2013 VOLKSWAGEN TIGUAN back up

x Securely stow all luggage
x Drive especially carefully and accelerate gently.
x Avoid sudden braking and driving maneuvers.
x Brake earlier than you would if you were not driving a loaded vehicle.
x If applicable, observe information about driving with a trailer
WARNING
Heavy loads can change the way your vehicle handles and increase stopping distances.
Heavy loads that are not properly stowed or secured can shift suddenly, causing loss of
control and serious injury.
x Secure the load properly to keep it from shifting.
x Always remember when transporting heavy objects that they change the vehicle's center
of gravity and also the way it handles.
– Always distribute the load as evenly as possible.
– Secure heavy objects as far forward in the luggage compartment as possible.
– Use your vehicle's luggage compartment tie-downs with suitable straps.
x Always tie down heavy items securely with suitable straps.
x Securely latch the rear seat backrest in the upright position.
x Never exceed the Gross Axle Weight Rating or the Gross Vehicle Weight Rating on the
safety compliance sticker on the left door jamb. Exceeding permissible weight can cause the
vehicle to skid and handle differently.
x Always adapt speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Always accelerate gently and avoid sudden braking and driving maneuvers.
x Always brake earlier than you would if you were not driving a loaded vehicle.
Weights and axle weights

Folding the backrest of the rear seat bench forward and back into place

Fig. 96 Folding the backrest forward and back.

WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal
injury.
x Always make sure there are no people or animals in the area around the rear seat backrest
when folding it forward.
x Never fold the rear seat backrest up or down while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get
caught or damaged.
x Keep hands, fingers, feet and other body parts out of the away when folding the rear seat
backrest up and down.
x Each rear seat backrest must be securely latched into place in the upright position so that
the safety belts on the rear seats can provide protection. This is particularly the case for the
middle seat on the rear bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together
with the rear seat backrest during sudden braking, driving maneuvers, or a collision.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded
down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head
restraint or backrest cushion will not touch the front seats.
NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is
adjusted in the fore and aft direction.
Removing and installing the rear seat

Fig. 97 Front attachment of the rear seat.

7. Secure both seat rails of the rear seat in front and back with 2 hexagonal nuts each, tightening the
nuts by hand - do not tighten them with the lug wrench yet.
8. To align the seat rails, press the left rear seat all the way to the left in the vehicle.
9. To align the seat rails, press the right rear seat all the way to the right in the vehicle.
10. Tighten the hexagonal nuts in the luggage compartment (arrows) to 44 ft-lbs (60 Nm) using a
torque wrench. If no torque wrench is available, tighten the hexagonal nuts using the lug wrench
and have the torque checked at a qualified workshop as soon as possible.
11. Push the rear seats as far back as possible
12. Remove the hexagonal nuts in the rear of the footwell again, set the 3 plastic covers ⇒ fig. 97 on
the studs and screw on with the hexagonal nuts.
13. Tighten the hexagonal nuts (arrows) to 44 ft-lbs (60 Nm) using a torque wrench. If no torque
wrench is available, tighten the hexagonal nuts using the lug wrench and have the torque checked
at a qualified workshop as soon as possible.
14. Clip on the small covers (not pictured) on the hexagonal nuts (arrows).
15. Install the foam insert and spare wheel in the vehicle
16. Install the luggage compartment floor
17. Install the luggage compartment cover
18. Install all rear head restraints
WARNING
No one may ride in the back of the vehicle when the rear seat has been removed.
WARNING
An improperly installed rear seat can separate from its mountings during an accident.
x All securing bolts must be tightened to the specified torque after the rear seat has been
installed.
CAUTION
Sharp-edged parts are located on the underside of the rear seat.
x Protect your hands when you lift the rear seat in or out.
NOTICE
x Have at least one person help to lift the rear seat in or out. One person should be in the
vehicle and one outside.
x The lever ⇒ fig. 43 for the fore and aft adjustment of the rear seat must not be operated
while the seat is removed. If the position of the fore and aft adjustment is changed, the rear
seat can only be installed by a qualified workshop.

Do not cover the ventilation slots in the side consoles. Otherwise, stale air cannot escape from
the vehicle.
Luggage compartment pass-through

Fig. In the rear backrest: Opening the luggage compartment pass-through.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment Hooks on elastic straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the
vehicle and do not let them snap back and hit you.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let
them snap back and hit you.
x First attach hooks to the tie-downs at the rear seat backrest in the luggage compartment
and then to the tie-downs near the loading edge of the luggage compartment. This way, if one
of the hooks on the elastic straps snaps back, it will move away from you, decreasing the risk
of personal injury.
The maximum load for the tie-downs is about lbs. ( kg).
For suitable ratchet straps and luggage stowage systems, please see an authorized Volkswagen
dealer or authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. In the luggage compartment: Shopping bag hooks.

WARNING
The elastic luggage net has to be stretched when being attached to the tie-downs in the
luggage compartment. The metal hooks can cause serious personal injury if not handled
properly and attached securely.
x Always hold the hooks on the luggage net bag firmly when attaching to the vehicle and do
not let them spring back and hit you.
x Always protect eyes and face from injury from the metal hooks when attaching them to the
tie-downs in the luggage compartment.
x First attach the luggage net bag hooks to the tie-downs on the rear seat backrest or on the
shopping bag hooks in the luggage compartment and then to the tie-downs near the loading
edge of the luggage compartment. If one of the hooks on the luggage bag net snaps back, it
will move away from you and not towards you, increasing the risk of injury.
Variable luggage compartment floor

Fig. In the luggage compartment: Opening and securing the variable luggage compartment floor.

Fig. Extending the luggage compartment floor forward or downward.

x To secure, push the retaining pin to the right.
x To close, push the retaining pin (1) to the left and guide the luggage compartment floor
downwards.
Extending the luggage compartment floor forward
x Remove the luggage compartment cover
x Remove the rear head restraints
x Push both sections of the rear seat forward
x Fold the rear backrests forward
x Fold the cover forward ⇒ fig. (1).
Extending the luggage compartment floor downward
x Remove the luggage compartment cover
x Raise the luggage compartment floor, pull from the side pins (2) and remove it from the vehicle to
the rear.
There may be a foam element with the spare wheel ⇒ fig. located beneath the variable luggage
compartment floor. If a spare wheel is present, remove it and remove the foam element from the
luggage compartment.
WARNING
During hard braking or an accident, loose objects can fly through the passenger
compartment and cause serious or even fatal injuries.
x Even if the luggage compartment floor panel is properly raised, it is still necessary to
secure all objects.
x Objects stowed between the rear seat bench and the luggage compartment floor panel
must never be more than 2/3 as high as the raised floor panel.
x Objects stowed between the rear seat bench and the raised luggage compartment floor
panel must never weigh more than about 16.5 lbs. (7.5 kg).
NOTICE
Do not let the luggage compartment floor fall freely when closing it. Always guide it down into
place. The trim or the luggage compartment floor could be damaged.
If you slide the rear seats forward, there is a gap between the luggage compartment floor and the
rear seats. Make certain there are no objects in this space before sliding the rear seats back again.
