2013 HONDA INSIGHT Owners Manual

Remove the blade f rom its holder
by grabbing the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder.Make sure the two rubber tabs
inside the blade f it to each notch of
the reinf orcement, as shown. is completely installed. Place the top of the wiper blade
on the end of the blade assembly,
and slide the blade onto the
assembly. Make sure the blade
Examine the new wiper blades. If
they have no plastic or metal
reinforcement along the back
edge, remove the metal
reinforcement strips from the old
wiper blade, and install them in
the slots along the edge of the
new blade.
3. 4.
5.
Wiper Blades
334
BLADE
REINFORCEMENTBLADE
12/07/13 17:19:21 31TM8630_339
Maint enanceTOC
2013 Insight

Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Make sure the blade is completely
installed and that its edge is not
bunched up.
Lower the wiper arm down against
the windshield, the passenger’s
side first, then the driver’s side.To replace a rear wiper blade:Raise the wiper arm off the
rear window. Disconnect the blade assembly
f rom the wiper arm by pulling up
the cover.
6.
7.
8.
1.2.
CONT INUED
Wiper Blades
335
COVER
REAR
12/07/13 17:19:29 31TM8630_340
Maint enanceTOC
2013 Insight

Examine the new wiper blades. If
they have no plastic or metal
reinforcement along the back
edge, remove the metal
reinforcement strips from the old
wiper blade, and install them in
the slots along the edge of the
new blade.
Make sure the two rubber tabs
inside the blade f it to each notch of
the reinf orcement, as shown.
Remove the blade f rom its holder
by grabbing the tabbed end of the
blade. Pull f irmly until the tabs
come out of the holder.
Push the blade assembly toward
thebaseof thearm.
When replacing a wiper blade,
make sure not to drop the
wiper blade or wiper arm
down on the windshield.
3.
4. 5.
Wiper Blades
336
BLADE
REINFORCEMENT
WIPER ARM
BLADE
TOP
12/07/13 17:19:36 31TM8630_341
Maint enanceTOC
2013 Insight

CONT INUED
Slide the wiper blade assembly
onto the wiper arm. Make sure it
locks in place.
Make sure the blade is completely
installed and that its edge is not
bunched up.
Place the top of the wiper blade
on the end of the blade assembly,
and slide the blade onto the
assembly. Make sure the blade
is completely installed. Lower the wiper arm down against
the windshield.
7.
8.
6. 9.
Wiper Blades
337
12/07/13 17:19:42 31TM8630_342
Maint enanceTOC
2013 Insight

To saf ely operate your vehicle, your
tires must be the proper type and
size, in good condition with adequate
tread, and correctly inf lated.
The f ollowing pages give more
detailed inf ormation on how to take
care of your tires and what to do
when they need to be replaced.Keeping the tires properly
inflated provides the best
combination of handling,
tread life, and riding comfort.
Underinf lated tires wear unevenly,
adversely affect handling and fuel
economy, and are more likely to
fail from being overheated.
Overinf lated tires can make your
vehicleridemoreharshly,are
more prone to damage f rom road
hazards, and wear unevenly.
The tire pressure monitoring system
(TPMS) warns you when a tire
pressure is low. See pagef or
more inf ormation. Even though your vehicle is
equipped with TPMS, we
recommend that you visually check
your tires every day. If you think a
tire might be low, check it
immediately with a tire gauge.
Use a gauge to measure the air
pressure in each tire at least once a
month. Even tires that are in good
condition may lose 1 to 2 psi (10 to
20 kPa, 0.1 to 0.2 kgf /cm ) per
month. Remember to check the
sparetireatthesametime.
Check the air pressures when the
tires are cold. This means the
vehicle has been parked for at least
3 hours, or driven less than 1 mile
(1.6 km). Add or release air, if
needed, to match the recommended
cold tire pressures.
We recommend that you visually
check your tires every day. If you
think a tire might be low, check it
immediately with a tire gauge. 289
On U.S. models On U.S. models
On all Canadian models
T ires Inf lation Guidelines
Tires
338
Using tires that are excessively
worn or improperly inflated can
cause a crash in which you can
be seriously hurt or killed.
Follow all instructions in this
owner’s manual regarding tire
inflation and maintenance.
12/07/13 17:19:53 31TM8630_343
Maint enanceTOC
2013 Insight

