2014 Citroen DS5 HYBRID4 Owner's Manual

175Visibility
DS5-HYBRID_EN_CHAP05_VISIBILITE_ED02-2013
1. Front - rear cour tesy lamp2. Front map reading lamp s
3. Rear map reading lamp s 4. Interior mood LEDs
Courtesy lamps
In this position, the courtesy lamp comes on gradually:
Front - rear courtesy lamps
Take care to avoid leaving anything in contact with the courtesy lamps.
With the "permanent lighting" mode, the lighting time varies according to the circumstances: - with the ignition off, approximately ten minutes, - in energy economy mode, approximately thirty seconds, - with the hybrid system active, unlimited.
- when the vehicle is unlocked, - when the electronic key is removed from the reader, - when opening a door, - when the remote control locking button is activated, in order to locate your vehicle.
It switches off gradually: - when the vehicle is locked, - when the ignition is switched on, - 30 seconds after the last door is closed.
Permanently off.
Permanent lighting.
Front - rear map reading
lamps
 With the ignition on, press the corresponding switch.

DS5-HYBRID_EN_CHAP05_VISIBILITE_ED02-2013
Interior mood lighting The dimmed passenger compartment lighting improves visibility in the vehicle when the light is p o o r.
At night, the interior mood lighting comes on automatically when the sidelamps are switched on (for example, a source of light in the roof console illuminates the middle of the centre console). The interior mood lighting switches off automatically when the sidelamps are switched of f.
Lamps on: there are 7 levels of brightness. The level of brightness increases progressively with each press of the button, returning to zero after the maximum level is reached. A long press gives maximum brightness. This adjustment is used to set the mood lighting level for the interior lamp, as well as for the door opening controls and the storage locations (depending on version).

Footwell lighting
Activation
Its operation is identical to that of the courtesy lamps. The lamps come on when one of the doors is opened.
The soft lighting provided by the footwell lamps improves visibility in the vehicle when the light is poor.
Switching on Adjusting the brightness of
the courtesy lamp

177Visibility
DS5-HYBRID_EN_CHAP05_VISIBILITE_ED02-2013

DS5-HYBRID_EN_CHAP06_SECURITE ENFANTS_ED02-2013
Child safety

DS5-HYBRID_EN_CHAP06_SECURITE ENFANTS_ED02-2013

DS5-HYBRID_EN_CHAP06_SECURITE ENFANTS_ED02-2013
General points relating to child seats
For maximum safety, please observe the following recommendations: - in accordance with European regulations, all children under the age of 12 or less than one and a half metres tall must travel in approved child seats suited to their weight , on seats fitted with a seat belt or ISOFIX mountings * , - statistically, the safest seats in your vehicle for carr ying children are the rear seats, - a child weighing less than 9 kg must travel in the "rear ward facing" position both in the front and in the rear.
CITROËN recommends that children should travel in the outer outer outerrear seats of your vehicle: - "rearward facing" up to the age of 3, - "forward facing" over the age of 3.
Although one of CITROËN main criteria when designing your vehicle, the safety of your children also depends on you.
* The rules for carrying children are specific to each country. Refer to the legislation in force in your country.

181Child safety
DS5-HYBRID_EN_CHAP06_SECURITE ENFANTS_ED02-2013
Child seat in the front *
"Rearward-facing" "Forward-facing"
Passenger seat in the fully back and highest position.
Ensure that the seat belt is correctly tensioned.
For child seats with a support leg, ensure that the support leg is in stable contact with the floor. If necessary, adjust the passenger seat.
* Refer to the current legislation in your country before installing a child seat on this seat.
When a "rear ward-facing" child seat is installed on the front passenger seat , adjust the seat to the intermediate longitudinal and highest position, with the backrest straightened. The passenger airbag must be deactivated. Otherwise, the child would risk being seriously injured or killed if the airbag were to inflate .
When a "for ward-facing" child seat is installed on the front passenger seat , adjust the vehicle's seat to the intermediate longitudinal and highest position with seat backrest straightened and leave the passenger's airbag activated.

DS5-HYBRID_EN_CHAP06_SECURITE ENFANTS_ED02-2013
Passenger airbag OFF
For information on deactivating the passenger's front airbag, refer to the "Airbags" section.
The warning label present on both sides of the passenger's sun visor repeats this advice. In line with current legislation, the following tables contain this warning in all of the languages required.
Never install a rear ward facing child restraint system on a seat protected by an active front airbag. This could cause the death of the child or serious injury.
Deactivating the passenger's front airbag
