2014 CHRYSLER 300 Owners Manual

Page 553 of 615

CHRYSLER 300 2014 2.G Owners Manual CavityCartridge Fuse Mini-Fuse Description
19 50 Amp Red –Power Steering #2
20 30 Amp Pink –Wiper Motor
21 30 Amp Pink –Headlamp Washers
22 –– Fuse – Spare
23 –– Fuse – Spare
24 –

Page 554 of 615

CHRYSLER 300 2014 2.G Owners Manual CavityCartridge Fuse Mini-Fuse Description
37 –10 Amp Red Engine Controller/Rad Fan Relays
38 –10 Amp Red Airbag Module
39 –10 Amp Red Power Steering Module/AC Clutch Relay
48 –10 Amp Red AWD

Page 555 of 615

CHRYSLER 300 2014 2.G Owners Manual Rear Power Distribution Center (Fuses)
There is also a power distribution center located in the
trunk under the spare tire access panel. This center
contains fuses and relays.
CAUTION!
•When install

Page 556 of 615

CHRYSLER 300 2014 2.G Owners Manual CAUTION!(Continued)
water to get into the power distribution center and
possibly result in an electrical system failure.
•When replacing a blown fuse, it is important to use
only a fuse having the c

Page 557 of 615

CHRYSLER 300 2014 2.G Owners Manual CavityCartridge Fuse Mini-FuseDescription
7 40 Amp Green —Exterior Lighting #2
8 30 Amp Pink —Interior Lighting/Washer
Pump
9 30 Amp Pink —Power Locks
10 30 Amp Pink —Driver Door
11 30 Amp Pin

Page 558 of 615

CHRYSLER 300 2014 2.G Owners Manual CavityCartridge Fuse Mini-FuseDescription
21 ——Fuse — Spare
22 ——Fuse — Spare
23 —10 Amp Red Fuel Door/Diagnostic
Port
24 —15 Amp Blue Radio Screen
25 —10 Amp Red Tire Pressure Monit

Page 559 of 615

CHRYSLER 300 2014 2.G Owners Manual CavityCartridge Fuse Mini-FuseDescription
36 ——Fuse — Spare
37 —15 Amp Blue Radio
38 —20 Amp Yellow Power Outlet Inside Arm
Rest
40 ——Fuse — Spare
41 ——Fuse — Spare
42 30 Amp Pin

Page 560 of 615

CHRYSLER 300 2014 2.G Owners Manual CavityCartridge Fuse Mini-FuseDescription
48 —20 Amp Yellow Active Suspension
49 ——Fuse — Spare
50 ——Fuse — Spare
51 —20 Amp Yellow Front Heated Seats
52 —10 Amp Red Heated Cupholder
