2013 TOYOTA HIGHLANDER display

AUDIO/VIDEO SYSTEM
227

Unit
1Turning on the DVD mode
2Skipping to the desired chapter
3Playing/pausing a disc
4Turning on or off the operation
switches on the display
5Selecting a switch
6Inputting the selected switch
Display (Page 1)
1Turning off
the operation switches on
the display
2Displaying to Page 2
3Turning on or off the title selection
screen for the disc
4Turning on or of f the menu screen for
the disc
5Reversing a disc
6Stopping a disc
7Pausing the disc/canceling the pause
8Fast forwarding a disc

AUDIO/VIDEO SYSTEM
228

Display (Page 2)
9Displaying to
the initial setting screen
10Displaying to Page 1
11Search for a title
12Returning to the previous screen
13Changing the audio language
14Changing the subtitle language
15Changing the angle
INFORMATION
To operate from the front audio sys-
tem, see “— DVD player operation”
on page 187.
(a) Turning on or off the operation
switches
Push
or to turn on the opera-
tion switches. Push
or once
again or select “Hide Buttons” to turn off
the operation switches.
(b) Turning on the title selection
screen
Push
or select “Top Menu” to turn
on the title selection screen. For the op-
eration of the title selection screen, see the
separate manual for the DVD disc.
(c) Turning on the menu screen
Push
or select “Menu” to turn on
the menu screen. For the operation of the
menu screen, see the separate manual for
the DVD disc.
(d) Returning to the previous screen
Select “Return” to return to the previous
screen. For the operation of the menu
screen, see the separate manual for the
DVD disc.

AUDIO/VIDEO SYSTEM
229
(e) Searching for a title
Push or select “Search” to dis-
play the screen to search for a title.
Select the title number , and push “ENT” to
input it. Select “Back” to return to the pre-
vious screen.
(f) Changing the subtitle language
Push or select “Sub Title” to dis-
play the subtitle language screen.
Each time
is pushed or “Sub Title”
is selected, another language stored on
the disc is selected.
Select “Back” to return to the previous
screen. (g) Changing the audio language
Push or select “Audio” to display
the audio language screen.
Each time
is pushed or “Audio” is
selected, another language stored on the
disc is selected.
Select “Back” to return to the previous
screen.
(h) Changing the angle
Push or select “Angle” to display
the screen to change the angle.
Each time
is pushed or “Angle” is
selected, the angle changes.
Select “Back” to return to the previous
screen.

AUDIO/VIDEO SYSTEM
232

Remote controller
1Selecting a switch
2Selecting a chapter
3Playing/pausing a disc
4Reversing a disc
5Displaying operation switches
6Inputting the selected switch
7Fast forwarding a disc
8Stopping a disc
9Changing the initial setting
Unit
1Skipping to the desired chapter
2Playing/pausing a disc
3Selecting a switch
4Inputting the selected switch
— Using the DVD player
(video CD)

AUDIO/VIDEO SYSTEM
233

Display (page 1)
1Selecting a disc menu number
2Turning off the menu screen
3Displaying to page 2
4Turning on the disc menu
5Returning to the previous page
screen (with the disc menu dis-
played)
6Proceeding to the next page screen
(with the disc menu displayed)
7Changing to a multiplex transmission
Display (page 2)
8Displaying to page 1
9Reversing a disc
10Pausing
the disc/canceling the pause
11Fast forwarding a disc
INFORMATION
To operate from the front audio sys-
tem, see “— DVD player operation”
on page 187.

AUDIO/VIDEO SYSTEM
234

Selecting a disc menu number
Select “Select Number” to display the
disc menu number search screen.
Select the disc menu number, and push
“ENT” to input it.
Select “Back” to return to the previous
screen.Using the control screen
Using the control screen, push or
to display the control screen.
1Repeat play
2Random playback
3Search playback
Canceling random, repeat and scan
play
Select “RPT” , “RAND” or “SCAN” again.
INFORMATION
To operate from the front audio sys-
tem, see “— DVD player operation”
on page 187.
— Using the DVD player
(audio CD/CD text)

AUDIO/VIDEO SYSTEM
235

Using the control screen
Push or to display the control
screen.
1Repeat play
2Random playback
3Search playback
4Displaying file information
5Selecting folder
INFORMATION
To operate from the front audio sys-
tem, see “— DVD player operation”
on page 187.
Repeat play
Repeat a file
Select “RPT” .
Repeat all of files in a folder
Select “RPT”, and push and hold “ENT”.
Random playback
Playing files from a particular folder in
random order
Select “RAND” .
Playing all of the files on a disc in ran-
dom order
Select “RAND” , and push and hold
“ENT” .
Search playback
Selecting the desired file by cueing the
files in the folder
Select “SCAN” .
The player will scan all the files in the fold-
er. Each file will be played for 10 seconds.
Selecting the desired file by cueing
the folders on the disc
Select “SCAN” , and push and hold
“ENT” . The player will scan all the folders
on the disc. The first file in each folder will
be played for 10 seconds.
Canceling random, repeat and play
back
Select “PRT” , “RAND” or “SCAN” again.
— Using the DVD player
(MP3 discs)

AUDIO/VIDEO SYSTEM
240

Setting the display mode
Pushing changes the display
modes sequentially as follows:
Normal → Wide 1 →Wide 2
Returning to the previous screen
Select “BACK” , and push “ENT” .
To initialize the password
Push  on the remote controller or unit ten
times when the screen to enter the person-
al code is displayed.
Adjusting the screen
Push .
Select the brightness, contrast, tone or col-
or, and make adjustments. Push
or
“ENT” to input it.
Brightness, contrast, tone and color
adjustment
“Brightness” “+”:
Brightens the screen.
“Brightness” “”:
Darkens the screen.
“Contrast” “+”:
Strengthens the contrast of the screen.
“Contrast” “”:
Weakens the contrast of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the
screen.
“Color” “Red”:
Strengthens the red color of the screen.
“Color” “Green”:
Strengthens the green color of the screen.
