2014 Citroen DS5 HYBRID4 Owner's Manual

263Checks
DS5-HYBRID_EN_CHAP09_VERIFICATIONS_ED02-2013

DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013
Technical data

DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013

DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013
Range varies according to the ambient climatic conditions, the driving style and conditions, the use of vehicle systems and ageing of the battery.
Electric motor and battery
Electric motor-
Technology Synchronous with permanent magnets.
Max. power: EU standard (kW) * 27
Max. power speed (rpm) 2 500
Max. torque: EU standard (Nm) 200
Max. torque speed (rpm) 1 250
Efficiency (%) 80 to 90
High voltage batteryNi-MH (Nickel Metal Hydride)
Voltage (V~) 200
Energy capacity (kWh / Ah) 1.1 / 5.5
Range (miles (km)) 1.2 (2) (approximately)
* The maximum power corresponds to the value type approved on an engine test bed, under conditions defined by European legislation (directive 1999/99/EC).

267Technical data
DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013
Engine and gearbox
Diesel engineHDi 160 PEF
Gearbox Electronic (6-speed)
Model code RHC
Cubic capacity (cc) 1 997
Bore x stroke (mm) 85 x 88
Max power: EU standard (kW) * 120
Max power engine speed (rpm) 3 850
Max torque: EU standard (Nm) 300
Max torque engine speed (rpm) 1 750
Fuel Diesel
Catalytic converter yes
Particle emission filter yes
Engine oil capacity with filter replacement (in litres) -
* The maximum power corresponds to the type approved value on a test bed, under conditions defined by European legislation (directive 1999/99/EC).

DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013
Diesel engineHDi 160 PEF
Gearbox Electronic (6-speed)
Model code RHC
- Unladen weight -
- Kerb weight * 1 735
- Gross vehicle weight (GV W) 2 265
- Gross train weight (GTW) on a 12% gradient 2 765
- Braked trailer (within GTW limit) on a 10% or 12% gradient 500
- Braked trailer ** (with load transfer with the GTW limit) 800
- Unbraked trailer 500
- Recommended nose weight 75
Weights and towed loads (in kg)
* The kerb weight is equal to the unladen weight + driver (75 kg). ** The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning, towing using a lightly loaded towing vehicle may have an adverse effect on its road holding. To make use of the 300 kg load transfer, the driver must be alone in the vehicle with no luggage in the vehicle.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude. The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country). High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C, limit the towed load.

269Technical data
DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013

Dimensions (in mm)

DS5-HYBRID_EN_CHAP10_CARACTERISTIQUES_ED02-2013
Identifi cation markings Various visible markings for the identification of your vehicle.
A.Vehicle Identification Number (VIN) under the bonnet. This number is engraved on the bodywork near the damper support.
The tyre pressures must be checked when the tyres are cold, at least once a month.
The rear quarter light cannot be etched as it is made of polycarbonate material.
B. Vehicle identification Number (VIN) on the windscreen lower cross member. This number is indicated on a self-adhesive label which is visible through the windscreen.
C. Manufacturer's label. The VIN is indicated on a self-destroying label affixed to the door aperture, on the passenger's side.
D. Tyre/paint label. This label is affixed to the centre pillar, on the driver's side.
It bears the following information: - the tyre inflation pressures with and without load, - the tyre sizes, - the inflation pressure of the spare wheel, - the paint colour code.
The use of snow chains is only authorised on the front wheels. The selector must be in 4WD mode.
If the tyre pressures are too low, this increases fuel consumption.
