Page 121 of 522
EVIC
MessageEVIC
Message
Display
TimeOdometer
Message
(<5mph
[8 km/h])Odometer
Message
Display
TimeOdometer
Message
(>5mph
[8 km/h])Odometer
Message
Display
TimeChimeConditionOperator
Action
Required
TRUNK
AJAR Continu-
ousDECK Continu-
ousDECK Continu-
ousSingle
Chime
The
Trunk Lid
is Un-
latched or
OpenThe Top
Will Not
Operate
Unless
the Trunk
Lid is
Closed3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119
Page 122 of 522
EVIC
MessageEVIC
Message
Display
TimeOdometer
Message
(<5mph
[8 km/h])Odometer
Message
Display
TimeOdometer
Message
(>5mph
[8 km/h])Odometer
Message
Display
TimeChimeConditionOperator
Action
Required
CON-
VERTIBLE
TOP MAL-
FUNC-
TION 6 sec. TOP FAIL Display
Scrolls
for 6 Sec-
ondsTOP 6 sec. Single
Chime
The
PTCM Ac-
tivated
the Sys-
tem
LOCK-
OUT Fea-
tureRefer to
Foot Note
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 123 of 522
EVIC
MessageEVIC
Message
Display
TimeOdometer
Message
(<5mph
[8 km/h])Odometer
Message
Display
TimeOdometer
Message
(>5mph
[8 km/h])Odometer
Message
Display
TimeChimeConditionOperator
Action
Required
CON-
VERTIBLE
TOP MAL-
FUNC-
TION Until
Fault is
No Lon-
ger De-
tected or
RepairedTOP FAIL
Display
Scrolls un-
til Fault is
No Lon-
ger De-
tected or
RepairedTOPDisplay
Flashes
until Fault
is No Lon-
ger De-
tected or
RepairedSingle
ChimeThe
PTCM Ac-
tivated
the Sys-
tem
LOCK-
OUT Fea-
tureSee your
autho-
rized
dealer for
service
If so equipped.
For vehicles not equipped with the EVIC.
The PTCM will lockout the power convertible top system if the vehicle charging system is malfunctioning, or the
battery is run down, or the hydraulic pump is overheating. In addition, the system prohibits lowering the top when
ambient temperature is at 0°F (-18°C) or lower and raising the top when ambient temperature is below -40°F (-40°C).
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
Page 124 of 522

•If you are trying to lower the top and ambient temperature is 0°F (-18°C) or lower, wait until the temperature rises
and the top is thawed and dry before operating the power top. A soft top should not be lowered at temperatures
below 32°F (0°C).
• If you are trying to raise the top and ambient temperature is below -40°F (-40°C), wait until the temperature rises
before operating the power top.
• If the vehicle charging system is malfunctioning, see your authorized dealer for service.
• If the battery is run down, have it recharged and tested at your authorized dealer.
• Hydraulic pump overheating can occur if you lower and raise the top consecutively (usually more than six or
seven times depending upon the ambient temperature). Wait at least five minutes before operating the power top
again.
NOTE:
If lockout occurs due to hydraulic pump overheating, the system will allow you to raise the top without waiting
five minutes. However, do so only if necessary.
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 125 of 522

Emergency Bypass Mode (To Raise The Top
Only)
This procedure is only to be used to raise the top when
the top cannot be returned to the UP (raised) position by
pressing the POWER TOP switch or is in a position in
which the vehicle cannot be driven. Please follow these
emergency bypass instructions to return the top to the UP
(raised) position.
Press the POWER TOP switch in the Top Up direction
five times within two seconds and hold the switch in the
Top Up position for a minimum of two minutes.
CAUTION!
•Once this procedure has been completed and the
top is in the UP (raised) position, see your autho-
rized dealer.
(Continued)
CAUTION! (Continued)
•DO NOT exceed 40 mph (64 km/h).
• Using the Emergency Bypass Mode could poten-
tially damage the convertible top and should only
be used to raise the power top to the UP (raised)
position when the normal top operation is not
functioning.
If damage starts to occur while in the Emergency Bypass
Mode, immediately release the power top switch and see
your authorized dealer.
NOTE: This procedure may take more time to fully raise
and close the power top. It is not uncommon to see
delays of up to 30 seconds before operation begins.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
Page 126 of 522
MIRRORS
Inside Day/Night Mirror
A two-point pivot system allows for horizontal and
vertical mirror adjustment. Adjust the mirror to center on
the view through the rear window.
Headlight glare can be reduced by moving the small
control under the mirror to the night position (toward the
rear of the vehicle). The mirror should be adjusted while
set in the day position (toward the windshield).
Adjusting Rearview Mirror
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 127 of 522
Automatic Dimming Mirror — If Equipped
This mirror automatically adjusts for headlight glare
from vehicles behind you. You can turn the feature on or
off by pressing the button at the base of the mirror. A light
to the left of the button will illuminate to indicate when
the dimming feature is activated. The sensor to the right
of the button does not illuminate.
NOTE:This feature is disabled when the vehicle is
moving in reverse.
CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Automatic Dimming Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
Page 128 of 522
Power Mirrors
The power mirror control is located on the driver’s door
trim.When finished, return the knob to the center “O” (Off)
position to guard against accidentally moving a mirror
position.
Power Mirror Control
To adjust a mirror, turn the control toward the left or right
mirror positions indicated. Tilt the control in the direction
you want the mirror to move.
Mirror Directions
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
