EAU1722A
PERIODIC MAINTENANCE AND ADJUSTMENT
EAUT1915
Replacing the fusesThe main fuse box is located above
the battery.ZAUM00**
1
1. Main fuseThe fuse box, which contains the fus-
es for the individual circuits, is located
in the storage compartment. (See
page 3-10.)
ZAUM00**
1
234
5
6
1. Lid
2. Backup fuse
3. Ignition fuse
4. Signaling system fuse
5. Taillight fuse
6. Headlight fuseIf a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off
the electrical circuit in question.
2. Remove the blown fuse, and then
install a new fuse of the specifi ed
amperage. WARNING! Do not
use a fuse of a higher amper-
age rating than recommended
to avoid causing extensive
damage to the electrical sys-
tem and possibly a fire.
[EWA15131]

NOTICE:
After removing and
installing the main fuse, be sure to turn the main switch
from “ON” to “OFF” three
times in 3 seconds intervals to
initialize the idle speed control
system.
[ECAT1062]
Speci ed fuses:
Main fuse:
20 A
Headlight fuse:
15 A
Signaling system fuse:
15 A
Ignition fuse:
7.5 A
Backup fuse:
7.5 A
Taillight fuse:
7.5 A3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
4P9-F8199-E5_CS.indd 6-264P9-F8199-E5_CS.indd 6-26
2011/09/06 14:18:412011/09/06 14:18:41
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
8-2
SPECIFICATIONS
Size
110/70-12 47L
Manufacturer/model
CHENG SHIN / C-992NRear tireType
Tubeless
Size
120/70-12 58L
Manufacturer/model
CHENG SHIN / C-6007LoadingMaximum load
157 kg (346 lb)Tire air pressure (measured on cold
tires)Loading condition
0-90 kg (0-198 lb)
Front
175 kPa (1.75 kgf/cm
2, 25 psi, 1.75 bar)
Rear
200 kPa (2.00 kgf/cm2, 29 psi, 2.00 bar)
Loading condition
90 kg - maximum load
Front
200 kPa (2.00 kgf/cm2, 29 psi, 2.00 bar)
Rear
225 kPa (2.25 kgf/cm2, 33 psi, 2.25 bar)
Front wheelWheel type
Cast wheel
Rim size
J12 X MT2.75
Rear wheelWheel type
Cast wheel
Rim size
J12 X MT3.00Front brakeType
Single disc brake
Operation
Right hand operation
Recommended fl uid
DOT 4Rear brakeType
Drum brake
Operation
Left hand operationFront suspensionType
Telescopic fork
Spring/shock absorber type
Coil spring/oil damper
Wheel travel
78.0 mm (3.07 in)Rear suspensionType
Unit swing
Spring/shock absorber type
Coil spring/oil damper
Wheel travel
95.5 mm (3.76 in)Electrical systemIgnition system
TCICharging system
AC magneto
BatteryModel
MF (YT7B-BS)
Voltage, capacity
12 V, 6.5 AhHeadlightBulb type
Halogen bulbBulb voltage, wattage x quantityHeadlight
12 V, 60 W/55 W x 1
Tail/brake light
12 V, 5.0 W/21.0 W x 1
Front turn signal light
12 V, 10.0 W x 2
Rear turn signal light
12 V, 10.0 W x 2
Auxiliary light
12 V, 5.0 W x 2
Meter lighting
LED x 2
High beam indicator light
LED x 1
Turn signal indicator light
LED x 1FusesMain fuse
20.0 A
Headlight fuse
15.0 A
Taillight fuse
7.5 A
4P9-F8199-E5_CS.indd 8-24P9-F8199-E5_CS.indd 8-2
2011/09/06 14:18:412011/09/06 14:18:41
Process BlackProcess Black

1
2
3
4
5
6
7
8
9
8-3
SPECIFICATIONSSignaling system fuse
15.0 A
Ignition fuse
7.5 A
Backup fuse
7.5 A
Spare fuse
20.0 A x 1
Spare fuse
7.5 A x 1
Spare fuse
15.0 A x 1
4P9-F8199-E5_CS.indd 8-34P9-F8199-E5_CS.indd 8-3
2011/09/06 14:18:412011/09/06 14:18:41
Process BlackProcess Black

INDEXAAcceleration and deceleration ................... 5-2
Air fi lter and V-belt case air fi lter
elements ............................................... 6-13
Auxiliary light bulb, replacing .................. 6-29BBattery ..................................................... 6-24
Brake fl uid, changing .............................. 6-20
Brake fl uid level, checking ...................... 6-19
Brake lever, front ....................................... 3-6
Brake lever, rear ....................................... 3-6
Brake levers, lubricating .......................... 6-21
Brake lever free play, checking ............... 6-18
Brake pads and shoes, checking ............ 6-19
Braking ...................................................... 5-2CCables, checking and lubricating ............ 6-21
Care .......................................................... 7-1
Catalytic converters .................................. 3-9
Centerstand and sidestand, checking and
lubricating ............................................. 6-22DDimmer switch .......................................... 3-6EEngine break-in ......................................... 5-3
Engine oil and oil strainer ........................ 6-10
Engine trouble warning light ...................... 3-2FFinal transmission oil .............................. 6-12
Front fork, checking ................................ 6-23
Fuel ........................................................... 3-7
Fuel consumption, tips for reducing .......... 5-3
Fuel tank cap ............................................ 3-7
Fuses, replacing ...................................... 6-26
HHandlebar switches ................................... 3-5
Headlight bulb, replacing ........................ 6-27
High beam indicator light .......................... 3-2
Horn switch ............................................... 3-6IIdentifi cation numbers ............................... 9-1
Ignition circuit cut-off system ................... 3-12
Indicator and warning lights ...................... 3-2KKeyhole cover ........................................... 3-2
Kickstarter ................................................. 3-9MMaintenance, emission control system ..... 6-3
Maintenance and lubrication, periodic ...... 6-4
Main switch/steering lock .......................... 3-1
Matte color, caution ................................... 7-1
Model label ................................................ 9-1
Multi-function display ................................ 3-3PPanels, removing and installing ................ 6-7
Parking ...................................................... 5-4
Part locations ............................................ 2-1RRear brake lever free play, adjusting ...... 6-18SSafe-riding points ...................................... 1-5
Safety information ..................................... 1-1
Seat ......................................................... 3-10
Sidestand ................................................ 3-11
Spark plug, checking ................................. 6-8
Specifi cations ............................................ 8-1
Speedometer ............................................ 3-3
Starting off ................................................. 5-2Starting the engine .................................... 5-1
Start switch ............................................... 3-6
Steering, checking .................................. 6-23
Storage ..................................................... 7-4
Storage compartments ............................ 3-10
TTail/brake light bulb or rear turn signal light
bulb, replacing ...................................... 6-28
Throttle grip and cable, checking and
lubricating ............................................. 6-21
Throttle grip free play, checking .............. 6-15
Tires ........................................................ 6-16
Tool kit ...................................................... 6-2
Troubleshooting ...................................... 6-29
Troubleshooting chart ............................. 6-31
Turn signal indicator light .......................... 3-2
Turn signal light bulb (front), replacing .... 6-28
Turn signal switch ..................................... 3-6VValve clearance ...................................... 6-15
Vehicle identifi cation number .................... 9-1WWheels .................................................... 6-17
Wheel bearings, checking ....................... 6-24
4P9-F8199-E5_CS.indd 9-24P9-F8199-E5_CS.indd 9-2
2011/09/06 14:18:422011/09/06 14:18:42
Process BlackProcess Black
