2013 VOLKSWAGEN TIGUAN back up

Adjusting rear seat

Fig. 43 Adjusting the rear seat.

Fig. 44 Adjusting the rear backrest.

NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is
adjusted in the fore and aft direction.
x If the rear seat is in a forward position, items can get into the area between the seat and the
luggage compartment floor. When you slide the rear seat back again, make sure that the area
behind the seat is clear of objects.
Adjusting front and rear head restraints

Fig. 45 Adjusting the front head restraints.

Fig. 46 Adjusting or folding the rear head restraints.

Adjusting the height
x Push the head restraint up in the direction of the arrow or down when the button ⇒ fig. 45 (1) or
⇒ fig. 46 (1) is pressed ⇒ .
x The head restraint must lock securely in the position selected.
Folding the outer rear head restraints down
x With the (2) button pressed, fold the head restraint forward and down ⇒ .
x To use the seating area, fold the head restraint back up until it locks in place.
Proper head restraint adjustment
Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of the head as close as possible to the head restraint.
Adjusting the head restraint for short people
Push the head restraint down as far as it will go, even if this means the person's head is still below the
top edge of the head restraint. A small gap may remain between the head restraint and the backrest
when the head restraint is all the way down.
Adjusting the head restraint for tall people
Pull the head restraint up as far as it will go.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in a crash.
x Every person in the vehicle must have a properly adjusted head restraint to minimize the
risk of neck injury in a crash. Each head restraint must be adjusted according to the occu-
pants' size so that the upper edge is even with the top of the person's head, but no lower than
eye level. Always sit so that the back of your head is as close as possible to the head re-
straint.
x Never adjust head restraint while driving.

Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button ⇒ fig. 47 (1) or ⇒ fig. 48 (1).
x Adjust the head restraint according to the occupant's size
Removing the rear head restraint
x Unlock the rear bench and fold it forward
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap (2) in the direction of the arrow and hold it in this position.
x At the same time press button (1) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the rear bench and fold it forward
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (1).
x Fold the backrest of the rear bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are proper-
ly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not
strike the headliner or the back of the front seat. The headliner or other parts of the vehicle
could otherwise be damaged.

Function Action for seat heating ⇒fig.52
Switch on: Press the Aor ebutton. Seat heating is switched on
to maximum.
Adjusting heating
level:
Press the button Aor erepeatedly until the desired
heating level is set.
Switch off: Press the button Aor erepeatedly until all indicator
lights in the button are off.

Special seat heating features
The seat heating on the passenger side is switched off every time the ignition is switched off.
Seat heating must be switched on again each time the ignition is switched on.
On the driver side the seat heating will resume at the setting that was set when the ignition was
switched off. However, this feature only works if the key does not get pulled out of the ignition switch,
or, for vehicles with Keyless Access, the doors are not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from medica-
tion, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature ⇒ .
The use of seat heating by persons with these conditions could result in burns to the back, buttocks,
and legs that may take a long time to heal and may never heal completely. If you have any of these
conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult
your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications, can
increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain
can receive serious burns to the back, buttocks, and legs that take a long time to heal or may
never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned
because of a medical condition. Take regular breaks and get out of the vehicle, particularly
on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is
being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front
seats or apply concentrated pressure to a small area of the seat or backrest.

x The adjusted mirror position is automatically stored and assigned to the vehicle key used to unlock
the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment
position is used again.
The passenger-side outside mirror automatically adjusts back from the position stored for backing up
when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob ⇒ fig. 95
is rotated from (R) into a different position.
Recalling settings for driver seat and outside mirrors
x Briefly press the appropriate memory button when the vehicle is not moving, the ignition is
switched off, and the driver door is open.
x OR: If the ignition is switched on and the driver door is closed, press and hold the appropriate
memory button until the stored position is reached.
x The passenger-side outside mirror automatically adjusts back from the position stored for backing
up when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is
rotated from (R) into a different position.
Assigning driver seat and outside mirror settings to a vehicle key
The memory function of all vehicle keys is disabled when the vehicle is first delivered from the factory.
To enable vehicle key memory feature:
x Unlock the driver door.
x Press and hold a memory button until memory position is reached.
x Press and hold the unlock button 0 on the vehicle key and then press the desired memory button
at the same time within about 3 seconds. A chime sounds to confirm activation.
To disable remote control vehicle key memory function:
x Press and hold the SET button.
x Press and hold the unlock button 0 on the remote control vehicle key within about 10 seconds. A
chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
x Follow the instructions, Assigning driver seat and outside mirror settings to a vehicle key to assign
the driver seat and outside mirror settings to the vehicle key.
x Unlock the vehicle with the same vehicle key.
x Adjust driver seat and outside mirrors.
x Lock the vehicle with locking button 1 in the vehicle key to store the settings.
Once the settings are stored, the driver seat and the outside mirrors move to the stored positions
whenever the vehicle is unlocked with the vehicle key open button 0 and the driver door is opened. If 2
people use the vehicle, each of them should always use the key in which his or her personal settings
have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop in certain situations, for instance, if a new
driver seat is installed.
Initializing clears all memories and assignments of the memory seat. After that, memory buttons can
be reprogrammed and assigned to a remote control vehicle key.
x Open the driver door but do not enter the vehicle.
x Adjust the seats from the outside.
x Move the angle of the backrest forward as far as it will go.
x Release the backrest adjustment switch and press it again until you hear a chime sound.

Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x Charging condition of the vehicle battery is weak.
x The SET button is pressed again within about 10 seconds.
x The seat position is readjusted within about 10 seconds after pressing the SET button.
Folding the front passenger backrest forward

Fig. 54 Folding the front passenger backrest forward.

Fig. 55 Unlocking the foldable front passenger backrest.

x Push the head restraint all the way down
x Unlock the front passenger backrest in the direction of the arrow ⇒ fig. 54 (1).
x Fold the front passenger backrest forward into the horizontal position in the direction of the arrow
(2).
x The front passenger backrest must be securely latched in the folded down position.
Folding the front passenger backrest into place
x Make sure that nobody is near the hinges when folding the backrest back into place.
x Unlock the front passenger backrest to fold it back ⇒ fig. 55.
x Fold the front passenger backrest into the upright position.
x The front passenger backrest must be securely latched in the upright position.
WARNING
Improper folding and improper latching of the front passenger backrest can cause serious
personal injury.
x Never fold the front passenger backrest forward or back when the vehicle is moving.
x Always make sure that the PASSENGER AIR BAG OFF  light is on and stays on
whenever the backrest of the front passenger seat is folded forward.
x Always keep hands, fingers, feet and other body parts out of the way of the seat hinges
and the seat locking mechanism when folding the backrest forward and back.
x Floor mats and other objects can get caught in the front passenger backrest hinges. This
can cause the front passenger backrest to incorrectly latch when folded back into the upright
position.
x When folded back into place, the front passenger backrest must be securely latched in the
upright position. An improperly latched front passenger backrest can suddenly move and
cause serious personal injury.
WARNING
Open seat mountings and hinges of the folded front passenger backrest can cause severe
injuries in the event of a braking maneuver or accident.
x Do not let passengers or children occupy the front passenger seat when the front
passenger backrest is folded forward.
x When the front passenger backrest is folded down, only the outer seat of the rear bench
behind the driver seat can be occupied. This also applies to children in child safety seats.
