Safety

Under-inflation alert
Reinitialisation
This is given by fixed illumination of
this warning lamp, accompanied byan audible signal and, depending on
equipment, the display of a message.
A label reminds you of the need to reinitialise
the system every time one or more tyre
pressure is adjusted, and after changing one or
more wheels.
)Reduce speed immediately, avoidexcessive steering movements and sudden
braking .)Stop the vehicle as soon as it is safe
to do so.
) In the event of a puncture, use the
temporary puncture repair kit or the spare
wheel (depending on equipment),or ) if you have a compressor, such as the one in the temporary puncture repair kit, check
the pressures of the four tyres when cold, or )
if it is not possible to make this check
immediately, drive carefully at reduced speed.



The loss of pressure detected does not always cause visible bulging of the tyre. Do not satisfy yourself with just a visual check. The aler t is maintained until the system is reinitialised.

236
Safety

Deactivation

Only the passenger's front airbag can bedeactivated. )With the ignition off
, inser t the key in thefpassenger airbag deactivation switch. )
Turn it to the "OFF"position. )
Remove the key keeping the switch in the
new position.
When the ignition is on, this warning lamp comes in the instrument panel. It stays on while the airbag isdeactivated.


To assure the safety of your child, the passenger's front airbag must bedeactivated when you install a "rear facing" child seat on the front passenger seat. Other wise, the child would risk being seriously injured or killed if the airbagwere deployed.

Reactivation
When you remove the child seat, with theignition off, turn the switch to the f"ON"position to reactivate the airbag and so assure
the safety of your front passenger in the event
of an impact.
Front airbags
Deployment
The airbags are deployed, except the passenger's
front airbag if it is deactivated, in the event of aserious front impact to all or part of the front impact
zone A, in the longitudinal centreline of the vehicle
on a horizontal plane and directed from the front to
the rear of the vehicle.
The
front airbag inflates between the thorax andhead of the front occupant of the vehicle and the steering wheel, driver's side, and the dashboard,passenger's side to cushion their for ward movement.
System which protects the driver and frontpassenger in the event of a serious front impact
in order to limit the risk of injury to the head and
thorax.
The driver's airbag is fitted in the centre of the steering wheel; the front passenger's airbag is fitted in the dashboard above the glove box.
When the i
gnition is switched on,
this warning lamp comes on in the
instrument panel for approximately
one minute to signal that the front
airbag is activated.

240
Safety
Sit in a normal upright position. Wear a correctly adjusted seat belt. Do not leave anything between theoccupants and the airbags (a child, pet,object...). This could hamper the operation of
the airbags or injure the occupants. After an accident or if the vehicle has beenstolen or broken into, have the airbagsystems checked. All work on the airbag system must be carried out by a CITROËN dealer or a qualified workshop.
Even if all of the precautions mentioned are obser ved, a risk of injury or of minor burns to the head, chest or arms when an airbag is deployed cannot be ruled out. Thebag inflates almost instantly (within a few milliseconds) then deflates within the sametime discharging the hot gas via openings provided for this purpose.


Front airbags

Do not drive holding the steering wheel by its spokes or resting your hands on the centre part of the wheel.
Passengers must not place their feet on thedashboard.
If possible, do not smoke as deployment of the airbags can cause burns or the risk of injury from a cigarette or pipe.
Never remove or pierce the steering wheel or hit it violently.
For the airbags to be fully effective, observe the following safety rules:
Lateral airbags
Use only approved covers on the seats, compatible with the deployment the lateral airbags. For information on the range of seatcovers suitable for your vehicle, you can contact a CITROËN dealer. Refer to the "Accessories" section.Do not fix or attach anything to the seat backs (clothing...). This could cause injuryto the chest or arms if the lateral airbag isdeployed.Do not sit with the upper par t of the body anynearer to the door than necessary.




Curtain airbags

Do not fix or attach anything to the roof. Thiscould cause injury to the head if the cur tainairbag is deployed.
If fitted on your vehicle, do not remove the grab handles installed on the roof, they playa par t in securing the cur tain airbags.

