240 Driving off road
If the vehicle threatens to tip over when
driving across a slope , you must immediate­
ly steer downhill in the di rection of the
slope.
D o not par k your veh icle on steep slopes or
g rades .
T o reduce t he risk of tippi ng over, dr ive o n
slopes in the d irection o f the downwa rd slope
(fa ll line) -
not cros swise .
A WARNING
After drivin g through wate r, m ud, slush ,
etc ., the brakes may be slow to take effect
because of wet b rake roto rs and pads. Dry
the brakes f irst by braking carefully to re­
store the full braking effect.
-
(D Note
Vehicle components s uch as the engine,
transmiss io n, suspension or elect rical sys ­
tem can be severely damaged by drivi ng
through wat er.
(1) Tips
- Check the depth of the wate r before dr iv­
i ng th rough it.
- Do not stop the veh icle, dr ive in reverse
or switc h the engine off whe n driving
t hr ough water .
- Keep in mind that oncoming vehicles may create waves that raise t he water
l eve l and make it t oo deep fo r yo ur vehi­
cle to dr ive th rough safely.
- Avoid dr iving thro ugh salt water because
i t can ca use corrosion.

242 Trailer towing
Weight Rating will also change the per­
formance and handling characterist ics of
your vehicle, which could cause a crash result ing in serious injury or death .
- The Gross Vehicle Weight Rat ing for your
vehicle would be exceeded if your vehicle
is simultaneously equipped with Panor ­
am ic sliding sunroof; th ird-row seating;
t railer towing equipment (factory or
dealer-installed) , and running boards
(deale r-installed) . UNDER NO CIRCUM ­
STANCES MAY ALL SUCH ITEMS BE IN­
STALLED ON THE SAME VEHICLE.
Operating instructions
MAX 6.9"
MAX175mm
E
Ill E Ill ... Q) m
Fig. 233 Permi tted ba ll pos it ion of t he t ra iler h itc h
Trailer towing weights
With a factory-installed trailer hitch, the
maximum permissible trailer weight is 6,615
l bs (3,000 kg) . Th e maximum permissible un­
braked trailer weight is 1,650 lbs (750 kg).
With an
aftermarket trailer hitch, the maxi­
m um permissible trailer weight is 5,512 lbs
(2,500 kg) . These specifications apply when
driving on roads having an incline of less than
12%.
Permissible tongue load
F or best vehicle handling under these
changed condit ions, adjust the trailer load so
that the tongue load is at the maximum al­
lowable or slightly lower . You can get an ap ­
prox imation of the tongue load w ith a bath­
room scale or you can measure the load at a
trucking company or weighing station .
With a
factory-installed trailer hitch, the
maximum permissible load on the ball h itch may not exceed 662 lbs
(300 kg). With an
af­
termarket
trailer hitch, the maximum permis­
s ib le load on the ba ll hitch may not exceed
551 lbs (250 kg). It is recommended to use
the maximum permissible load.
Trailer load distribution
Be sure the load in the trailer is held secure ly
in place to prevent it from shifting forward,
backward or sideways.
Never allow a passenger to ride in a trailer
¢&. in Driving instructions on page 243.
Ball mount
The trailer hitch may only be used w ith suita­
ble ball mount and ball¢
fig. 233. In stalla­
tion of the hitch ball must be carried out in ac­
cordance with the manufac turer's instruc­
tions. At the height dimension of 1.5 in
(38.5 mm) a tolerance of +/- 0.5 in (12. 7 mm)
is permissib le.
Engine cooling system
Towing a trailer makes the engine work ha rd­
er . It is important that the cooling system's
performance is up to the additional load .
Make sure that the cooling system has enough
fluid .
Tire pressure
When towing a trailer, infla te the tires of your
vehicle to the cold tire pressu re listed under
" Full l oad" on the tire pressure label. The tire
pressure label is located on the driver's side B­
pillar . Inflate trailer tires to trailer and tire
manufacturers' spec ificat ions .
Lights
The headlight settings shou ld be checked with
the trai ler attached before driving
off. Check
to make sure both vehicle and trailer lights
are working properly.