If you check air pressures when the
tires are hot (driven for several
miles/kilometers), you will see
readings 4 to 6 psi (30 to 40 kPa, 0.3
to 0.4 kgf/cm ) higher than the cold
readings. This is normal. Do not let
air out to match the recommended
cold air pressure. The tire will
You should get your own tire
pressure gauge and use it whenever
you check your tire pressures. This
will make it easier for you to tell if a
pressure loss is due to a tire
problem and not due to a variation
between gauges.
While tubeless tires have some
ability to self-seal if they are
punctured, you should look
closely for punctures if a tire
starts losing pressure.The following chart shows the
recommended cold tire pressures f or
most normal driving conditions.
Thecompactsparetirepressureis:
Every time you check inf lation, you
should also examine the tires f or
damage, f oreign objects, and wear.
Youshouldlookfor:
Bumpsorbulgesinthetreador
side of the tire. Replace the tire if
youfindeitherof theseconditions.
Cuts, splits, or cracks in the side
of the tire. Replace the tire if you
can see f abric or cord.
Excessive tread wear.
For convenience, the recommended
tire sizes and cold tire pressures are
on a label on the driver’s doorjamb.
For additional inf ormation about
your tires, see
page .382
Tire Size Cold Tire Pressure
Recommended Tire Pressures Tire Inspection
Tires
339
60 psi (420 kPa , 4.2 kgf/cm)
P185/60R15 84T
33 psi (230 kPa ,2.3 kgf/cm
)
Front/Rear:
12/07/13 17:20:05 31TM8630_344
Maint enanceTOC
be underinf lated.
2013 Insight

Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a 1/2
inch (12.7 mm) wide band across the
tread. This shows there is less than
1/16 inch (1.6 mm) of tread lef t on
the tire.
A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators.The service lif e of your tires is
dependent on many f actors,
including, but not limited to, driving
habits, road conditions, vehicle
loading, inf lation pressure,
maintenance history, speed, and
environmental conditions (even
when the tires are not in use).
In addition to your regular
inspections and inf lation pressure
maintenance, it is recommended that
you have annual inspections
perf ormed once the tires reach f ive
years old. It is also recommended
that all tires, including the spare, be
removed from service after 10 years
from the date of manufacture,
regardless of their condition or state
of wear.
The last f our digits of the TIN (tire
identif ication number) are f ound on
the sidewall of the tire and indicate
the date of manufacture (See
onpage ). In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
383
Tire Service Lif e
Tire
Labeling T ire Maintenance
Tires
340
TREAD WEAR INDICATOR
INDICATOR LOCATION MARKS
Improper wheel weights can damage
your vehicle’s aluminum wheels. Use
only Honda wheel weights f or
balancing.
12/07/13 17:20:13 31TM8630_345
Maint enanceTOC
2013 Insight

To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the multi-information display. Move
the tires to the positions shown in
the illustration each time they are
rotated. If you purchase directional
tires, rotate only front-to-back.Replace your tires with radial tires of
the same size, load range, speed
rating, and maximum cold tire
pressure rating (as shown on the
tire’s sidewall).
It is best to replace all f our tires at
thesametime.If thatisnotpossible
or necessary, replace the two f ront
tires or two rear tires as a pair.
Replacing just one tire can seriously
af f ect your vehicle’s handling.
If you ever replace a wheel, make
sure that the wheel’s specif ications
match those of the original wheels.
Replacement wheels are available at
your dealer. Also be sure you use only TPMS
specif ic wheels. If you do not, the
tire pressure monitoring system will
not work.
Mixing radial and bias-ply tires on
your vehicle can reduce braking
ability, traction, and steering
accuracy. Using tires of a dif f erent
size or construction can cause the
ABS and vehicle stability assist
system (VSA) to work inconsistently.
The ABS and VSA system work by
comparing the speed of each wheel.
When replacing tires, use the same
size originally supplied with the
vehicle. Tire size and construction
can af f ect wheel speed and may
cause the system to activate.
On U.S. models
CONT INUED
T ire Rotation
Replacing T ires and Wheels
Tires
341
FrontFront
(Front Non-directional
Tires and Wheels) (Front Directional
Tires and Wheels)
12/07/13 17:20:23 31TM8630_346
Maint enanceTOC
2013 Insight
