2013 VOLKSWAGEN TOUAREG steering wheel

Adjusting the steering wheel position

Fig. 49 Manual adjustment for the steering wheel position.

Fig. 50 Behind the steering wheel on the steering column: electrical adjustment for steering wheel.

.WARNING
Improper use of the steering column adjustment feature can result in serious personal injury
and even death.
x Always pull the lever ⇒ fig. 49 (1) firmly upward after adjusting the steering column so that
the steering wheel does not change position suddenly while the vehicle is moving.
x Never adjust the steering column while the vehicle is moving. If you find that you need to
adjust the steering wheel while driving, stop the vehicle in a safe place and make the proper
adjustment.
x Never adjust the steering wheel so that it points toward your face. Always make sure that
the steering wheel points toward your chest. Otherwise, the airbag system cannot protect
you properly in the event of a crash.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands
at the 9 o'clock and 3 o'clock positions to help reduce the risk of serious personal injury if the
driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands anywhere
inside the steering wheel or on the steering wheel hub. Holding the steering wheel the wrong
way increases the risk of severe injury to the arms, hands, and head if the driver front airbag
deploys.
Center armrest

Fig. 51 1 part and 2 part front center armrest.

Storing driver seat settings to the driver door memory buttons
x Apply the electronic parking brake.
x Shift the transmission into neutral.
x Sit on the driver seat and adjust it to the desired position
x Adjust both outside mirrors
x Adjust the steering wheel position
x Press the SET button until the LED lights up (arrow).
x Within about 10 seconds press the desired memory button 1, 2 or 3⇒ fig. 55. The LED will
extinguish and a chime signal will confirm the memory storage.
Storing front passenger seat settings to the front passenger door memory buttons
x Apply the electronic parking brake.
x Shift the transmission into Neutral (N).
x Sit on the front passenger seat and adjust it to the desired position
x Switch on the ignition.
x Press the SET button until the LED lights up (arrow).
x Within about 10 seconds press the desired memory button 1, 2 or 3 The LED will go out and a
chime sounds to confirm that settings have been.
Storing the passenger side outside mirror setting for backing up
x Apply the electronic parking brake.
x Shift the transmission into Neutral (N).
x Switch on the ignition.
x Briefly press the desired memory button 1, 2 or 3 on the driver door.
x Shift the transmission into Reverse (R).
x Adjust the passenger outside mirror, to provide good visibility of the curb for example.
x The mirror position you have set is automatically stored and assigned to the selected memory
button.
The passenger-side outside mirror automatically adjusts back from the position stored for backing up
when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is rotated
from (R) into a different position.
Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x Charging condition of the vehicle battery is weak.
x Repeated pressing of the SET button within about 10 seconds.
x Readjustment of the seat position within about 10 seconds after pressing the SET button.
Recalling stored memory settings
x With the vehicle door open and the ignition off , the stored setting positions can be recalled and set
automatically. For this, tap the corresponding memory button 1, 2 or 3 in the respective vehicle door
briefly. After about 10 minutes, the stored positions can not be set automatically.
x OR: With the vehicle door closed and the ignition .on press and hold the corresponding memory
button on the vehicle door until the stored positions are reached.

.WARNING
Improper use of high beams can distract and blind others, causing accidents and serious
injuries.
.The turn signal light works only when the ignition is switched on. The emergency flasher works
even when the ignition is switched off.
.The indicator light flashes twice as fast if a turn signal bulb is burned out.
.High beams can only be switched on when low beams are on.
Switching lights on and off

Fig. 84 Next to the steering wheel: Light switch.

