speed
dial number, phonebook name, or number using
voice commands.
2 Limitations for Manual Operation P. 371
2 Speed Dial P. 388
You can use the keyboard on the audio with touch
screen to input numbers.
Select numbers, then to start dialing.
Main MenuTable of Contents
Page 400 of 561

Continued399
uuBluetooth® HandsFreeLink ®uHFL Menus
Features
■To make a call using the call history
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate to select Call History, then
press .
4. Move or to select All, Dialed ,
Received , and Missed .
5. Rotate to select a number, then press
.
uDialing starts automatically.
■ To make a call using a speed dial entry
1. Press the PHONE button.
2. Press the MENU button.
3. Rotate to select Speed Dial, then press
.
4. Rotate to select a number, then press
.
uDialing starts automatically.
1To make a call using the call history
The call history displays the last 20 dialed, received, or
missed calls.
(Appears only when a phone is connected to HFL.)
These icons next to the number indicate the
following:: Dialed calls.
: Received calls.
: Missed calls.
1To make a call using a speed dial entry
Move to select More Speed Dials to view another
paired phone’s speed dial list. You can make a call
from that list using the currently connected phone.
When a voice tag is stored, press the button to
call the number using the voice tag. 2 Speed Dial P. 388
Any voice-tagged speed dial entry, phonebook name
or number can be dialed by voice from any screen.
Press the button and follow the prompts.
