2014 CHRYSLER 300 Owners Manual

Page 417 of 615

CHRYSLER 300 2014 2.G Owners Manual NOTE:
•P (Passenger) - Metric tire sizing is based on U.S.
design standards. P-Metric tires have the letter “P”
molded into the sidewall preceding the size designa-
tion. Example: P215/65R15 95H

Page 418 of 615

CHRYSLER 300 2014 2.G Owners Manual Tire Sizing Chart
EXAMPLE:
Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15
LT P= Passenger car tire size based on U.S. design standards, or
....b

Page 419 of 615

CHRYSLER 300 2014 2.G Owners Manual EXAMPLE:
R = Construction code
–R means radial construction, or
– D means diagonal or bias construction
15, 16, 18 = Rim diameter in inches (in)
Service Description: 95= Load Index
– A numer

Page 420 of 615

CHRYSLER 300 2014 2.G Owners Manual EXAMPLE:
Load Identification:
Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL)
tire:
•XL = Extra load (or reinforced) tire, or
•LL= L

Page 421 of 615

CHRYSLER 300 2014 2.G Owners Manual EXAMPLE:
DOT MA L9 ABCD 0301
DOT = Department of Transportation
– This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire
safety standards and is approve

Page 422 of 615

CHRYSLER 300 2014 2.G Owners Manual Tire Terminology And Definitions
TermDefinition
B-Pillar The vehicle B-Pillar is the structural member of the body located
behind the front door.
Cold Tire Inflation Pressure Cold tire inflation press

Page 423 of 615

CHRYSLER 300 2014 2.G Owners Manual Tire Loading And Tire Pressure
Tire And Loading Information Placard Location
NOTE:The proper cold tire inflation pressure is listed on
the driver ’s side B-Pillar or the rear edge of the driver’s

Page 424 of 615

CHRYSLER 300 2014 2.G Owners Manual Tire And Loading Information PlacardThis placard tells you important information about the:
1. Number of people that can be carried in the vehicle.
2. Total weight your vehicle can carry.
3. Tire size
