2013 HONDA CROSSTOUR Owners Manual

144
uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
Controls
Interior Convenience ItemsPull the handle to open the glove box. You
can lock the glove box with the master key or
the built-in key.
■Glove Box1Glove Box
3WARNING
An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.
Always keep the glove box closed while
driving.
Glove Box
To Lock
Main MenuTable of contents

145
uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
Continued
Controls
Pull the handle to open the console compartment. ■Removable tray
The tray in the console compartment is
detachable.
To remove this tray, slide it forward, then pull
it up.
■Console Compartment
Removable Tray
Main MenuTable of contents

uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
146
Controls
■ Front seat beverage holders
■ Rear seat beverage holders
Fold the armrest down to use the rear seat
beverage holders.
■Beverage Holders1Beverage Holders
NOTICESpilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.
Be careful when you are using the beverage holders.
Hot liquid can scald you.
Main MenuTable of contents

Continued147
uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
Controls
The accessory power sockets can be used when the ignition switch is in ACCESSORY (q or ON (w *1
.
■Accessory power socket (console panel)
Open the cover to use it.
■ Accessory power socket (console
compartment)
Open the console lid and the cover to use it.
*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.
■Accessory Power Sockets1Accessory Power Sockets
NOTICEDo not insert an automotive type cigarette lighter
element.
This can overheat the power socket.
The accessory power socket is designed to supply
power for 12 volt DC accessories that are rated 120
watts or less (10 amps).
To prevent battery drain, only use the power socket
with the engine running.
When each sockets is being used simultaneously, the
combined power rating of the accessories should not exceed 120 watts (10 amps).
Main MenuTable of contents

uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
148
Controls
■ Accessory power socket (cargo area)
Open the cover to use it.
There is a coat hook on the rear left grab
handle. Pull it down to use it.
■Coat Hook1Coat Hook
The coat hook is not designed for large or heavy items.
Main MenuTable of contents

Continued149
uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
Controls
Use floor cargo hooks to secure luggage in the cargo area.
There are also hooks on both sides of the cargo area.
■Cargo Hooks1Cargo Hooks
Each hook is designed to hold up to 56.2 lbs (25.5 kg)
of weight.
Hooks
Hooks
Main MenuTable of contents

uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
150
Controls
Pull the handle to open the cargo floor lid.
The reverse side of the cargo floor lid is water-
proofed. Flip the lid to use the water-proofed
side. ■ To keep the lid open:
1. Remove the hook from the back of the
cargo floor lid.
2. Pull the hook to the hole on the side panel.
■ Removable box
The removable box is under the cargo floor.
To remove the box, lift it up with the straps on
both sides.
■Under-floor Storage Area1Under-floor Storage Area
NOTICEDo not put objects that weigh more than 22.1 lbs (10
kg) in the removable box. Exceeding the maximum
load may damage the box.
Do not leave water, soil, sand, or perishable foods in
the removable box. Rotting food and dirt on the floor
may cause the breakdown of electrical equipment.
Strap
Main MenuTable of contents

151
uuInterior Lights/Interior Convenience ItemsuInterior Convenience Items
Continued
Controls
Pull the strap to raise the lid.
The reverse side of each lid is water-proofed.
Flip the lids, then replace each other side.
■Side Storage Compartments
Strap
Main MenuTable of contents
