2014 Citroen DS5 HYBRID4 Owner's Manual

103Access
DS5-HYBRID_EN_CHAP02_OUVERTURES_ED02-2013
Quality of the fuel used for
Diesel engines
The Diesel engines are per fectly compatible with biofuels which conform to current and future European standards (Diesel fuel which complies with standard EN 590 mixed with a biofuel which complies with standard EN 14214) available at the pumps (containing up to 7 % Fatty Acid Methyl Ester). The B30 biofuel can be used in certain Diesel engines; however, this use is subject to strict application of the special servicing conditions.
Contact a CITROËN dealer or a qualified workshop. The use of any other type of (bio)fuel (vegetable or animal oils, pure or diluted, domestic fuel...) is strictly prohibited (risk of damage to the engine and fuel system).

DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013
Comfort

DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013

DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013
Front seats
Manual
1. Adjustments to the height and angle of the head restraint To raise it, pull upwards. To lower it, press on the lug and the head restraint at the same time. 2. Adjustment of the backrest angle Turn the wheel to adjust the angle of the backrest. 3. Adjustment of the seat height Raise or lower the control lever the number of times required to obtain the desired position. 4. Forwards-backwards adjustment of the seat position Lift the control bar and slide the seat for wards or backwards. 5. Adjustment of the driver's lumbar support Turn the wheel to obtain the desired level of lumbar support.
Before moving the seat backwards, ensure that there is nothing that might prevent the full travel of the seat, so as to avoid the risk of of jamming the seat caused by the presence of objects on the floor behind the seat or rear passengers. If the seat jams, stop the movement immediately.

107Comfort
DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013
Switch on the ignition or start the engine if the vehicle has gone into economy mode. The electric functions of the driver's seat are active for about 45 seconds after opening the front door. They are deactivated about 45 seconds after switching off the ignition and in economy mode.
To reactivate them, switch on the ignition.
Electric
1. Adjustment of the seat cushion angle and height, and forwards-backwards adjustment Raise or lower the front of the control to adjust the seat cushion angle.  Raise or lower the rear of the control to raise or lower the seat.  Simultaneously raise or lower the front and rear of the control in order to raise or lower the entire seat. 2. Adjustment of the backrest angle Move the control for wards or backwards to adjust the backrest angle. 3. Adjustment of driver's lumbar support Press the control switches to obtain the desired level of lumbar support.
4. Manual adjustment of the cushion Pull on the grip to adjust the length of the cushion.
Before moving the seat backwards, ensure that there is nothing that might prevent the full travel of the seat, so as to avoid the risk of of jamming the seat caused by the presence of objects on the floor behind the seat or rear passengers. If the seat jams, stop the movement immediately.

DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013
Storing driving positions
System which stores the electrical settings of the driver's seat and the head-up display settings. It enables you to store up to two positions using the buttons on the side of the driver's seat.
Storing a position using buttons M / 1 / 2
 Switch on the ignition.  Adjust your seat and the head-up display.  Press button M , then press button 1 or 2within four seconds. An audible signal indicates that the position has been stored. Storing a new position cancels the previous position.
Recalling a stored position
 Briefly press button 1 or 2 to recall the
corresponding position. An audible signal indicates the end of the adjustment.
You can interrupt the current movement by pressing button M , 1 or 2 or by using one of the seat controls. A stored position cannot be recalled while driving. Recalling stored positions is deactivated 45 seconds after switching off the ignition.

109Comfort
DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013
The head restraint is fitted with a frame with notches which prevents it from lowering; this is a safety device in case of impact. The adjustment is correct when the upper edge of the head restraint is level with the top of the head. Never drive with the head restraints removed; they must be in place and adjusted correctly.
Head restraint height and
angle adjustment
 To raise a head restraint, pull it upwards.  To remove the head restraint, press the lug A and pull the head restraint upwards. To put the head restraint back in place, engage
the head restraint stems in the openings keeping them in line with the seat back. To lower the head restraint, press the lug A and A and Apush down on the head restraint at the same time.  To adjust the angle of the head restraint, tilt its lower part forwards or rearwards.

DS5-HYBRID_EN_CHAP03_CONFORT_ED02-2013
Massage function
This system provides a back massage. It only operates when the hybrid system is active or in STOP mode of the Stop & Start system.
Activation
 Press this switch.
Its indicator lamp comes on and the massage function is activated for a period of 1 hour. During this time, massage is per formed in 6 cycles of 10 minutes (6 minutes of massage followed by 4 minutes break). After one hour, the function is deactivated, the indicator lamp goes off.
Deactivation
You can deactivate the massage
function at any time by pressing this switch, its indicator lamp goes off.
Heated seats control
With the hybrid system active, the front seats can be heated individually.
 Use the adjustment wheel to switch on and select the level of heating required:
0 : Off. 1 : Low. 2 : Medium. 3 : High.