Safety chains
Be sure trailer safety chains are properly con­
nected from the trai ler to the h itch on the ve ­
hicle. Leave enough slack in the chains to per­
mit turning corners. When you install safety
IJ,,

-Blend must contain not more than 1S%
MTBE.
Seasonally adjusted gasoline
Many gasoline grades are blended to perform
espec ially we ll for winter or summer driving.
During seasonal change-over, we suggest that
you fill up at busy gas stat ions where the sea­
sonal adjustment is more likely to be made in
time .
(D Note
-Methanol fuels which do not meet these
requirements may cause corrosion and
damage to plastic and rubber compo­
nents in the fuel system.
- Do not use fue ls that fail to meet the
specified criter ia in this chapter.
- If you are unable to determine whether
or not a particular fue l blend meets the
specifications, ask your service station or
its fuel supp lier.
- Do not use fuel for which the contents
cannot be identified.
- Fuel system damage and performance
problems resulting from the use of fuels
different from those specified are not
the responsibility of Audi and are not
covered under the New Vehicle or the Emission Control System Warranties.
- If you experience a loss of fuel economy
or driveability and performance prob­ l ems due to the use of one of these fuel
blends, we recommend that you switch
to unblended fuel.
Gasoline additives
Applies to vehicles : wit h gasoli ne e ng in e
A majo r concern among many auto manufac­
ture rs is carbon deposit build-up caused by
the type of gasoline you use.
Although gasoline grades differ from one manufacturer to another , they have certain
things in common. All gasoline g rades contain
substances that can cause deposits to collect
on vital engine parts, such as fuel injectors
and intake valves. Although most gasoline
Fuel supply and filling your fuel tank 257
brands include additives to keep engine and
fuel systems clean, they are not equally effec­
tive .
Audi recommends using TOP TIER Detergent
Gasoline . For more information on TOP TIER
Detergent Gasoline, please go to the official
webs ite (www.toptiergas.com).
After an extended per iod of using inadeq uate
fuels, carbon deposit build-ups can rob your
engine of peak performance.
(D Note
Damage or malf unct ion due to poor fuel
quality is not covered by the Audi New Ve­
hicle Limited Warranty.
Diesel fuel
Applies to veh icles: w ith diesel engine
Always use ULSD (Ultra Low Sulfur Diesel) sul­
fur content 15 ppm or less.
The ULSD (U ltra Low Sulfur Diesel) meets the
ASTM-D-97S (grade 2).
Die sel fuel with a higher concentration than
ULSD-Die sel No. 2 ASTM D975 and Bio-die­
sel with a higher concentration than 5
% like
Bl 1 , B20 or B100 are strictly prohibited.
Service station fue l pumps are labeled with
the correct fuel information for easy recogni­
tion by the user. If the diesel fuel pump is not
labeled ask the station operator what fuel is
being dispensed before filling up your vehicle.
Serv ice stations offering Diesel fuel are gener ­
ally located on truck routes or major high­
ways . Directories of Diesel fuel stations are
usually available at Diese l fuel stations.
Some states in the USA require permits to
purchase Diesel fuel. Check with your State
Motor Vehicle Department .
Diesel fuel may not be available outside the
USA and Canada. Be sure to check before trav-
eling to other countries .
Ill-
•
•

container meets industry standards (ANSI/
ASTM F852 -86).
(D Note
Never drive yo ur vehicle unt il the fuel tank
is complete ly empty. The irregular supply
of fuel can cause misfiring . Gasoline could
enter the exhaust system and damage the
catalyt ic converter.
Refuelling
F ig. 234 Righ t rear vehicle side: Opening th e fue l fill er
flap
F ig. 235 Fu el cap hooked on the opened fuel filler flap
When adding fuel, the ignition and any cellu­
lar phones in the vehicle must be sw itched
off. When activating the central locking, the
fuel filler flap is automatica lly unlocked or
locked. Refuel the ve hicle w ith the ignition
turned
off.
Tak ing th e fu el cap off
• To open the fuel filler flap, press on the left
s ide of the flap¢
fig. 234 -arrow- .
