2013 VOLKSWAGEN TOUAREG infotainment

Enabling and disabling the “Coming home” and “Leaving home” functions
The “Coming home” and “Leaving home” functions can be enabled or disabled in the Infotainment
System.
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select the menu item External lightingin the list.
x Tap Leaving homeor Coming hometo enable or disable the feature.
The feature is enabled when the check box in the Leaving homeor Coming homefunction key is checked =.
Switching the “Coming home” and “Leaving home” functions on and off
The “Coming home” feature must be switched on manually. The “Leaving home” feature is
automatically controlled by a low-light sensor.

“Coming home” Action
Switch on: – Switch off the ignition.
– Operate the headlight flasher for about 1 second.
Opening the driver door switches on the “Coming home” feature. The delay
period starts when the last vehicle door or the rear hatch is closed. The
“Coming home” lighting is switched on when the driver door is open, the
headlight switch is set to AUTO, and the low light sensor detects darkness.
The delay period starts once the last vehicle door or the rear hatch is closed.
Switch off: – Automatically after the preset delay period is over.
– Automatically if any door or the rear hatch is still open about 60 seconds
after activation.
– Turn the light switch to the  position.
– Switch on the ignition.


“Leaving home” Action
Switch on: – Unlock the vehicle when the light switch is not in the O position and the low-
light sensor registers darkness. Unlock the vehicle if the light switch is in the
AUTO position and the low-light sensor registers darkness.
Switch off: – Automatically after the preset delay period is over.
– Lock the vehicle.
– Turn the light switch to the / position.
– Switch on the ignition.

Background lighting in the outside mirrors
The background lighting in the outside mirrors lights up the area close to the doors while you are
getting into or out of the vehicle. It is switched on when the vehicle is unlocked, a vehicle door is
opened, or the “Coming home” or “Leaving home” feature is activated. If the vehicle is equipped with a
light sensor, the background lighting in the outside mirrors is only switched on in darkness.

The lights stay on for about 10 seconds (lighting delay period). The “Coming home” and
“Leaving home” functions can be enabled and disabled in the Infotainment System.
If the “Coming home” feature is switched on and the driver door is opened, no acoustic warning
will sound to alert that the light is still on.
Instrument panel lighting , headlight range adjustment

Fig. 85 Next to the steering wheel: Control for instrument cluster lighting.

Safety information on Infotainment System
.WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
x Setting the sound volume too high may damage your hearing. This applies even if you are
exposed to high volumes for short periods only.
.WARNING
The volume level may suddenly get louder change when you switch media source or connect
a new audio source.
x Always lower the base volume before switching media source or connecting a new audio
source.
.WARNING
Driving recommendations and traffic symbols displayed by the navigation system may differ
from the current traffic situation.
x Traffic signs and traffic regulations have priority over the recommendations and displays
provided by the navigation system.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
.WARNING
External devices that are loose in the vehicle or not properly secured could be thrown around
the interior and cause injuries during a sudden driving or braking maneuver, or in a crash.
x Never put or attach an external device on a door, on the windshield or above or near to the
areas marked “AIRBAG” on the steering wheel, the instrument panel and the seat backrests,
or between these areas and the vehicle occupants. External devices could cause serious
injury in an accident, especially when the airbags inflate.

.Due to country-specific legal requirements, some functions are not selectable on the screen
above a certain driving speed.
.Using a cell phone in the vehicle may cause noise from the vehicle speakers.
.Some countries may have restrictions regarding the use of Bluetooth devices. Information can
be obtained from the local authorities.
Controls

Fig. 123 Overview of rotary/push knobs and the Infotainment buttons.

(8) PHONEInfotainment button3 for accessing the telephone functions .
Switching on or off

.WARNING
The volume may suddenly get louder when you switch media source or connect a new audio
source.
x Always lower the volume before switching media source or connecting a new audio
source.
.NOTICE
Excessively loud or distorted playback can damage the vehicle speakers.
If the base volume on the Infotainment System has been considerably increased to play a certain
audio source, lower the volume again before switching to another audio source.
Function keys on screen

Fig. 124 Setup main menu (SETUP).

Fig. 125 Navigation settings.
.

x Briefly press the  button on the multi-function steering wheel.
x Say the voice command in the language set in the Infotainment System.

Language: voice command
German: Hilfe Sprachbedienung
English: Voice operation help
French: Aide Système de commande vocale
Spanish: Ayuda Manejo por voz
Italian: Aiuto sistema di comando vocale
Portugese: Ajuda do comando por voz
Dutch: Help spraakbediening
Russian: Сijа\dа ih kиklеfе ]hehkh\h]h mijа\eеgия

x Follow the subsequent explanations and instructions in the voice dialog.
Control during voice dialog
While voice guidance is being provided by the Infotainment System, the microphone symbol “not
active” (without the 3 lines) is shown on the instrument cluster display and on the Infotainment System
screen.
x Briefly press the  button on the multi-function steering wheel to interrupt voice guidance from the
Infotainment System and immediately say the next voice command.
You can only say a voice command when the  symbol “active” is displayed.
If a voice command is spoken incorrectly or incompletely and no action has been started as a result,
the voice command can be repeated. The  symbol remains “active”.
x Briefly press the  button on the multi-function steering wheel to repeat the voice command.
Recording name tags
A name tag can be recorded as a voice command in some menus via the voice operation. Follow the
instructions from the voice dialog. Avoid loud noises in the background when recording voice inputs.
.Some voice commands are only available if the unit is in the right operating area.
.Display of the help menus for the individual operating areas can be disabled.
.If a voice command has been misunderstood several times, it may be sensible to terminate
voice operation manually by pressing the  button longer and to then start again.
Notes on voice operation

Fig. 133 Infotainment system without navigation: Settings main menu (CAR).
