2013 Lexus GS350 Navigation manual

1
2
3
4
5
6
7
9
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
1. INFORMATION DISPLAY.............. 176
TRAFFIC ............................................. 176
2. SETUP ............................................... 181
TRAFFIC AND PARKING SETTINGS ..
181
1. CONNECTED SERVICES ............... 188
CONNECTED SERVICES
OVERVIEW ..................................... 188
SETTINGS REQUIRED FOR USING
THE SERVICE ................................. 191
USING CONNECTED SERVICES .... 197
2. SETUP ............................................... 206
ONLINE SEARCH SETTINGS .......... 206
1. 12.3-INCH DISPLAY OPERATION 212
12.3-INCH DISPLAY-OVERVIEW... 212
BASIC SCREENS ............................... 214
INTERRUPTION SCREENS.............. 221
ALPHABETICAL INDEX .................. 226
5INFORMATION
6CONNECTED SERVICES
712.3-INCH DISPLAY
INDEX

10
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07

1
11
2
3
4
5
6
7
1
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
1. Remote Touch ................................... 12
2. MAP SCREEN .................................. 14
3. REGISTERING HOME .................... 16
4. REGISTERING QUICK ACCESS ... 18
5. OPERATION FLOW: GUIDING
THE ROUTE................................... 20
6. SETTING HOME AS THE
DESTINATION .............................. 22
1. NAVIGATION SYSTEM FUNCTION
INDEX ............................................ 24
1. NAVIGATION MENU SCREEN ..... 26
2. “Menu” SCREEN .............................. 28
3. “Setup” SCREEN .............................. 30
4. “Information” SCREEN .................... 32
1NAVIGATION OPERATION
2FUNCTION INDEX
3QUICK REFERENCE
QUICK GUIDE

12
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
1. NAVIGATION OPERATION
1. Remote Touch
The above illustration is for a left-hand drive vehicle. The button positions
are reversed for right-hand drive vehicles.

13
1. NAVIGATION OPERATION
1
QUICK GUIDE
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
No.NameFunctionPage
“MENU” but-
tonPress to display the “Menu” screen.28
“·” buttonPress to change the scale of the map and to
scroll the list screen.38, 43, 58
“MAP/VOICE”
buttonPress to repeat a voice guidance, cancel the
map scroll, start guidance or display the cur-
rent position.
47
Remote Touch
knob
Move in the desired direction to select a func-
tion, letter and map screen button.
Press to enter the selected function, letter or
map screen button.
38

14
1. NAVIGATION OPERATION
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
2. MAP SCREEN
No.NameFunctionPage
2D north up, 2D
heading up or
3D heading up
symbolThis symbol indicates whether the map orien-
tation is set to north-up or heading-up. A
north up view of the map is available in 2D
map mode only. A heading up view of the
map is available in 2D and 3D map modes.
58
Border guid-
anceWhen a vehicle crosses a borderline, the na-
tional flag of that country is displayed.

15
1. NAVIGATION OPERATION
1
QUICK GUIDE
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
Speed limit in-
formation iconSpeed limit information can be displayed.148
Zoom out
screen buttonSelect to reduce the map scale.58
Zoom in screen
buttonSelect to magnify the map scale.58
“Menu”Select to utilize functions such as setting a
destination and registering a memory point.26
Distance and
time to destina-
tionSelect to display the distance, estimated travel
and arrival time to the destination.113
Traffic indica-
torThis mark is displayed when traffic informa-
tion is received.177
“GPS” mark
(Global Posi-
tioning System)Whenever the vehicle is receiving signals
from the GPS, this mark is displayed.160
Scale indicatorThis figure indicates the map scale.58
*: Press and hold the Power/Volume knob for 3 seconds or more to turn off the screen and
restart the navigation system. Do this when the vehicle-mounted device response is ex-
tremely slow.
INFORMATION
Remove dirt from the display and its surrounding area by lightly wiping with a soft,
dry cloth, such as a cloth used for cleaning glasses with plastic lenses. Scrubbing
too hard or using a hard cloth could scratch the display. Also, the display is treated
with a coating, and could be damaged by coming into contact with benzine or alka-
line solution.
When the screen is viewed through polarized sunglasses, a rainbow pattern may
appear on the screen due to optical characteristics of the screen. If this is disturbing,
please operate the screen without polarized sunglasses.
No.NameFunctionPage

16
1. NAVIGATION OPERATION
GS450h_300h_350_250_NAVI_OM30D64E_(EE)
13.10.23 11:07
3. REGISTERING HOME
Select “Menu” and press the
Remote Touch knob.
Select “Destination” and press the
Remote Touch knob.
Select “Home” and press the
Remote Touch knob.
If a home address has not been regis-
tered, it can be registered it by select-
ing “Home”.
Select “Yes” and press the
Remote Touch knob.
There are 10 (11 when “UK” is se-
lected) different methods to
search your home. (See “DESTI-
NATION SEARCH” on page 81.)1
2
3
4
5