• Unscrew fuel fil ler cap counter-clockwise
and hang it on the fuel fille r flap ¢
fig. 235.
• Check the label on the inside o f the f uel fill­
er flap to determine if the vehicle must be
fueled with gasoline or diesel fuel.
Fuel suppl y and filli ng your fuel t ank 259
Refuelling p ro cedur e
• Insert the fuel nozz le from the gasoline
pump into the fuel fi ller neck as far as it wi ll
go .
• Select a medi um refue lling rate so that the
nozz le switches off automatically when the
tank is full.
Pu tting th e fuel cap bac k on
• After fi lling your tank, twist the fuel filler
cap clockwise as far as it wi ll go.
• Close the fue l filler flap.
T o avoid fuel spill ing or evaporating from the
fuel tank always close fuel filler cap proper ly
and completely. An improperly closed fuel fill­
er cap may also cause the MIL lamp¢
page 2 7
to come on (only vehicles with gasoline en­
gine).
A WARNING
Improper refueling or handling of fuel can
cause fire, explosion and severe burns.
- Fuel is highly flammable and can cause
severe burns and other injur ies.
- Failure to shut the engine off wh ile refu­
eling and/or to insert the pump nozzle
fully into the fuel filler neck could cause
fue l to spray out of filler neck or to over­
f low. Fue l spray and overflowing fue l can
cause a fi re.
- Never use a cel lu lar telephone while re­
fueling. The electromagnetic rad iation
can cause sparks that can ignite f uel va­
pors and cause a fire.
- Never get back into your vehicle whi le re­
fueling. If in exceptional circumstances
you must get back in your vehicle while
refueling, make certain that you close
the door and touch metal to discharge
stat ic electricity before touching the fill­
er nozzle again. Static e lectricity can
cause sparks that can ignite fuel vapors re leased du ring refuel ing .
- Never smoke or have an open flame any­
where in or near your veh icle when refu-
eling or filling a portab le fue l conta iner.
ll>

264 Checking and filling
Checking and filling
Engine hood
Releasing the engine hood
The engine hood is released from inside the
vehicle.
F ig . 2 41 Driver's side footwell: engine hood re lease
lever
.. Open the driver's door.
.. Pull the release lever on the left under the
inst rument panel
c> fig. 241 in the d irect ion
of the ar row .
The hood pops up s light ly under spring pres­
sure.
Opening the engine hood
Fig. 242 Re lease lever under the eng ine hood
Before opening the engine hood, make s ure
that the windshie ld wipers are flat against the
windshie ld. Otherwise, they co uld damage the
pa int on the hood.
.. Lift the hood s light ly
c> _& .
.. Pull up on the release under the hood
¢ fig. 242. This releases the catch.
.. Open the hood all the way.
A WARNING
-Hot eng ine co olant can burn you.
- To reduce the risk of being b urned, never
o pen the hood if you see or hear steam
or coo la nt escaping from the eng ine
compa rtment. Wait unt il no steam or
coo lant can b e seen o r heard before care­
fu lly openi ng the ho od.
Closing the engine hood
.. Pull the hood down un til the pressure from
t he stru ts is reduced .
.. Let the hood
drop down and la tch in p lace.
Do not try to push it shut; it may fail to en­
gage
c> _& .
A WARNING
--
A ho od t hat is not completely latched
could fly up an d block your vi ew while dr iv­
i ng.
- W hen you close the engine hood, c heck it
to make sure the safety catch has p roper­
ly engaged . The hood sho uld be flush
wit h the surrou nding vehicle body parts.
- If you notice while dr iv ing t hat t he hood
is not s ecured properly, stop at once and
close it.
Working in the engine compartment
Be especially careful whenever you work in
the engine compartment .
Whenever you must perform any wo rk in the
engine compartment, for example checking
and filling different fluids, th ere is a risk of
injury, burns and accidents. To pr event per­
sonal injury alway s observe the following
WARNINGS. The engine compartm ent of any
vehicle is a hazardous area
c> &, .
