4
After the ignition has been switched off, the headlamps remain on briefly to make your exit from the vehicle easier when the light is poor.
ASR and ESP systems
These systems are linked to assure the
directional stability o
f the vehicle, within the
limits of the laws of physics.

Glass panoramic sunroof

This roof provides incomparable visibility and light in the passenger compartment.
Rear parking sensors / Reversing camera
These two systems warn you if an obstacle is detected behind the vehicle
when reversing.
11
7
Stop & Start
This system puts the engine
temporarily into standby
during stops in the traffic (red lights, traffic jams, etc....). The
engine restar ts automatically as soon as you want to move
off. The Stop & Start systemreduces fuel consumption, exhaust emissions and thenoise level when stationary.
Exterior
14 0 / 142
83
133

Familiarisation
8
1. Cruise control / speed limiter switches. 2.
Steering wheel adjustment control.3.Lighting and direction indicator control stalk. 4.
Instrument panel. 5.
Driver's airbag.Horn.
6.Gear lever.
7. Bonnet release.
8.Door mirror controls.
Electric window controls.
Rear electric windows and doors deactivation control.9. Fusebox.10.Manual headlamp height adjustment. 11.
Front side window demisting vent.12 .Windscreen demisting vent.


Instruments and controls

.Familiarisation
13

Lighting

Ring A

Ring B
Raise or lower the lighting stalk passing thepoint of resistance; the corresponding directionindicators will flash for as long as the stalkremains in this position.
Direction indicators


Switching on "AUTO" mode
)Press the stalk down and release it.


Ring B: rear wiper
8188 Li
ghting off.
Automatic illumination of headlamps.
Sidelamps.
Dipped / main beam headlamps.
Rear
foglamp.

or
Front and rear
foglamps. P
ark.
Intermittent wipe.
Wash-wi
pe.

Control stalk A: windscreen wipers


Wipers


Switching off "AUTO" mode
)
Push the stalk up and return it to position "0".
114
"Motorway" function
Press the lighting stalk up or down once,without passing the point of resistance; thecorresponding direction indicators will flash
three times.
You can use this function at any speed, but it is particularly useful when changing lane on high-
speed roads.
Seeing clearly
87
89
80

20















































Eco-driving
Optimise the use of your gearbox
With a manual gearbox, move off gently, change up without waitingand drive by changing up quite soon. If your vehicle has the system,the gear shift indicator invites you to change up; it is displayed in the instrument panel, follow its instructions.
With an automatic or electronic gearbox, stay in Drive "D"
or Auto "A",according to the type of gearbox, without pressing the accelerator pedal heavily or suddenly.

Drive smoothly
Maintain a safe distance between vehicles, use engine braking rather than the brake pedal, and press the accelerator progressively. Thesepractices contribute towards a reduction in fuel consumption and CO2emissions and also helps reduce the background traffic noise.


If your vehicle has cruise control, make use of the system at speedsabove 25 mph (40 km/h) when the traffic is flowing well.



Control the use of your electrical
equipment


Before moving off, if the passenger compar tment is too warm, ventilate it by opening the windows and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and leave the air ventsopen.
Remember to make use of equipment that can help keep the temperature in the passenger compar tment down (sunroof and windowblinds...).
Switch off the air conditioning, unless it has automatic digital regulation,as soon as the desired temperature is attained. Switch off the demisting and defrosting controls, if not automatic. Switch off the heated seat as soon as possible.


Switch off the headlamps and front foglamps when the level of lightdoes not require their use.


Avoid running the engine before moving off, particularly in winter; your vehicle will warm up much faster while driving.


As a passenger, if you avoid connecting your multimedia devices
(film, music, video game...), you will contribute towards limiting theconsumption of electrical energy, and so of fuel.
Disconnect your por table devices before leaving the vehicle.

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2emissions.

1
Monitoring
23








Indicator and warning lamps


Visual indicators informing the driver that a system is in operation (operation or deactivation indicator lamps) or of the occurrence of a fault (warning
lamp).
Associated warnings
The illumination of certain warning lamps may
be accompanied by an audible signal and amessage in the multifunction screen.
The warning lamps may come on continuously (fixed) or flash.

When the ignition is switched on

Certain warning lamps come on for a few seconds when the vehicle's ignition is switched on.
When the engine is started, these same
warning lamps should go off.
If they remain on, before moving off, refer to the
information on the warning lamp concerned.
Certain warning lamps may come onin one of two different modes. Only by relating the type of illumination to the operating status of the vehicle can itbe ascertained whether the situation isnormal or whether a fault has occurred.

Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.

Warning lampis onCauseAction / Observations
Left-hand directionindicator
flashing with buzzer.The lighting stalk is pushed down.
Right-hand direction indicatorr

flashing with buzzer. The lighting stalk is pushed up.
Sidelamps
fixed. The lighting stalk is in the
"Sidelamps" position.
Dipped beamheadlamps fixed. The lighting stalk is in the "Dipped beam headlamps" position.
Main beam headlamps fixed. The lighting stalk is pulled towardsyou. Pull the stalk to return to dipped beam headlamps.

2
Multifunction screens
45

Display confi guration
Once this menu has been selected, you can
gain access to the following settings:


- brightness-video setting,

- date and time setting,

- selection of the units.
Example: setting of the duration of the guide-me-home lighting
)Press the "  " or "  " buttons, then
the "OK"
button to select the menu required.
)Press the "
" or "
" buttons, then
the "OK"
button to select the "Guide-me-home headlamps" line.
)
Press the " " or " " buttons to set the
value required (15, 30 or 60 seconds), then
press the "OK"button to confirm.
) Press the "
" or "" buttons, then
the "OK"button to select the "OK"
box
and confirm or press the "Back" button tocancel.
Once the fuel consumption unit has been changed to mpg, the informationrelating to speed and distance also changes to miles.
Ad
just the date and time) Select the "Date and time adjustment"
function using the "
" or "
" button.)
Press the "OK"button to confirm the selection. )
Adjust the settings one by one usingthe "  " or "
" button then confirm with
the "OK"
button. )
Then select the "OK"box in the screenand then confirm.

3
Comfort
65

Adjustment
)Adjust the mirror so that the glass is
directed correctly in the "day" position.




Manual day/night model

Da
y / night position
)Pull the lever to change to the "night" anti-dazzle position. )Push the lever to change to the normal"day" position.






Rear view mirror
Adjustable mirror providing a central rearward view.
Equipped with an anti-dazzle system, which darkens the mirror glass and reduces the nuisance to
the driver caused by the sun, headlamps from other vehicles...








Steering wheel adjustment
)When stationary, pull the control lever to yrelease the adjustment mechanism.)
Adjust the height and reach to suit your
driving position.) Push the control lever to lock theadjustment mechanism.


As a safety measure, the mirrors should be adjusted to reduce the "blind spot".


As a safety precaution, these operations should only be carried out while the vehicle is stationary.
Automatic day/night model
By means of a sensor, which measures the light from the rear of the vehicle, this system automatically and progressively changes
between the day and night uses.
In order to ensure optimum visibility during your manoeuvres, the mirror lightens automatically when reverse gear is engaged.
