2013 TOYOTA LAND CRUISER Owners Manual

689 6-1. Specifications
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Tire related termMeaning
Overall widthThe linear distance between the exteriors of
the sidewalls of an inflated tire, including eleva-
tions due to labeling, decorations, or protective
bands or ribs
Passenger car tireA tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less
Ply A layer of rubber-coated parallel cords
Ply separationA parting of rubber compound between adja-
cent plies
Pneumatic tireA mechanical device made of rubber, chemi-
cals, fabric and steel or other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tireA pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tireA tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section widthThe linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
SidewallThat portion of a tire between the tread and
bead
Sidewall separationThe parting of the rubber compound from the
cord material in the sidewall

690 6-1. Specifications
LC200_OM_OM60F57U_(U)
Tire related termMeaning
Snow tireA tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i mThe rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
TreadThat portion of a tire that comes into contact
with the road
Tread ribA tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI)The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixtureThe fixture used to hold the wheel and tire
assembly securely during testing

691 6-1. Specifications
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
*:Table 1  Occupant loading and distribution for vehicle normal load
for various designated seating capacities
Designated seating
capacity, Number of
occupantsVehicle normal load,
Number of occupantsOccupant distribution in
a normally loaded
vehicle
2 through 4 2 2 in front
5 through 10 32 in front, 1 in second
seat
11 through 15 52 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 72 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

692
LC200_OM_OM60F57U_(U)
6-2. Customization
Customizable features
Customizing vehicle features using the touch screen (vehicles
with navigation system)
Press “SETUP”.
Touch “Vehicle” on the “Setup” screen.
Touch “Vehicle Customization”.
Touch the setting to be changed.
Change each setting and touch
“Save”.
If “Save” is not touched before
switching to another screen, any
changes will be lost.
A message indicating that the settings are being saved will
appear.
Do not perform any other operations while this message is
displayed.
Your vehicle includes a variety of electronic features that can be per-
sonalized to your preferences.
Programming of these preferences can be performed by your Toyota
dealer.
For vehicles with the navigation system, it is also possible to cus-
tomize certain vehicle features yourself using the touch screen.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.
STEP1
STEP2
STEP3
STEP4
STEP5

693 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Customizable features
Vehicle customization settings can be changed at your Toyota dealer.
For vehicles with the navigation system, some settings can be
changed using the touch screen.
Settings that can be changed using the touch screen
Settings that can be changed using the vehicle switches
Settings that can be changed by your Toyota dealer
Definition of symbols: O= Available, — = Not available
ItemFunctionDefault
settingCustomized
setting
Smart key
system
(P. 32)Smart key
systemOn Off O — O
Smart door
unlockingDriver’s door All the doors O O O

694 6-2. Customization
LC200_OM_OM60F57U_(U)
Wireless
remote
control
(P. 44)Wireless remote
controlOn Off — — O
Open door warn-
ing function
(when locking the
vehicle)On Off — — O
Unlocking opera-
tionDriver’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one stepO—O
Smart key
system
(P. 32)
and
wireless
remote
control
(P. 44) Operation signal
(Emergency
flashers)On Off O — O
Time elapsed
before automatic
door lock function
is activated if
door is not
opened after
being unlocked60 secondsOff
O—O 30 seconds
120 seconds
Adjust the vol-
ume of confirma-
tion buzzer
sounds when the
vehicle is locked
or unlocked7Off
O—O
1 to 6
ItemFunctionDefault
settingCustomized
setting

695 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Door lock
(P. 46)Unlocking using a
mechanical keyDriver’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one stepO—O
Speed-detecting
automatic door
lock functionOff On O O O
Shifting the shift
lever to position
other than “P”
locks all doorsOn Off O O O
Shifting the shift
lever to “P”
unlocks all doorsOn Off O O O
Opening driver’s
door unlocks all
doorsOff On O O O
Power
windows
(P. 93)Mechanical key
linked operation
(close)Off On — — O
Mechanical key
linked operation
(open)Off On — — O
Wireless remote
control linked
operation (open)Off On — — O
Linked entry
functionOff On — — O
ItemFunctionDefault
settingCustomized
setting

696 6-2. Customization
LC200_OM_OM60F57U_(U)
Moon roof
(P. 97)Mechanical key
linked operation
(open)
*1Off On — — O
Mechanical key
linked operation
(close)
*1Off On — — O
Linked operation
of components
when door key is
usedSlide only Tilt only — — O
Wireless remote
control linked
operation
(open)
*2
Off On — — O
Linked operation
of components
when wireless
remote control
usedSlide only Tilt only — — O
Linked entry
function
*3Off On — — O
ItemFunctionDefault
settingCustomized
setting