A WARNING
To he lp avo id i njury, before yo u check any­
thi ng under the hoo d:
- Tu rn off the eng ine .
- Remove the igni tion key.

-Apply the parking brake.
- Move selector lever to "P" (Park).
- Always let the engine cool down. Hot
components will burn skin on contact.
- To reduce the risk of being burned, never
open the hood if you see or hear steam
or coolant escaping from the engine
compartment. Wa it until no steam or
coolant can be seen or heard before care­
fully opening the hood.
- Keep children away from the engine com­
partment .
- Never spill fluids on hot engine compo­
nents. They can cause a fire.
- Never touch the radiator fan. The auxili­
ary electric fan is temperature controlled
and can switch on suddenly.
- Never open the coolant reservoir cap
when the engine is still warm. The cool­
ant system is pressurized and hot cool­
ant could spray out .
- Protect your face, hands and arm from
steam or hot engine coolant by placing a
thick rag over the cap when you open the
coolant reservoir .
- Do not remove the engine cover under
any circumstances . This increases the
risk of burns.
- If work on the fuel system or the electri­
cal system is necessary:
- Always disconnect the battery .
- Never smoke or work near heaters or
open flames. Fluids in the engine com­
partment could start a fire.
- Keep an approved fire extinguisher im­
mediately available.
- To avoid electrical shock and personal in­
jury while the engine is running or being
started, never touch:
- Ignition cables
- Other components of the high voltage
electronic ignition system.
- If you must perform a check or repair
with the engine running:
Checking and filling 265
- First, fully apply the parking brake,
move selector lever to "P" (Park) .
- Always use extreme caution to prevent
clothing, jewelry, or long hair from get­
ting caught in the radiator fan, V-belts
or other moving parts, or from contact­
ing hot parts . Tie back hair before
starting, and do not wear clothing that
will hang or droop into the engine.
- Minimize exposure to emission and
chemical hazards~&. .
A WARNING
California Proposition 65 Warning:
- Engine exhaust, some of its constituents,
and certain vehicle components contain
or emit chemicals known to the State of
California to cause cancer and birth de­
fects and reproductive harm. In addition,
certain fluids contained in vehicles and
certain products of component wear con­
tain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm.
- Battery posts, terminals and related ac­
cessories contain lead and lead com­
pounds, chemicals known to the State of
California to cause cancer and reproduc­
tive harms. Wash hands after handling.
Q) Note
When adding fluids, always make sure that
they are poured into the proper container
or filler opening, otherwise serious dam­
age to vehicle systems will occur .
@ For the sake of the environment
To detect leaks in time, inspect the vehicle
floor pan from underneath regularly . If
you see spots from oil or other vehicle flu­ ids, have your vehicle inspected by an au­
thorized Audi dealer. •
•

266 Checking and filling
Engine compartment
These are the most important items that you can check .
Fig. 243 Typical layout for containers, engine oil di pstick and engine oil fille r cap
CD W indshield/head light washer
. ( ") container O ......... ... .. . 279
@ Coolant expansion tank (-L) ... 272
® E
ng ine oi l filler cap ('t".:r.) ... .. . 270
© Eng ine oil dipstick (orange) . .. . 269
® Brake fluid reservoir ((0)) ...... 274
® Power steering reservoir ... .. . 230
(j) Jump start connector(+) under
a cover, ( -) with hex head screw
277, 314
The position of the engine o il fi lling hole and
the engine oil dipstick
r=;, fig. 243 (position ®
and @) can vary according to the type of en­
gine .
_&. WARNING
Before you check anything in the engine
compartment, always read and heed all
WARNINGS ¢.&.
in Working in the engine
comportment on page 264.
-
Engine oil
Engine oil specifications
The engine oil used in your Audi needs the
right kind of oil.
The engine in your Audi is a sophist icated
powerplant that was built to exacting specifi­
cations. This engine needs the right kind of
engi ne oil that meets specifications regard ing
quality and v iscosity so that it can run
smooth ly and reliab ly. Choosing the right oil
and changing oil within the time and mileage
intervals printed in your vehicle's Warranty
&
Maintenance booklet matters a lot more to­
day than it did years ago . Audi has developed
a spec ia l quality standard for eng ine oil that
will help assure that your vehicle's engine w ill
get the lubrication it needs for proper opera­
t ion .