262
Practical information
A. "Sealant" or "Air" position selector. B.
On "I"
/ off "O"
switch.C.
Deflation button. D.Pressure gauge (in bar and p.s.i.). E.Compartment housing:


- a cable with adaptor for 12 V socket,

- various inflation adaptors for
accessories, such as balls, bic
ycle
tyres...

Description of the kit


The speed limit sticker Imust be affixed to the vehicle's steering wheel to remind you that a wheel is in temporary use.
Do not exceed a speed of 50 mph
(80 km/h) when driving with a tyre repaired using this type of kit. F
.Sealant car tridge.G. White pipe with cap for repair.H.
Black pipe for inflation.I.
Speed limit sticker. The t
yre inflation pressures are given on this
label.

290
Practical information

Type 1 fuse tables
Fusebox 1


Dashboard fuses

The fusebox is located in the lower dashboard (left-hand side).
Access to the fuses
)Refer to the paragraph "Access to the tools".
Fuse N°RatingFunctions
F
85 A Steering mounted controls
F1
820 A Touch screen tablet, audio and navigation system, CD player,USB por ts and auxiliary sockets.
F1
615 A
Front 12V socket.
F1
515 A
Boot 12V socket.
F2
85 A STA R T/STOP button.
F3
015 A Rear wiper.
F27 15 A
Front screenwash pump, rear screenwash pump.
F2
615 A
Horn.
F20 5
A Airbags.
F215 A Instrument panel.
F1
95 A Rain and sunshine sensor.
F12 5
A Keyless starting unit.
F2 5
A Manual headlamp adjustment control.

292
Practical information
Type 2 fuse tables
Fuse N°RatingFunctions
F
33 A START/STOP button.
F6A 15 A Touch screen tablet, audio and navi
gation system, CD player,USB ports and auxiliary sockets.
F8 5
A Alarm.
F
93 A Steering mounted controls.
F1
95 A Instrument panel.
F2
43 A Rain and sunshine sensor.
F25 5
A Airbags.
F33 3
A Memorisation of driving position.
F3
45 A Electric power steering.
F13 10 A
Fr
ont 12V socket.
F1410 A
Boot 12V socket.
F1
63 A Map reading lamps in row 1 cour tesy lamps.
F27 5
A Electronic gearbox gear selector.
F3
020 A Rear wiper.
F3
83 A Manual headlamp adjustment control.

300
Practical information





Towing the vehicle
The towing eye is installed in the boot under
the floor.
To gain access to it:)open the boot, )lift the floor and remove it,)remove the towing eye from its housing.

General recommendations
Observe the legislation in force in your country. Ensure that the weight of the towing vehicle is higher than that of the towed vehicle. The person at the wheel of the towed vehicle must have a valid driving licence.When towing a vehicle with all four wheels on the ground, always use an approved towing bar; rope and straps are prohibited. When towing a vehicle with the engine off, there is no longer any power assistance for braking or steering. In the following cases, you must always call on a professional recovery service: - vehicle broken down on a motor way or fast road, - 4 wheel drive vehicle, - when it is not possible to put the gearbox into neutral, unlock the steering, or release theparking brake, - towing with only two wheels on the ground, - where there is no approved towing bar available...
Procedure
for having your vehicle towed or for towing another vehicle using the towing eye.
Access to the tools

301
7
Practical information

To w i ng another vehicle
)
On the rear bumper, unclip the cover bypressing at the bottom. )
Screw the towing eye in fully. )
Install the towing bar. )
Switch on the hazard warning lamps on
both vehicles.)
Move off gently, drive slowly and for a shor t distance.
)On the front bumper, unclip the cover bypressing on the left. )Screw the towing eye in fully. )Install the towing bar.


To w i ng your vehicle
)Place the gear lever in neutral(position N
on an electronic or automatic gearbox). Failure to observe this instructioncould result in damage to certain components (braking, transmission...) and the absenceof braking assistance the next time the engine is star ted.
)
Unlock the steering by turning the keyin the ignition one notch and release the
parking brake.
) Switch on the hazard warning lamps onboth vehicles.
)
Move off gently, drive slowly and for a shor tdistance.
