2014 HONDA ACCORD HYBRID Owners Manual

88
uuIndicatorsuMulti-Information Display Warning and Information Messages
Instrument Panel
MessageConditionExplanation
●
Appears for about three seconds when ACC has
been automatically canceled.●You can resume the set speed after the condition that
caused ACC to cancel improves. Press the RES/+
button. 2Adaptive Cruise Control (ACC) *
P. 427
● Appears when you press the MAIN button on the
steering wheel.
2 Adaptive Cruise Control (ACC) *
P. 427
● Appears for a few seconds when you set the power
mode to ON.
—
●Appears if there is a problem with ACC.●Have your vehicle checked by a dealer.
Models with adaptive cruise control
(Green)
(Amber)
* Not available on all models
Main MenuTable of Contents

89
uuIndicatorsuMulti-Information Display Warning and Information Messages
Continued
Instrument Panel
MessageConditionExplanation
●Appears when you press the CRUISE button on the
steering wheel.
2 Cruise Control *
P. 424
● Appears if you have set a speed for cruise control.
2 Cruise Control *
P. 424
MessageConditionExplanation
● Flashes when the system senses a likely collision with
a vehicle in front of you.● Take appropriate action to prevent a collision (apply the
brakes, change lanes, etc.).
2Forward Collision Warning (FCW) *
P. 435
2 Adaptive Cruise Control (ACC) *
P. 427
● Appears when your vehicle is too close to the traffic
lane lines. The beeper sounds.● Take appropriate action to keep your vehicle within the
lane lines.
2Lane Departure Warning (LDW) *
P. 439
Models without adaptive cruise control
Models with forward collision warning and lane departure warning
* Not available on all models
Main MenuTable of Contents

90
uuIndicatorsuMulti-Information Display Warning and Information Messages
Instrument Panel
MessageConditionExplanation
●
Appears when the washer fluid gets low.●Refill the washer fluid.
2Refilling Window Washer Fluid P. 483
●
Appears when the turn-by-turn direction comes on
the multi-information display.
2 Refer to the Navigation System Manual
●
Appears when the power system temperature is
high.●Your vehicle has less ability to accelerate and may be
harder to start on an incline.
● Park in a safe place, and cool the system down.
2Overheating P. 525
●
Appears when the High Voltage battery temperature is low.●Your vehicle has less ability to accelerate and may be
harder to start on an incline.
● Goes off once you start driving as the High Voltage
battery warms up.
●Appears after the 12-volt battery charging system
indicator comes on.●Your vehicle has less ability to accelerate and may be
harder to start on an incline.
● Contact a dealer immediately.
Canadian models
Main MenuTable of Contents

91
uuIndicatorsuMulti-Information Display Warning and Information Messages
Instrument Panel
MessageConditionExplanation
●Appears when the High Voltage battery temperature
is too low to operate (approx. -22°F [-30°C] or
below).● You can start the engine and use the climate control
system to warm up the interior, which will also warm
the High Voltage battery enough for you to drive the vehicle.
●Appears when the High Voltage battery and other
system control temperatures are too low to operate
(approx. -40°F [-40°C] or below).● You must wait for an increase in the ambient
temperature or move the vehicle to a warmer location.
● Consult a dealer.
●
Appears if the power system is in diagnostic mode.● You may notice a decrease in availa ble power. Have your
vehicle checked by a dealer.
● As a result of diagnostics, the POWER SYSTEM
indicator may come on. 2POWER SYSTEM Indicator P. 73
●
Appears when you failed to select EV mode or EV
mode is automatically canceled.
● The cause may be shown with the following
message: -Ambient Temperature Too Low
- Battery Charge Too Low
- Engine Too Cold
- Cabin Being Heated
- Speed Too High
- Hard Acceleration Requested●
EV mode is available once the condition is improved or
the cause that canceled EV mode is cleared.
Main MenuTable of Contents

92
Instrument Panel
Gauges and Multi-Information Display
Gauges
Gauges include the speedometer, fuel gauge, POWER/CHARGE gauge, High
Voltage battery charge level gauge, and related indicators. They are displayed when
the power mode is in ON.
Displays your driving speed in mph or km/h.
Displays the amount of fuel left in the fuel tank.
■Speedometer
■Fuel Gauge1Fuel Gauge
NOTICEYou should refuel when the reading approaches .
Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.
The actual amount of remaining fuel may differ from
the fuel gauge reading.E
Main MenuTable of Contents

93
uuGauges and Multi-Information DisplayuGauges
Instrument Panel
■Electric motor
The degree to which the electric motor is being powered is displayed by the readings on the POWER side.
■ Battery charge in progress
The degree to which the High Voltage battery is being charged is displayed by the
readings on the CHARGE side.
Shows the remaining High Voltage battery charge level.
■POWER/CHARGE Gauge
■High Voltage Battery Charge Level Gauge1High Voltage Battery Charge Level Gauge
The High Voltage battery charge level may decrease
under the following conditions:• When the 12-volt battery has been replaced.
• When the 12-volt battery has been disconnected.
• When the High Voltage battery control system
corrects its reading.
The charge level reading will be corrected
automatically while driving.
Changes in the temperature of the High Voltage
battery can increase or decrease the battery’s
charging capacity. If temperature changes cause the
battery’s capacity to change, the number of
indicators in the battery charge level gauge may also
change, even if the amount of charging remains the
same.
Main MenuTable of Contents

94
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
Multi-Information Display
The multi-information display shows the odometer, trip meter, outside temperature
indicator, and other gauges.
It also displays important messages such as warnings and other helpful information. ■Main displays
Press the (information) button to change the display.
■Switching the Display
Average Fuel Economy/
Instant Fuel EconomyRange
Elapsed Time
Average Speed
Blank Screen
Vehicle
Settings Engine Oil
Life
ButtonAverage Fuel
Economy Records
Eco Drive Display
Power Flow
Monitor
Main MenuTable of Contents

95
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
■Lower displays
Press the SEL/RESET button to change the display.
Odometer Trip A Trip B
SEL/RESET
Button
Main MenuTable of Contents