Modern engine lubr ication has taken a quan ­
tum leap in the last few years. Many synthetic "'

oils available today provide better engine lu­
brication that can outlast traditional petrole­
um-based oils, making them a smart choice
for use throughout the life of your Audi.
Whether you use synthetic or petroleum­based engine oil, the oil that you use must
conform to Audi's oil quality standard
VW 502 00 (vehicles with gasoline engine) or VW 507 00 (vehicles with diesel engine) to
help keep your vehicle's engine running
smoothly and help prevent the formation of harmful deposits , sometimes called "sludge,"
that over time can lead to expensive repairs.
At the time of printing, engine oils available in
the U .S . and Canada that meet the exacting
specifications of Audi oil standard VW 502 00 (vehicles with gasoline engine) or VW 507 00
(vehicles with diesel engine) are synthetic en­
gine oils. This does not mean, however, that
every synthetic engine oil will meet Audi oil
standard VW 502 00 (vehicles with gasoline
engine) or VW 507 00 (vehicles with diesel
engine). So always be sure that you use an ap­
proved oil.
To help prevent the formation of harmful de­ posits use only oil with the following specifi­
cations printed on the oil container :
-Audi oil standard VW 502 00 (gasoline en­
gine)
- Audi oil standard VW 507 00 (diesel en-
gine)
Oil container labels may carry the specifica­
tion singly or in combination with other desig­
nations and oil quality standards.
Viscosity
Engine oils are graded according to their vis­
cosity . The proper viscosity grade oil for your
engine depends on climactic or seasonal con­
ditions where you drive. You can use oil with a
viscosity grade of SAE SW40 ac ross all tem­
perature ranges for normal driving conditions.
However, if engine oil viscosity grade SAE
SW40 is not available, you can also use viscos­
ity grade SAE SW-30 or SAE OW-40 as long as
it meets Audi oil quality standard VW 502 00
Checking and filling 267
(vehicles with gasoline engine) or VW 507 00
(vehicles with diesel engine) specifications.
Because engine oil that meets the Audi oil
standard may not be available everywhere
when you need it, we strongly recommend
that you always carry with you an extra quart (liter) of oil that expressly conforms to the
VW 502 00 (vehicles with gasoline engine) or
VW 507 00 (vehicles with diesel engine) spec­
ification, in case you have to top
off the oil
while on the road.
Applies to vehicles with gasoline engine on­
ly: Only if the level of the oil is at or below the
minimum mark on the oil dipstick -and no oil
that expressly conforms to Audi oil standard
VW 502 00 specificat ions is available - may
you top
off with a high quality engine oil, pref­
erably synthetic-based, that meets ACEA A3
or API SM specifications, but even then, only in viscosity grades SAE SW-40, SAE SW-30, or
SAE OW-40 . However, during the entire time
between oil change intervals, never top off
with more than a total of 0.5 qt/liter engine
oil that does not conform to Audi oil specifica­
tion VW 502 00.
Applies to vehicles with diesel engine only:
Only if the level of the oil is at or below the
minimum mark on the oil dipstick - and no oil
that expressly conforms to Audi oil standard
VW 507 00 spec ifications is available - may
you top
off with a high quality engine oil, that
meets ACEA C3 or API CF specifications, but
even then, only in viscosity grades SAE
5W-40, SAE 5W-30, or SAE OW-40. However,
during the entire time between oil change in­
tervals, never top off with more than a total
of 0 .5 qt/liter engine oil that does not con­
form to Audi oil specification VW S07 00.
For more information about engine oil that
has been approved for your vehicle, please
contact either your authori zed Audi dealer or
Audi Customer Relations at 1 (800) 822-2834
or visit our web si te at www.audiusa .com or
www .audicanada .ca. Here you will also find a
current list of oils (manufacturers, brand
names etc.) that conform to Audi oil standard
lilJJ,,
•
•