Function Action
Switching the DRL off: – Switch the ignition on.
– Turn the light switch to the / position.
– Set the parking brake.
Switching the DRL back on: – Release the parking brake.
– OR: Turn the light switch to the  position.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static
cornering lights. On some models the static cornering lights may be integrated in the headlights. At
speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on when you turn
a corner. If you turn to the right, the right fog light comes on; turn left and the left fog light comes on.
The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the !54/ position) ⇒ fig. 84, they work only when the headlights have been
automatically switched on. The static cornering lights do not come on when the headlight switch is in
the O position or when the fog lights themselves have been switched on.
Automatic headlight control AUTO
Automatic headlight control is a convenience feature only and cannot always recognize all driving
situations.
If the light switch is in the !54/ position, the outside vehicle lighting and the instrument lighting are
automatically switched on at dusk/nightfall and off in normal daylight in the following situations ⇒ :

Automatic activation: Automatic deactivation/change to daytime
running lights:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.
If you drive faster than about 87 mph (140 km/h)
for several seconds.
If you drive slower than about 40 mph (65 km/h)
for several seconds.
If the rain sensor recognizes heavy rain and
switches the windshield wipers on.
If the windshield wipers have not moved for
several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
The Adaptive Front Lighting System can be switched on and off in the Infotainment System.
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Assist systemsfunction key on the screen.
x Select the menu item Light Assist (main beam control)from the list.
x Tap Adaptive Front Lighting System (AFS)to enable or disable this feature.

The lights stay on for about 10 seconds (lighting delay period). The “Coming home” and
“Leaving home” functions can be enabled and disabled in the Infotainment System.
If the “Coming home” feature is switched on and the driver door is opened, no acoustic warning
will sound to alert that the light is still on.
Instrument panel lighting , headlight range adjustment

Fig. 85 Next to the steering wheel: Control for instrument cluster lighting.

Safety information on Infotainment System
.WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
x Setting the sound volume too high may damage your hearing. This applies even if you are
exposed to high volumes for short periods only.
.WARNING
The volume level may suddenly get louder change when you switch media source or connect
a new audio source.
x Always lower the base volume before switching media source or connecting a new audio
source.
.WARNING
Driving recommendations and traffic symbols displayed by the navigation system may differ
from the current traffic situation.
x Traffic signs and traffic regulations have priority over the recommendations and displays
provided by the navigation system.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
.WARNING
External devices that are loose in the vehicle or not properly secured could be thrown around
the interior and cause injuries during a sudden driving or braking maneuver, or in a crash.
x Never put or attach an external device on a door, on the windshield or above or near to the
areas marked “AIRBAG” on the steering wheel, the instrument panel and the seat backrests,
or between these areas and the vehicle occupants. External devices could cause serious
injury in an accident, especially when the airbags inflate.

x Briefly press the  button on the multi-function steering wheel.
x Say the voice command in the language set in the Infotainment System.

Language: voice command
German: Hilfe Sprachbedienung
English: Voice operation help
French: Aide Système de commande vocale
Spanish: Ayuda Manejo por voz
Italian: Aiuto sistema di comando vocale
Portugese: Ajuda do comando por voz
Dutch: Help spraakbediening
Russian: Сijа\dа ih kиklеfе ]hehkh\h]h mijа\eеgия

x Follow the subsequent explanations and instructions in the voice dialog.
Control during voice dialog
While voice guidance is being provided by the Infotainment System, the microphone symbol “not
active” (without the 3 lines) is shown on the instrument cluster display and on the Infotainment System
screen.
x Briefly press the  button on the multi-function steering wheel to interrupt voice guidance from the
Infotainment System and immediately say the next voice command.
You can only say a voice command when the  symbol “active” is displayed.
If a voice command is spoken incorrectly or incompletely and no action has been started as a result,
the voice command can be repeated. The  symbol remains “active”.
x Briefly press the  button on the multi-function steering wheel to repeat the voice command.
Recording name tags
A name tag can be recorded as a voice command in some menus via the voice operation. Follow the
instructions from the voice dialog. Avoid loud noises in the background when recording voice inputs.
.Some voice commands are only available if the unit is in the right operating area.
.Display of the help menus for the individual operating areas can be disabled.
.If a voice command has been misunderstood several times, it may be sensible to terminate
voice operation manually by pressing the  button longer and to then start again.
Notes on voice operation
