2013 NISSAN XTERRA LC2 Navigation Manual

5. Touch “Change State/Province” if the stateor province displayed is not correct. 6. If necessary, enter the name of the state or
province.
The display shows the touch keyboard.
“HOW TO INPUT CHARACTERS”
(page 2-8) 7. Press “List” at any time and a list of remain-
ing cities will be shown. Touch the desired
city.
LNV2226LNV2066LNV0953
Navigation4-31

8. Touch “Street”.The display shows the touch keyboard.
“HOW TO INPUT CHARAC-
TERS” (page 2-8) 9. Touch the name of the desired street.
10. A list of intersecting streets will be shown if six or less exist. Otherwise, the touch key-
board will be displayed again so that the
name of the second street in the intersec-
tion can be entered. Enter the second street
name.
11. Select the intersecting street. 12. Touch “Start”.
The route to the intersection will be
calculated.
LNV2067LNV0955LNV2229
4-32Navigation

The center of a city can be set as a destination.
To set a city center as a destination:1. Press the NAV button.
2. Touch “Destination”.
3. Touch “Next Page”.
4. Touch “City Center”.
5. If the state shown is not correct, touch “Change State or Province”. Otherwise,
proceed to step 7. 6. Enter the name of the state or province. The
display shows the touch keyboard.
“HOW TO INPUT CHARAC-
TERS” (page 2-8)
The keyboard has an intelligent spelling
setting, so it excludes non-existing
combinations. On the top right of the
screen, the number of matches is shown.
7. Touch “City”
8. Enter the name of the first street. The dis- play shows the touch keyboard. 9. Touch “Start” to calculate the route to the
city center.
LNV2227LNV2066LNV2229
SETTING A CITY CENTER AS A DES-
TINATION
Navigation4-33

This method allows you to search for a destina-
tion by scrolling the map, then have the system
calculate a route to the destination or store the
position in the address book.1. Press the NAV button.
2. Touch “Destination”.
3. Touch “Next Page”.
4. Touch “Map”.
The system is automatically set to the 2D, North
Up setting. 5. Scroll the map and touch the screen at the
preferred location.
6. Touch the position data.
7. Touch “OK”.
Choose “Store” to store the location in the ad-
dress book. The touch keyboard is displayed so
that a name for the entry can be stored. Choose “Start” to calculate the route and begin
route guidance to the chosen location.
LNV2230LNV2231LNV2229
SETTING DESTINATION BY MAP
4-34Navigation

The Navigation System receives traffic informa-
tion from NavTraffic to inform you of traffic events
and guide you to an alternate route. Traffic
events include accidents, road construction,
heavy traffic and other factors that affect the
route ahead.
DISPLAYING TRAFFIC EVENTS
ALONG ROUTE
When a route is active, press the MENU button
and then touch “Traffic Information” to display
the traffic event nearest the current vehicle
location. The location and nature of the traffic
event is displayed on the screen. Three menu
options are available on the screen.
NOTE:
This feature can also be accessed using
the NISSAN Voice Recognition System (if
so equipped) by pressing the
orbutton on the steering wheel and
when prompted, saying “Information” then
“Traffic”. ●
“On Route”
Touch the “On Route” key to display a list of all
traffic events that are present along the current
route. Touch the line of a specific event on the
screen to see more details about that item.
LNV2111LNV2106
TRAFFIC FEATURE
Navigation4-35

●“All”
Touch the “All” key to display a list of all traffic
events in the area, including those which are not
directly along the current route. Touch the line of
a specific event on the screen to see more de-
tails about that item. ●
“Avoid Rd.”
Touch the “Avoid Rd.” key to direct the naviga-
tion system to avoid the area impacted by the
listed traffic event. The next screen lists two
options. Touch the “Avoid Road Ahead” key to avoid the
road listed on the traffic event. You can choose
the distance over which the system avoids the
affected road. Touch the “+” or “-” key to set the
distance and then touch “Recalculate Route” to
calculate the new route.
LNV2113LNV2105LNV2107
4-36Navigation

Touch the “Avoid Segment of Route List” key to
avoid a series of roads on the route list due to the
traffic event. The route list is displayed on the
screen. Touch the names of two streets on the list
to avoid that portion of the route and then touch
“Recalculate Route” to calculate the new route.
TRAFFIC ICONS
The following traffic icons are used:
: Accident
: Entrance/Exit Closed
: Incident
: Information
: Narrow Lanes
: Road Construction
: Traffic Jam
NOTE:
A black line is drawn over the road and
route (if active) to indicate road construc-
tion areas and length.
TRAFFIC FLOW FEATURE
Using information received from NavTraffic, the
system informs you of traffic levels on certain
highways and roads in the area along the route.
Press the MAP button to display the map of the
current vehicle location. Any roads with traffic
flow information will appear colored as follows:
● Green: traffic is light and moving at normal
speeds. (>45 mph)
● Yellow: traffic is heavy and moving slowly.
(10-45 mph)
● Red: traffic is gridlocked and not moving.
(<10 mph)
TRAFFIC SETTINGS
To access the settings for the traffic feature:
1. Press the MENU button.
2. Touch the “Settings” key.
LNV2106LNV2378
Navigation4-37

3. Touch the “Info” key.4. Touch the “Traffic Settings” key.The following settings can be adjusted:
●Dynamic Guidance
● Show Traffic Incidents
● Show Traffic Flow
● Announce Traffic Alerts
LNV2233LNV2234LNV2072
4-38Navigation
