2014 FIAT QUBO Owners Manual

FIATQUBO
The data contained in this publication is intended merely as a guide. FIAT reserves the right to modify the models and
versions described in this booklet at any time for technical and commercial reasons.
If you have any further questions please consult your FIAT dealer.
Printed in recycled paper without chlorine.
OWNER HANDBOOK
ENGLISH
COP QUBO SISTEMA GB:FIORNO UM GB 14-07-2010 10:49 Pagina 1

We really know your vehicle because we invented,
designed and built it: we really know every single detail. At Fiat Professional Service authorised workshops
you can find technicians directly trained by us, offering quality and professionalism for all service operations.
Fiat Professional workshops are always close to you for the regular servicing operations, season checks and practical
recommendations by our experts.
With Fiat Professional Genuine Parts you keep the reliability, comfort and performance features of your
new vehicle unchanged in time: that's why you bought it for.
Always ask for Genuine Parts for the components used on our vehicles; we recommend them because they come from
our steady commitment in research and development of highly innovative technologies.
For all these reasons: rely on Genuine Parts,
because they are the only ones designed by Fiat Professional for your vehicle.
SAFETY: BRAKING SYSTEMENVIRONMENT: PARTICULATE FILTERS, CLIMATE CONTROL SYSTEM MAINTENANCECOMFORT: SUSPENSION AND WINDSCREEN WIPERS
PERFORMANCE: SPARK PLUGS, INJECTORS ANDBATTERIESLINEACCESSORI: ROOF RACK BARS, WHEEL RIMS
WHY CHOOSING
GENUINE PARTS

CHOOSING GENUINE PARTS
IS THE MOST NATURAL CHOICE
PERFORMANCEGENUINE PARTS
COMFORTGENUINE PARTS
SAFETYGENUINE PARTS
AMBIENTGENUINE PARTS
VALUESGENUINE PARTS
ACCESSORIESGENUINE PARTS

HOW TO RECOGNISE
GENUINE PARTS



All Genuine Parts undergo strict controls, both during design and manufacturing stages,
by specialists using vanguard materials,
to test the component reliability.
This to guarantee performance and safety for you and your passengers on board,
for a long time.
Always ask for and make sure a Genuine Part has been used.

Dear customer,
Thank you for choosing Fiat and congratulations on your choice of a Fiat QUBO.
We have written this handbook to help you get to know all your new Fiat QUBO's features and use it in the best
possible way. You should read it carefully before taking to the road for the first time. You will find information, tips and
important warnings regarding driving your vehicle to help you get the most from the technological features of your FIAT
QUBO.
Read the warnings and indications, marked with the following symbols:
personal safety;car safety;environmental protection.
The enclosed Warranty Booklet lists the services that Fiat offers to its Customers:
❒the Warranty Certificate with terms and conditions for maintaining its validity;
❒the range of additional services available to Fiat Customers.
Enjoy reading. Happy motoring!This Owner Handbook describes all Fiat QUBO versions. As a consequence, you
should only consider the information which is related to the trim level, engine and
version that you have purchased.

READ THIS CAREFULLY!REFUELLING
Diesel engines: only use diesel fuel for motor
vehicles conforming to the European specification
EN 590. The use of other products or mixtures
may damage the engine beyond repair and
consequently invalidate the warranty, depending
on the damage caused.
STARTING THE ENGINEDiesel engines: Turn the ignition key to MAR
and wait for the warning light
to go out.
Turn the ignition key to AVV and release as soon
as the engine starts.
PARKING ON FLAMMABLE MATERIAL
The catalytic converter develops high
temperatures during operation. Do not park the
vehicle on grass, dry leaves, pine needles or
other flammable material as this constitutes a fire
hazard.
RESPECTING THE ENVIRONMENTThe vehicle is fitted with a system that allows
continuous diagnosis of the emission-related
components in order to help protect the
environment.ELECTRICAL ACCESSORIES
If, after buying the vehicle, you decide to add
electrical accessories (with the risk of gradually
draining the battery), visit a Fiat Dealership. They
can calculate the overall electrical requirement
and check that the electrical system of the
vehicle can support the required load.
SCHEDULED SERVICINGCorrect maintenance is essential for ensuring the
vehicle stays in tip-top condition and retains its
safety features, its environmental friendliness and
low running costs for a long time to come.
THE OWNER'S HANDBOOK CONTAINS…... important information, advise and warnings for
correct use, driving safety and maintenance of
your vehicle over time. Particular attention
should be paid to information marked with the
following symbols:
(personal safety),
(environmental protection),
(car integrity).

KNOW YOUR VEHICLE
DASHBOARDThe presence and position of controls, instruments and indicators may vary according to the versions.1. Vent for directing air to the side windows 2. Adjustable air vent 3. Left-hand stalk: exterior lights 4. Instrument panel
and warning lights 5. Right-hand stalk: front and rear windscreen wipers, trip computer 6. Radio (for versions/markets,
where applicable) 7. Emergency light switch, heated rear window switch, ASR/Traction Plus on/off switch (for
versions/markets, where provided), rear swing door lock button (for versions/markets, where provided) 8. Passenger's air
bag (for versions/markets, where provided) 9. Glove box/oddment tray (for versions/markets, where provided)
10. Adjustable air vents 11. Heating/ventilation/climate control system controls 12. Glove compartment 13. Ignition
switch 14. Driver's air bag 15. Bonnet opening lever 16. Controls display: fog light/rear fog light/head light alignment
adjustment/display
fig. 1
F0T0070
3KNOW YOUR
VEHICLESAFETY
STARTING AND
DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
SERVICING AND
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX

INSTRUMENT PANELVersions with multifunction display
Warning lights
and
are available on diesel versions only.
A. Speedometer (speed indicator) B. Fuel level gauge with reserve warning light C. Engine coolant temperature gauge
with overheating warning light D. Rev counter E. Multifunction displayfig. 2
F0T0460
